Actron Sunpro CP7605 Operating Instructions Manual

Actron Sunpro CP7605 Operating Instructions Manual

Dwell/tach/voltmeter

Advertisement

Available languages

Available languages

requerimiento para el buen funcionamiento y
facilidad de manejo del motor.
2. Ajustes de la inyección de combustible - Al-
gunos sistemas de inyección de combustible
tienen un ajuste de autoridad mínimo y máximo
que se debe comprobar durante la puesta a
punto periódica o cuandoquiera que se encuen-
tre algún problema con la velocidad en vacío.
3. Pruebas misceláneas del motor - Muchos de
FULL ONE (1) YEAR WARRANTY
Actron Manufacturing Company, 9999 Walford Av-
enue, Cleveland, Ohio 44102, warrants to the user
that this unit will be free from defects in materials
and workmanship for a period of one (1) year from
the date of original purchase. Any unit that fails within
this period will be repaired without charge when
returned to the Factory. Actron requests that a copy
of the original, dated sales receipt be returned with
the unit to determine if the warranty period is still
in eff ect. This warranty does not apply to damages
caused by accident, alterations, or improper or un-
reasonable use. Expendable items, such as batteries,
fuses, lamp bulbs, fl ash tubes also are excluded from
the scope of this warranty. ACTRON MANUFACTURING
COMPANY DISCLAIMS ANY LIABILITY FOR INCIDENTAL
OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY
WRITTEN WARRANTY ON THE UNIT. Some states do
not allow the disclaimer of liability for incidental or
consequential damages, so the above disclaimer
may not apply to you. This warranty gives specifi c
legal rights, and you may also have rights which vary
from state to state.
©1996, Actron Manufacturing Company
Sunpro is a registered trademark of Sun Electric Corporation and is
used under exclusive license.
2-219301
los procedimientos de prueba indicados en el
manual de servicio del motor requieren que el
motor funcione a una velocidad específi ca du-
rante la prueba. Este instrumento proporciona
excelentes capacidades de monitoreo para este
propósito.
GARANTIA COMPLETA DE UN AÑO
Actron Manufacturing Company, 9999 Walford Avenue,
Cleveland, Ohio 44102, EE.UU., garantiza al usuario que esta
unidad estará libre de defectos de materiales y mano de
obra por un (1) año a partir de la fecha de compra del com-
prador original. Cualquier unidad que falle dentro de este
período será reparada opción de Actron sin cargo cuando
se regrese a la fábrica. Actron requiere que un comprobante
de compra (recibo de venta) fechado acompañe la unidad
para determinar si está en garantía. Esta garantía no es
aplicable a daños causados por accidente, alteraciones,
usos impropios o no razonables. Artículos consumibles,
tales como baterías, fusibles, lámparas y tubos de destello
quedan excluidos de esta garantía. Actron Manufacturing
Company rechaza cualquier responsabilidad de daños
incidentales o indirectos por incumplimiento de cualquier
garantía escrita de la unidad. Algunos estados de los
EE.UU. y ciertos países no permiten el rechazo de cualquier
responsabilidad de daños incidentales o indirectos, por
lo que el rechazo anterior puede no ser aplicable en su
caso. Esta garantía concede derechos legales específi cos
y es posible que Ud. tenga otros derechos que varían de
estado a estado de los EE.UU. y de país a país.
Actron Manufacturing Co.
9999 Walford Avenue
Cleveland, Ohio 44102-4696
20

OPERATING INSTRUCTIONS

Dwell/Tach/Voltmeter
FOR 12 VOLT ELECTRONIC OR
CONVENTIONAL IGNITION SYSTEMS
• OPERATING INSTRUCTIONS
• SAFETY RULES
• TUNE-UP PROCEDURES
• REPAIR PARTS
Angulo de cierre/Tacómetro/Voltí-
metro
PARA SISTEMAS DE ENCENDIDO ELECTRONICO O CONVEN-
CIONAL DE 12 VOLTIOS
• INSTRUCCIONES DE OPERACION
• REGLAS DE SEGURIDAD
• PROCEDIMIENTOS PARA LA PUESTA A PUNTO
• PIEZAS DE REPUESTO
Instrucciones en español — página 11
CP7605

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sunpro CP7605 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Actron Sunpro CP7605

