Model : ALEDVD31511E Super Slim Digital LED TV Incorporating “Led Backlight” Technology with DVD, DVBt “Freeview”& HDMI Customer Help Line : 0845 293 7698 Website : www.ekey.co.uk...
Contents Safety Information Safety Instructions Digital Switchover Accessories User Controls Remote Control Connections Menu Operation Teletext “Analog” Teletext “Digital” EPG (Electronic Programme Guide) DVD Operation DVD Setup menu’s Disc Care Wall Mounting Trouble Shooting Guide Specifications Rovi Statement...
1. Safety Information The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of un-insulated “dangerous voltage” within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to the persons. The exclamation point within an equilateral triangle is intend to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
2. Safety Instructions CAUTION. PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS USER MANUAL AND MARKED ON THE APPLIANCE. RETAIN THIS BOOKLET FOR FUTURE USE. This set has been designed and manufactured to assure your personal safety. Improper use can result in Electric shock or Fire hazard.
4. Accessories Please check the contents of the TV before you continue. If any item is missing please contact your point of purchase. User Manual Remote Control Female Scart to Mini Scart Jack to RCA x 3 lead CVBS Jack to RCA x 3 lead YPbPr...
5. User Controls. Side View Eject. Press to eject disc.. Play / Pause. Press to Play disc, press again to Pause, Press again to continue playing. 3. Vol + Increases Volume level. In menu mode, will shift the selection to the right, or increase level being adjusted.
6. Remote Control 1. STANDBY. Switches TV to Standby 2. MUTE. Press to mute sound, press and Operation. again to restore sound. 3. P MODE. Selects picture modes. 4. INFO. Displays information of disc contents, time playing etc. 5. S MODE. Selects sound modes. 6.
Page 8
6. Remote Control. Battery Fitting and Disposal Open the battery cover Fit two “AAA” batteries. Ensure the battery polarities are correct i.e + to + and – to -. Replace the battery cover To prevent injury, do NOT break open or throw exhausted batteries in a fire. Do not mix batteries, old and new, Carbon or Alkaline.
7. Connections. IMPORTANT. When making connections ensure the TV is disconnected from the MAINS supply input, and that the appliance being connected is also disconnected from the mains supply. PC AUDIO. Stereo audio input from PC (Used in conjunction with VGA input). MiniSCART.
Page 10
7. Connections. Y,Pb,Pr and Audio. Disconnect TV from mains supply. Antenna Connect Y,Pb,Pr inputs and Audio or cable if required. Re connect mains supply to both TV and source. Use SOURCE button to select Y,Pb,Pr. Under Side Connectors HDMI PC connections. Disconnect TV from mains supply.
Page 11
7. Connections. Y,Pb,Pr Lead CVBS, R / L audio Lead (supplied) (supplied) Yellow = CVBS (Video) Green = Y Red = Right Audio Red = Pr White = Left Audio Blue = Pb Source/ Input Menu. To access the Source menu, press the SOURCE button on the Remote Control or the INPUT button on the TV.
8. Menu Operation. Fig 1 Basic Tuning Press the LCD MENU button on the Remote Control. The menu as in Fig 1 will be shown. Using the ▲/▼ buttons select “AUTOTUNING” and press OK. Menu Fig 2 will be displayed. If you are in another country other than UK, use the ►/◄...
Page 13
8. Menu Operation. OSD Menu. Press the LCD MENU button to display the main menu, Fig 4 will be displayed. Fig 4 To select the other menu’s press the ► button and the menu’s will rotate in the sequence :- Picture, Sound, Time, Setup, Lock, Channel. To enter each menu press the ▼...
Page 14
8. Menu Operation. Sound. (Fig 7) Sound Mode. Select from :- Standard, Music, Movie, Sports and Personal. Standard. Used for general viewing. Music. Selected for enhanced music appreciation. Movie. A more dynamic setting suitable for movie viewing. Fig 7 Sports. Suitable for sports viewing. Personal.
8. Menu Operation. Channel. (Fig 11). Fig 11 Auto Tuning. After initial installation it may be necessary to re install all the stations. Select Auto Tuning and press OK. The sub menu (Fig 12) will be shown. If using in the UK select Start with the ▼ button and press OK. If using in another country, select the country using the ►/◄...
Page 16
8. Menu Operation. Programme Edit. (Analog) (Fig 15). Delete “Red” Should it be necessary to Delete a station, use the cursors to select the station to be deleted. Press the RED button, this will put a RED marker next to the station to be deleted, press RED again and the station will be deleted, to exit delete press the Menu button.
Page 17
8. Menu Operation. Using a CAM (Conditional Access Module) (CI Slot). Fig 17 This feature allows the user to access digital terrestrial “pay per view” channels. To use this facility a conditional access module (CAM) and viewing card need to be obtained by subscribing to a pay channel company. To insert the module.
9. Teletext. (Analog) TV Teletext is an information system broadcast by certain programme providers. It can provide Subtitles for viewers hard of hearing. Weather, Travel information, games and many other services. Below is a description of the buttons associated with Teletext. TEXT.
11. EPG (Electronic Programme Guide) (DVBt only). An “Electronic Programme Guide” EPG is provided by the programme providers. To access this press the Fig 22 EPG button on the remote control. The EPG provides programme information for the next 7 days. (Fig 22) Press▲/▼to move up and down the list and ►/◄...
Page 20
13. DVD Setup Menu’s TV System. This is set to “PAL” as default and it should not be changed. Screen Saver. When switched on the Screen Saver will be displayed after 5 minutes of DVD Pause or DVD Stop. Default is “On”.
Mount the TV to the wall bracket using 4 x 5 mm x 15 mm set screws. (Do NOT use longer screws as the internal parts of the TV may be damaged). Akura Ltd accepts no responsibility for any damage, caused to or by, incorrect mounting of the wall bracket. Fig 27...
16. Trouble shooting guide. Should you experience difficulties operating this product please consult the guide below before calling the Customer Help Line. SYMPTOM POSSIBLE CAUSE REMEDY Dead No led lit Power not connected to TV Check power lead connections and mains switch is turned on No Picture.
17. Specifications. ITEM DESCRIPTION 100-240V AC 50/60 Hz (70W ave) Power Requirements (100W) max Standby Power <1W Visible Screen Size 31.5" (80cm) diagonal Case dimensions 778 x 543 x 210 mm inc base Weight 9.46 Kg’s Colour Systems PAL, SECAM Sound Systems (analog ) BG, I, DK, L Audio Output...
