SERVICE MANUAL
Panel System
Display resolution
Antenna
Television System
Channel Coverage
Power Requirements
Inputs/Outputs
DVI-HDTV
Video (IN)
S Video (IN)
Audio (IN)
Component Video Input
CONTROL S (OUT)
Variable/Fixed Audio (OUT)
Monitor/Fixed Audio (OUT)
KE-42XBR900
SPECIFICATIONS
Plasma Display panel
Display resolution:
1024 pixels (horizontal)
768 pixels (vertical)
75 ohm external terminal for VHF/UHF
NTSC, American TV Standard
VHF
2-13
UHF
14-69
CATV
1-125
120V, 60 Hz
1 terminal, 3.3V T.M.D.S., 50 ohms
The DVI-HDTV input terminal is compliant with the EIA-861 standard and is not
intended for use with personal computers.
3 total (1 on front panel)
1 Vp-p, 75 ohms unbalanced, sync negative
3 total
(1 on front panel)
Y: 1 Vp-p, 75 ohms unbalanced, sync negative
C: 0.286 Vp-p (Burst signal), 75 ohms
6 total
(1 on front panel)
500 mVrms (100% modulation)
Impedance: 47 kilohm
2 (Y, P
, P
)
Y: 1.0 Vp-p, 75 ohms unbalanced, sync negative;
B
R
P
B
P
R
1
1
More than 408 m Vrms at the maximum volume
setting (Variable)
More than 408 mVrms (Fixed)
Impedance (output): 2 kilohms
1
FLAT PANEL COLOR TV
US Model
Canadian Model
: 0.7 Vp-p, 75 ohms
: 0.7 Vp-p, 75 ohms