  • Page 1: Operating Instructions

    Actron sin cargo cuando returned to the Factory. Actron requests that a copy se regrese a la fábrica. Actron requiere que un comprobante FOR 12 VOLT ELECTRONIC OR of the original, dated sales receipt be returned with de compra (recibo de venta) fechado acompañe la unidad...
  • Page 2: Safety Guidelines

    VEHICLE MANUAL, SOURCES FOR SERVICE INFORMATION SAFETY GUIDELINES The following is a list of publishers who have service manuals for your specifi c vehicle at nominal cost. TO PREVENT ACCIDENTS THAT COULD RESULT IN SERIOUS INJURY AND/OR DAM- Write to them for availability and prices, specifying the make, style, and model year of your AGE TO YOUR VEHICLE OR TEST EQUIPMENT, CAREFULLY FOLLOW THESE SAFETY vehicle.
  • Page 3: Functions, Connections And Accessories

    FUNCTIONS, CONNECTIONS AND ACCESSORIES ACCESSORIES Fig. 3 Primary Tach Connection — See Figure 2. GREEN Clip of the instrument. DESCRIPTION 1. GM DIAGNOSTIC ADAPTOR TO BAL- LAST 3. TEST LEAD The GM Diagnostic Adaptor is used to make GREEN The Model CP7605 Dwell/Tach/Voltmeter has a CLIP Hook this lead to the proper test point in the connection to vehicle equipped with the GM Di-...
  • Page 4 BASIC SYSTEM CHECK – Charging Voltage diagnosis. Fig. 6 Fig. 9 Primary Tach Connection — Primary Tach Connection — 1. GREEN CLIP – Connect to the Positive (+) Battery 7. If battery voltage remains abnormally high GREEN Clip GREEN Clip terminal.
  • Page 5 scribed under DWELL/TACH/BREAKER POINT Start the engine and allow it to warm up (upper Fig. 13 Fig. 15 Typical General Motors Dwell Variation RESISTANCE MEASUREMENTS radiator hose hot.) Breaker Points Distributor NOTE: When testing a vehicle with dual points, Operate the engine at curb idle OR the RPM MORE THAN 3 DEGREES alternately block one set of points open with a specifi ed by the vehicle emission control label...
  • Page 6: Reglas De Seguridad

    procedures in your vehicle service manual REGLAS DE SEGURIDAD require the engine to run at a specifi c RPM dur- ing the test. Your instrument provides excellent PARA IMPEDIR ACCIDENTES QUE PUEDAN CAUSAR GRAVES LESIONES Y/O monitoring capabilities for this purpose. DAÑAR EL VEHICULO O EL EQUIPO DE PRUEBA, SEGUIR ATENTAMENTE ESTAS REGLAS DE SEGURIDAD Y LOS PROCEDIMIENTOS DE PRUEBA.
  • Page 7 MANUAL DEL VEHICULO, FUENTES DE INFORMACION ACERCA DE SERVICIO. CONTROLES, CONEXIONES Y ACCESORIOS DEL ANGULO DE CIERRE/ La siguiente es una lista de editores que publican manuales de servicio para vehículos específi cos a por TACOMETRO/VOLTIMETRO un precio nominal. Escribirles para averiguar la disponibilidad y precios, especifi cando la marca, estilo y año del modelo del vehículo.
  • Page 8 MEDICION DE LA RESISTENCIA DEL ANGULO DE Fig. 6 Fig. 9 Fig. 3 CONEXION PRINCIPAL DEL CONEXION PRINCIPAL DEL CONEXION PRINCIPAL DEL CIERRE/TACOMETRO/PLATINOS TACOMETRO - Pinza VERDE TACOMETRO - Pinza VERDE TACOMETRO - Pinza VERDE PINZA VERDE - Conectar al tacómetro o terminal AL EQUILIBRA- negativo (-) de la bobina de encendido.
  • Page 9 PRUEBAS DEL SISTEMA ELEC- 3. Selector de función - Voltios 2. Quitar la tapa del distribuidor e inspeccionar los PRUEBA DEL SISTEMA DE ENCEN- platinos. Los platinos bien ajustados adquieren TRICO - POSICION PARA "VOLTS" 4. Girar el motor mientras se observa la escala de 16 DIDO - POSICION PARA "DWELL"...
