- Page 1 Dynamic Messenger User’s Manual DM8m, DM10m Dynamic Messenger...
-
Page 2: Table Of Contents
CONTENTS 1. Introductions ........................3 1.1 8"m Dynamic Messenger ....................3 1.2 10"m Dynamic Messenger ....................3 2. Warnings and Suggestions ....................3 2.1 Safety Precautions ......................3 2.2 Troubleshooting ......................3 2.3 Warranty ......................... 3 3. Installation ........................... 4 3.1 Remove CF Cover ...................... -
Page 3: Introductions
1. Introductions This user’s manual covers operational instructions and technical specifications of 8" and 10" Adview Dynamic Messengers with motion sensor and built-in compact flash card player. Please read it carefully prior to turning on the unit. 1.1 8-inch Dynamic Messenger with motion sensor Frame: 7.25"h X 11"w high impact plastic. -
Page 4: Installation
3. Installation 3.1 Remove Compact flash Cover The DM8/10m will come with a metal cover over the CF port. This cover will need to be removed with a small phillips screw driver before CF card insertion. Once card is inserted metal cover can be reinstalled to keep card from easily being stolen or changed. -
Page 5: Operation Guide
4. Operation Guide 4.1 Remote Control - Before use please remove plastic battery saver sheet from end of remote. SETUP AV/VGA POWER MUSIC PHOTO MOVIE ENTER DISPLAY STOP --/-- MENU VOL- VOL+ MUTE STEP PLAY/PAUSE 4.2 Remote Control Button Functions Memory Card Player 1. -
Page 6: Av Input/Output
4.3 AV Input /Output AV Cable Video Audio Audio Power Adapter Video Plug-In AV Input - Source player must have composite Audio/Visual ouputs, use AV Cable (Included). Plug yellow connector into source video output. Plug white and red connectors into source audio outputs. On DM8/10m plug single cabled 3.5mm stereo jack into Video In and double cabled jack into Audio In. -
Page 7: Motion Sensor
4.5 Motion Sensor Activate Motion Sensor - If jumper is attached to wire connector you will need to remove it. Please store jumper in a safe location. Motion sensor is now activated. If no motion is detected for 5 minutes DM8/10m will Jumper go into sleep mode. -
Page 8: Media Guide
5. Multimedia Player System 5.1 Memory Cards DM8/10m supports Compact Flash cards. 5.2 File Formats Supported Photo: JPEG (file must have * .jpg extension. If left as * .jpeg it will not play) Music: MP3 ( file must have * .mp3 extension) Video: MPEG 1 (VCD, DAT format), MPEG 2 (SVCD, DVD), MPEG4, DivX 3.11/4.x/5.x, XviD VIDEO AUDIO... -
Page 9: Setup Menu-Photo
5.4.1 SETUP MENU—PHOTO PHOTO THUMBNAIL DIGEST ON/OFF—turn this function on/off Enter main page Press ENTER to open submenu PHOTO SETUP Press to highlight item to change, press highlight your selection, press ENTER to save. press to the previous menu, choose MAIN PAGE and press ENTER to go to the previous menu. -
Page 10: Setup Menu-Music
5.4.3 SETUP MENU—MUSIC MUSIC Repeat ONE: repeat one music file ALL: repeat all music files OFF: turn repeat function off Operation as above MUSIC—REPEAT MODE 5.4.4 SETUP MENU—SLIDE SHOW SLIDE SHOW playing function setup MANUAL: slide show playing manually AUTO: slide show playing automatically Operation as above SLIDE SHOW—SLIDE SHOW MODE SLIDE SHOW folder repeat function setup... - Page 11 SLIDE SHOW—INTERVAL TIME ONE SECOND THREE SECONDS FIVE SECONDS TEN SECONDS SLIDE SHOW—INTERVAL TIME SLIDE SHOW—TRANSITION FULL SCREEN None TOP->BOTTOM Wipe Down BOTTOM->TOP Wipe Up T/B->CENTER Box In CENTER->T/B Box Out BLIND;T/B Blinder LEFT->RIGHT Tile Fill Left SLIDE SHOW—TRANSITION RIGHT->LEFT Tile Fill Right L/R->CENTER Tile Box In...
-
Page 12: Setup Menu-Movie
5.4.5 SETUP MENU—MOVIE MOVIE—INTERVAL TIME FAST: Fast Speed NORMAL: Normal Speed Operation as above MOVIE—INTERVAL TIME MOVIE OFF: Turn it off ONE: Repeat one file ALL: Repeat all files SLIDE SHOW—REPEAT MODE 5.4.6 SETUP MENU—PREFERENCES PAGE PREFERENCES PAGE menu can only be accessed when CF card is not inserted into DM8/10m. NOTE: PREFERENCES PAGE—TV TYPE MULTI.SYSTEM:... - Page 13 PREFERENCES PAGE—VIDEO OUTPUT S-VIDEO: S-VIDEO signal output (recommended) YPBPR: YPBPR signal output RGB: RGB signal output PREFERENCES PAGE—VIDEO OUTPUT PREFERENCES PAGE—OSD LANGUAGE ENGLISH: OSD in English CHINESE: OSD in Chinese PREFERENCES PAGE—OSD LANG PREFERENCES PAGE—OSD MESSAGE ON/OFF: Turn it on or off PREFERENCES PAGE—OSD MESSAGE...
-
Page 14: Setup Menu-Exit Setup
PREFERENCES PAGE—DEFAULTS RESET: Restore the default settings PREFERENCES PAGE—DEFAULTS 5.4.7 SETUP MENU—EXIT SETUP SETUP MENU—MAIN PAGE Press to exit. Press ENTER to exit OSD menu Note: You can press SETUP to exit OSD menu after changing the settings. EXIT SETUP... -
Page 15: Menu Setup
6. MENU Setup Press MENU button until desired option is highlighted. General Menu: • VIDEO ADJUST • MENU ADJUST • EXIT 6.1 VIDEO ADJUST BRIGHTNESS - To adjust press VOL- to decrease and VOL+ to increase CONTRAST - To adjust press VOL- to decrease and VOL+ to increase SATURATION - To adjust press VOL- to decrease and VOL+ to increase TINT - To adjust press VOL- to decrease and VOL+ to increase SHARP - To adjust press VOL- to decrease and VOL+ to increase... -
Page 16: Specifications
7. Specifications DM8m Dimensions: 7.25"h x 11.00"w Panel: 8-inch Active Matrix TFT LCD Viewing Area (mm): 161 (H) × 121 (V) Lamp Life: 40,000 Hours Viewing Angel: Vertical 90° / Horizontal 120° Resolution: 800 x 600 Power: DC 12V Operating Current: 1.6A Power Consumption: 19.2W...
