- Page 1 Albrecht AE 77 H Programmable Hand-Held-Scanner Operating Guide...
- Page 3 Nickel-Cadmium Battery Warning! AE 77 H Programmable Do not charge nickel-cadmium batteries with any charger other than Hand-Held Scanner the one supplied by authorized dealer as an option. Using another charger may damage the batteries, or cause Precautions them to explode. Before you use this scanner, please read and observe the following: Earphone Warning!
-
Page 4: Function Keys
Function Keys Controls and Indicators 14. Antenna Connector 15. Phone Jack 16. Squelch Control 17. On/Off Volume Control 23 22 18. Search indicator 19. Frequency Display 1. Display 20. Keypad Lock Indicator 2. Numeric keypad 21. Low Battery Indicator 3. Enter 22. -
Page 5: Table Of Contents
Contents Introduction ....6 What is Scanning? ... . .6 Feature Highlights ....6 Setup . -
Page 6: Introduction
• Priority Channel Scanning – Introduction Allows you to designate a priority channel which is monitored every The AE 77 H Hand Scanner is a two seconds when Priority Scanning sophisticated information radio that is selected. allows you to monitor 6 different •... -
Page 7: Installing The Batteries
Installing the Batteries Charging Warning Do not charge alkaline batteries in this 1. Open the cover. scanner. Doing so may cause serious damage to the product and void the warranty. Before attempting to recharge batteries, make sure you have installed four rechargeable nickel-cadmium batteries. -
Page 8: Basic Operation
Basic Operation Note: See page 4 for function keys, controls and indicators while reading this guide. Setting the Squelch To set the squelch, you must be in the 5. Turn SQUELCH back counter- manual mode. No signal should be clockwise just until the hiss stops. present when adjusting squelch. -
Page 9: Programming
If the frequency entered is outside the Programming frequency range of the scanner, a distinctive beep sounds. (See the table Before the AE 77 H can receive on page 6 or the band list on page 19.) radio broadcasts, you must program a frequency into at least one channel. -
Page 10: Scanning
Channel Lockout Scanning You can lockout any channel so it is not reviewed during normal scanning. When you turn on the power, the You can restore the channel to AE 77 H automatically starts in the scanning whenever you wish. scan mode. -
Page 11: Locking A Channel While Scanning
Locking a Channel While Scanning Restore a Locked Out Channel If the scanner keeps stopping on a 1. Press particular channel due to noise or too frequent transmissions, you may want to keep that channel from scanning. 1. Wait until the scanner stops at the channel. -
Page 12: Restore All Locked-Out Channels
Restore All Locked-out Channels 2. Press PRI again at anytime to deactivate priority scan. 1. Press 2. Press and hold /L/O for about Changing the Priority Channel two seconds. You cannot eliminate the priority channel, but you can change it to any You will hear two beeps when all the other of the 100 available channels. -
Page 13: Searching
5. When Search is stopped, you can Searching L or M to move up or down 1 press frequency step. (See the table on page 19 for the step size for each Band.) Band Search The AE 77H has 6 factory- Preprogrammed Search Bands. -
Page 14: Direct Search
Direct Search 3. Enter upper limit of the search band. You can search by using L or M when a) Enter the frequency number. you listen to a channel. b) Then press 1. Press 2. Select a channel a) Enter the channel number. L or M to begin your b) Then press 4. -
Page 15: Search Hold Feature
5. When search is stopped, you can 4. Press /LIMIT to resume BAND L or M to move up or down 1 press searching. frequency step. Note: The search continues toward either the upper or lower search limit, Search Hold Feature depending on which direction key (L 1. -
Page 16: Storing Search Frequencies
Storing Search Frequencies 4. Press /MON/ CLR and You can quickly store any frequency number key to select the MONITOR you find during search. MEMORY. —OR— 1. Press /MON/ CLR to store the displayed frequency in the /MON/ CLR repeatedly. MONITOR MEMORY. -
Page 17: Care And Maintenance
Repairs Care and Maintenance • Do not attempt any repair. The scanner contains no serviceable General Use parts. Contact the dealer from whom • Turn the scanner off before you purchased the radio or take it to disconnecting the power or replacing a qualified repair technician. -
Page 18: Troubleshooting
Troubleshooting If your AE 77 H is not performing properly, try the following steps. Problem Suggestion Scanner won’t work. 1. Check the connections at both ends of the AC Adapter. 2. Turn on the wall switch of your room. You could be using an outlet controlled by the wall switch. -
Page 19: Specifications
: Uniden Bearcat model UBC105XLT is in compliance with the essential requirements and other relevant provisions of the Council Directive 1999/5/EC. See next page for Albrecht OEM CE declaration valid for Germany... - Page 20 CE Konformitätserklärung/ Declaration of Conformity Hiermit wird erklärt, daß unser Produkt / herewith we declare that our product Empfangsgerät für Funkdienste (Scanner) AE 77 H den folgenden europäischen Normen entspricht: / is in conformity to following European Standards EU-Richtlinien / EU directives 73/23/EEC (LVD); 89/336 EEC (EMC) and 99/5/EEC (R&TTE) EN 301 489-1, EN 301 489-5, EN 301 489-15 (EMC) EN 300 086-2 (PMR Radio) EN 301 783-2 (Amateur Radio)
- Page 21 Frequency Ranges AE 77 H Frequency Steps Mode Application (kHz) Range (MHz) 66– 88 4 m Band, VHF-low range for public utilities 108.0000- 12.5 / International Air Band 136.9916 8.33 137.0000- Weather satellites and military 143.9950 mobile radio 144-145.9875 12.5 2 m Amateur Radio 146.000-174 MHZ VHF Hi Band, Commercial...
