APEXi S-AFCII (SAFC 2 Wiring Diagram page 16

Manufacturing
Car Name Car Model Engine Model
year
'93.10～'99.10
3S-GTE '91.12～'93.9
'89.10～'91.11
SW20 '97.12～'99.10
MR2 '93.10～'97.11
3S-GE
'91.12～'93.9
'89.10～'91.11
4A-GZE '86.8～'89.9
AW11
4A-GE '84.6～'89.9
ZZT230 1ZZ-FE
'99.9～※
ZZT231 2ZZ-GE
ST205 3S-GTE '94.2～'99.8
3S-GE '93.10～'97.11
'96.6～'99.8
ST203
ST202
3S-FE
'95.8～'96.5
CELICA
'93.10～'95.7
'91.9～'93.9
ST185 3S-GTE
'89.10～'91.8
ST182 3S-GE '89.10～'93.9
ST165 3S-GTE
'85.8～'89.9
ST162 3S-GE
ST206 3S-GE '94.1～'98.7
'96.6～'98.7
CURREN
ST207
3S-FE '95.10～'96.5
ST206
'94.1～'95.9
16
ECU Terminal Sensor
Remarks
Position Drawing Type
PR-2
T5-c
FL-2
T5-b
T9-b HW-13
M T6-b
T5-c PR-3
T5-b
T2-a FL-3
T1-a PR-3
Ｌ Ｔ９－ｂ HW-24
T5-c PR-2
T6-b
M/T T4-f
A/T T5-g
PR-3
M/T T4-a
A/T
E
T5-c
FL-2
T5-b
T5-c PR-3
T2-a
FL-2
T2-c
T6-b
M/T T4-f
A/T T5-g
M/T T4-a
E PR-3
With A/T TRC T6-b
Without A/T TRC T5-c
With TRC T6-b
Without TRC T5-c
