Page 2: Package Contents
Your DUB-2240 should contain all the items listed below. Before you begin the installation of the device, please check to make sure that the following items are included in your package. D-Link DUB-2240 Wireless USB 4-Port Hub USB Cable ... -
Page 3: Hardware Overview
Hardware Overview The 4-port USB hub hardware features: Antenna Reset Button Mini USB port Power Receptor D-Link DUB-40 Quick Install Guide... -
Page 4: Installation
After the InstallShield Wizard detects what operating system is running on your PC, the Welcome screen will appear. As instructed, do not plug the USB adapter or hub into the PC at this time. Only the DUB-2240 hub should be powered on. Click Next D-Link DUB-40 Quick Install Guide... - Page 5 Click Next Select a destination folder where the software will be installed. By default the software will install in the C:\Program Files\ D-Link\Wireless USB\folder. Select Change to install in a different folder. Click Next to continue D-Link DUB-40 Quick Install Guide...
- Page 6 Click Next The wizard will notify you when the software has been installed sucessfully and the devices are ready to use. This completes the software setup. D-Link DUB-40 Quick Install Guide...
- Page 7 Once you are associated with the USB hub and the hub is disconnected from the computer, you may plug your USB devices into the wireless hub. Note: For the best reception and performance, position the adapter vertically. D-Link DUB-40 Quick Install Guide...
- Page 8 The Devices screen displays the status of the connection between the wireless USB adapter and hub. From the Devices screen, you can check the connection status of the wireless USB hub, the properties, and setup security for the wireless connection. D-Link DUB-40 Quick Install Guide...
- Page 9 • Prompt before connecting to this device - You will receive an alert asking if you would like to connect to the USB hub. • Manually connect to this device - You must open the software and click Connect to connect to the USB hub. D-Link DUB-40 Quick Install Guide...
- Page 10 Properties You can change the name of the wireless hub. This is helpful if you are attached to multiple hubs. In the box, type in a new name and click Apply. D-Link DUB-40 Quick Install Guide...
- Page 11 The Security Setup page allows you to enable security on the wireless connection between the hub and the user. Click Remove to disable the security. When attempting to connect to a hub that has security enabled, you will be prompted to enter a password. D-Link DUB-40 Quick Install Guide...
- Page 12 Advanced The Advanced screen allows you to change the wireless channel that USB hub uses. Select a new channel and click Apply Now. D-Link DUB-40 Quick Install Guide...
- Page 13 This page also displays what computers the selected hub is currently associated with. When attempting to access the Administration screen you will be prompted to enter the administrator password: Note: The Administration tab is only available when the hub is wired to a computer. D-Link DUB-40 Quick Install Guide...
- Page 14 Notes D-Link DUB-40 Quick Install Guide...
- Page 15 Registration Product registration is entirely voluntary and failure to complete or return this form will not diminish your warranty rights. D-Link DUB-40 Quick Install Guide...
-
Page 16: Technical Support
Copyright ©00 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link and the D-Link logo are registered trademarks of D-Link Corporation or its subsidiaries in the United States and other countries. Other trademarks are the property of their respective owners. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate.
