- Page 1 Dynamic Messenger User’s Manual DM8i, DM10i Interactive Dynamic Messenger...
-
Page 2: Table Of Contents
CONTENTS 1. Introductions ........................3 1.1 8"i Dynamic Messenger ....................3 1.2 10"i Dynamic Messenger ....................3 2. Warnings and Suggestions ....................3 2.1 Safety Precautions ......................3 2.2 Troubleshooting ......................3 2.3 Warranty ......................... 3 3. Installation ........................... 4 3.1 Remove CF Cover ...................... -
Page 3: Introductions
1. Introductions This user’s manual covers operational instructions and technical specifications for 8" and 10" Adview Interactive Dynamic Messengers with built-in compact flash card player. Please read it carefully prior to turning on the unit. 1.1 8-inch Interactive Dynamic Messenger Frame: 9"h X 12"w high impact plastic. -
Page 4: Installation
3. Installation 3.1 Remove Compact flash Cover The DM8/10i will come with a metal cover over the CF port. This cover will need to be removed with a small phillips screw driver before CF card insertion. Once card is inserted metal cover can be reinstalled to keep card from easily being stolen or changed. -
Page 5: Operation Guide
4. Operation Guide 4.1 Remote Control - Before use, please remove plastic battery saver sheet from end of remote. The remote control for interactive units has very limited functionality. To power DM8/10i On/Off, plug or unplug adapter cord, as Power key on remote does not function. SETUP AV/VGA POWER... -
Page 6: Audio Output
4.3 Audio Output Audio Cable 3.5mm Composite Stereo Jack Audio Jacks Audio Power Adapter Plug-In Audio Output - DM8/10i can output to any player with composite audio inputs, use Audio Cable (Included). Plug white and red composite jacks into player audio inputs. On DM8/10i plug 3.5mm stereo jack into Audio Out. -
Page 7: Media Guide
5. Interactive Player System 5.1 Memory Cards DM8/10i supports Compact Flash cards. 5.2 File Formats Supported Video: MPEG 1 (VCD, DAT format), MPEG 2 (SVCD, DVD), MPEG4, DivX 3.11/4.x/5.x, XviD Video File Formats: MPG, AVI, MP4, DAT, VOB 5.3 Compact Flash Setup After copying desired files, carefully insert CF card into CF port, it will only fit one way. -
Page 8: Menu Setup
6. MENU Setup Press MENU button until desired option is highlighted. General Menu: • VIDEO ADJUST • MENU ADJUST • EXIT 6.1 VIDEO ADJUST BRIGHTNESS - To adjust press VOL- to decrease and VOL+ to increase CONTRAST - To adjust press VOL- to decrease and VOL+ to increase SATURATION - To adjust press VOL- to decrease and VOL+ to increase TINT - To adjust press VOL- to decrease and VOL+ to increase SHARP - To adjust press VOL- to decrease and VOL+ to increase... -
Page 9: Specifications
7. Specifications DM8i Dimensions: 9.00"h x 12.00"w Panel: 8-inch Active Matrix TFT LCD Viewing Area (mm): 161 (H) × 121 (V) Lamp Life: 40,000 Hours Viewing Angel: Vertical 90° / Horizontal 120° Resolution: 800 x 600 Power: DC 12V Operating Current: 1.6A Power Consumption: 19.2W...
