- Page 1 O W N E R ’ S M A N U A L T H E S O N I C F R O N T I E R S S F D - 1 D I G I T A L P R O C E S S O R...
- Page 2 CONTROL FUNCTIONS AND CONNECTIONS A-Phase Control Switch - This toggle switch allows the user D-Power Indicator LED - This LED will light when the Power to invert the system phasing easily and safely. When the switch Switch (E) is in the ON position and the SFD-1 is receiving is in the 0°...
- Page 3 F - Detachable Power Cord Socket - Plug the Detachable K -Left and Right Channel RCA Single-Ended Audio Power Cord into this socket (see Figure 1). The SFD-1 is factory Output Connectors - If the balanced inputs are not applic- set for the correct operating voltage for the area in which it is able for use, the RCA single-ended (unbalanced) audio outputs sold (see shipping box for voltage setting).
- Page 4 INSERTION OF THE TUBES OPERATION OF THE SFD-1 DIGITAL PROCESSOR The SFD-1 comes with two 6922 (6DJ8-type) tubes, individual- Before plugging in the SFD-1, check to see that the unit is config- ly boxed and bagged along with a cotton glove, screwdriver, ured for the correct AC line voltage for country of use.
- Page 5 T R O U B L E S H O O T I N G Power Indicator LED (D) will flash on and off for approximately If at any time the SFD-1 Digital Processor fails to work properly, consult 45 seconds. During this time, the signal outputs are muted while this checklist: the two 6922 tubes are warming up and stabilizing.
- Page 6 SFD-1 PLACEMENT FOR PROPER VENTILATION LIMITED FIVE YEAR WARRANTY Allow at least 6” (15 cm) of clear space above the SFD-1 Sonic Frontiers, Inc. warrants to the purchaser that each SFD-1 chassis for proper ventilation, making sure the air vent slots in Digital Processor is free of manufacturing defects for a period the chassis cover remain unobstructed.
- Page 7 SFD-1 TECHNICAL SPECIFICATIONS Input Receiver UltraAnalog AES20 AES/EBU ultra-low jitter Input Receiver Digital Filter NPC 5803 (8-times oversampling) D/A Converter UltraAnalog D20400A (1 Dual) Low Pass Proprietary passive configuration Analog Filter Frequency Response 5 Hz to 20 kHz ± 0.2 dB Intrinsic Jitter <...
- Page 8 We at Sonic Frontiers are sure that you will derive many years of listening pleasure with your new SFD-1 Digital Processor. This Owner’s Manual contains important information regarding the operation and care of the SFD-1. Be sure to read this manual carefully and follow these instructions in order to keep it looking, operating and sounding its best.
