Sony MDR-X05 Operating Instructions

Stereo Headphones
Operating Instructions
Mode d'emploi
Manual de instrucciones
MDR-X05
English Stereo headphones  Multi-folding design for optimum portability.
 Tangle-free serrated cord
Features
Tiny serrations on the flat cord reduce tangling
 Easy-to-use remote control (only for iPod, caused by friction.
iPhone & iPad)
 40 mm driver units reproduce natural and
powerful bass sound.
 Advanced Direct Vibe Structure provides
acoustically tight seal, realizing superior sound
isolation and deep bass sound. Optimized
diaphragm front chamber for more expansive
and clearer mid-range sound.
 Seamless earpads with pressure-relieving
cushions provide ultimate wearing comfort,
and a tight seal for superior sound isolation and
deep bass sound.
 Soft head cushion provides long-term listening
comfort.
©2012 Sony Corporation Printed in China
4-450-456-13(1)
How to use / Utilisation / Utilización
* There is a tactile dot beside Volume +.
* Vous pouvez remarquer un point tactile à côté de Volume +.
* Hay un punto táctil al lado de Volumen +.
Using the Center button Specifications
Plays/pauses a track of the connected iPod
Headphones
product with a single press. Skips to the next track
Type: Closed, dynamic / Driver unit: 40 mm,
with a double press. Skips to the previous track
dome type (CCAW Voice Coil) / Power handling
with a triple press. Starts the "VoiceOver*" feature
capacity: 1,000 mW (IEC*) / Impedance: 40 Ω at
with a long press (if available).
1 kHz / Sensitivity: 104 dB/mW / Frequency
Press once to answer the call. Press again to end.
response: 4 Hz – 24,000 Hz / Cord: 1.2 m (47
Hold down for about two seconds to reject an
Y-type / Plug: Four-conductor gold-plated L-
incoming call. When you let go, two low beeps
shaped stereo mini plug for iPod/iPhone/iPad with
confirm the call was rejected.
remote function / Mass: Approx. 235 g (8.29 oz)
without cord
* Availability of the "VoiceOver" feature depends
on iPod and its software version. Microphone
Open circuit voltage level: – 42 dB (0 dB=1 V/Pa)
Note
Be careful not to unintentionally press any buttons Supplied accessory
when you carry your iPod with this unit connected. Carrying pouch (1)
* IEC = International Electrotechnical Commission
Design and specifications are subject to change
without notice.
Volume +*
Volume +*
Volumen +*
Microphone
Center button
Micro
Touche centrale
Micrófono
Botón central
Volume –
Volume –
Volumen –
Precautions
The validity of the CE marking is restricted to only
those countries where it is legally enforced, mainly
High volume may affect your
in the countries EEA (European Economic Area).
hearing. For traffic safety, do not use
while driving or cycling.
Optional replacement earpads can be ordered
from your nearest authorized Sony retailer or
www.sony.com.
/ in),
1  Because the headphones are of a high density
4
enclosure, forcing them against your ears may
result in eardrum damage. Avoid using the
headphones where they are liable to be struck
by people or other objects, such as a ball, etc.
Pressing the headphones against your ears may
produce a diaphragm click sound. This is not a
malfunction.
You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate this
equipment.
Compatible iPod/iPhone/iPad
 iPad (4th generation)
models  iPad (3rd generation)
 iPad 2
You can use the unit with only the following
 iPad
models supporting remote control. Update your
 iPad mini
iPod, iPhone or iPad to the latest software before
use. In the Operating Instructions, iPod, iPhone
On copyright
and iPad are collectively described as "iPod"
iPad, iPhone, iPod, iPod classic, iPod nano, iPod
except in special cases.
shuffle, and iPod touch are trademarks of Apple
 iPod touch (5th generation)
Inc., registered in the U.S. and other countries.
 iPod touch (4th generation)
"Made for iPod, " "Made for iPhone, " and "Made for
 iPod touch (3rd generation)
iPad" mean that an electronic accessory has been
 iPod touch (2nd generation)
designed to connect specifically to iPod, iPhone
 iPod nano (7th generation)
or iPad, respectively, and has been certified by
 iPod nano (6th generation)
the developer to meet Apple performance
 iPod nano (5th generation)
standards. Apple is not responsible for the
 iPod nano (4th generation)
operation of this device or its compliance with
 iPod classic 120GB 160GB (2009)
safety and regulatory standards.
 iPod shuffle (4th generation)
 iPod shuffle (3rd generation)
 iPhone 5
 iPhone 4S
 iPhone 4
 iPhone 3GS
