- Page 1 ALED3211E 3U Super Slim Digital LED TV Incorporating “Led Backlight” Technology with DVBt “Freeview”, HDMI & PVR Customer Help Line : 0845 293 7698 Website : www.ekey.co.uk...
-
Page 2: Table Of Contents
Contents Safety Information Safety Instructions Digital Switch over Accessories User Controls Remote Control Connections Menu Operation Basic Tuning OSD Menu TV setting DTV Manual Tuning ATV Manual Tuning Programme edit Cam Module Teletext (Analog) Teletext (Digital) Digital Radio EPG (Electronic Programme Guide ). Media (PVR Hard drive recorder). -
Page 3: Safety Information
1. Safety Information The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of un-insulated “dangerous voltage” within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to the persons. The exclamation point within an equilateral triangle is intend to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. -
Page 4: Safety Instructions
2. Safety Instructions CAUTION. PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS USER MANUAL AND MARKED ON THE APPLIANCE. RETAIN THIS BOOKLET FOR FUTURE USE. This set has been designed and manufactured to assure your personal safety. Improper use can result in Electric shock or Fire hazard. -
Page 5: Accessories
4. Accessories Please check the contents of the TV before you continue. If any item is missing please contact your point of purchase. User Manual Remote Control 2x Female Scart to Mini Scart Jack to RCA x 3 lead CVBS Jack to RCA x 3 lead YPbPr... -
Page 6: User Controls
5. User Controls. Side View Vol + Increases Volume level. In menu mode, will shift the selection to the right, or increase level being adjusted. Vol – Reduces Volume level. In menu mode will shift the selection to the left, or decreases level being adjusted. -
Page 7: Remote Control
6. Remote Control 1. POWER. Switches TV to 2. MUTE. Press to mute sound, press Standby and Operation. again to restore sound. 3. P MODE. Selects picture modes. 4. INFO. Displays TV settings and channel being viewed. 5. S MODE. Selects sound modes. 6. - Page 8 6. Remote Control. Battery Fitting and Disposal Open the battery cover Fit two “AAA” batteries. Ensure the battery polarities are correct i.e + to + and – to -. Replace the battery cover To prevent injury, do NOT break open or throw exhausted batteries in a fire. Do not mix batteries, old and new, Carbon or Alkaline.
-
Page 9: Connections
7. Connections. IMPORTANT. When making connections ensure the TV is disconnected from the MAINS supply input, and that the appliance being connected is also disconnected from the mains supply. PC AUDIO. Stereo audio input from PC (Used in conjunction with VGA input). Mini SCART 1 &... - Page 10 7. Connections. Y,Pb,Pr and Audio. Connect Y,Pb,Pr inputs and Audio Antenna if required. or cable Use SOURCE button to select Y,Pb,Pr. Under Side Connectors HDMI PC connections. Connect VGA (15 pin) plug to TV and PC. Connect stereo audio lead. Use SOURCE button to select VGA.
- Page 11 7. Connections. Y,Pb,Pr Lead CVBS, R / L audio Lead (supplied) (supplied) Yellow = CVBS (Video) Green = Y Red = Right Audio Red = Pr White = Left Audio Blue = Pb Source/ Input Menu. To access the Source menu, press the SOURCE button on the Remote Control or the INPUT button on the TV.
-
Page 12: Menu Operation
8. Menu Operation. Connect the TV to the Mains supply and suitable aerial. It is advisable not to connect other apparatus until you have established that the TV is working correctly. If using the TV for DVBt (Freeview) viewing, the existing aerial may not be suitable. -
Page 13: Osd Menu
8. Menu Operation. OSD Menu. Press the LCD MENU button to display the main menu, Fig 4 will be displayed. Fig 4 To select the other menu’s press the ► button and the menu’s will rotate in the sequence :- Picture, Sound, Time, Setup, Lock, Channel. To enter each menu press the ▼... - Page 14 8. Menu Operation. Sound. (Fig 7) Sound Mode. Select from :- Standard, Music, Movie, Sports and Personal. Standard. Used for general viewing. Music. Selected for enhanced music appreciation. Movie. A more dynamic setting suitable for movie viewing. Fig 7 Sports. Suitable for sports viewing. Personal.
-
Page 15: Tv Setting
8. Menu Operation TV Setting. (Fig 10). Fig 10 After initial installation it may be necessary to re install all the Auto Scan. stations. Select Auto Tuning and press OK. The sub menu (Fig 11) will be shown. If using in the UK select Start with the ▼ button and press OK. If using in another country, select the country using the ►/◄... -
Page 16: Programme Edit
8. Menu Operation Programme Edit. (Analog) (Fig 14). Delete “Red” Should it be necessary to Delete a station, use the cursors to select the station to be deleted. Press the RED button, this will put a RED marker next to the station to be deleted, press RED again and the station will be deleted, to exit delete press the Menu button. -
Page 17: Cam Module
8. Menu Operation Using a CAM (Conditional Access Module) (CI Slot). Fig 16 This feature allows the user to access digital terrestrial “pay per view” channels. To use this facility a conditional access module (CAM) and viewing card need to be obtained by subscribing to a pay channel company. To insert the module. -
Page 18: Teletext (Analog)
9. Teletext (Analog TV) Teletext is an information system broadcast by certain programme providers. It can provide Subtitles for viewers hard of hearing. Weather, Travel information, games and many other services. Below is a description of the buttons associated with Teletext. TEXT. -
Page 19: Epg (Electronic Programme Guide )
12. EPG (Electronic Programme Guide) (DVBt only). An “Electronic Programme Guide” EPG is provided by the Fig 22 programme providers. To access this press the EPG button on the remote control. The EPG provides programme information for the next 7 days. -
Page 20: Recording
13. Media The HDD will now be “Formatted” and “Fig 25” will be shown, then “Fig 26”. When completed “Fig 26” will be displayed. Set the amount of the HDD to allow for “Time Shifting” and press OK. Each press of the ►/◄ buttons will change the allowable time of Time shifting, press “OK”... - Page 21 13. Media Programme. Displays the name of the programme selected. Fig 32 Mode. Sets the number of times the recording will be made. Select from Auto, Once, Everyday, and Weekly. AUTO. This selection automatically sets the recording timer from the EPG and cannot be changed. Once, Everyday and Weekly, opens the menu as in Fig 32 and allows changes to be made.
-
Page 22: Playback
13. Media Fig 35 Media Playback DTV. Press the “INDEX” button on the Remote control. A list of programmes stored on your HDD or Memory stick will be displayed. “Fig 35”. Move up and down the list using the ▲/▼ buttons. To see the details of the item listed, press the ►... -
Page 23: Wall Mounting Guide
Mount the TV to the wall bracket using 4 x 5 mm x 12 mm set screws. (Do NOT use longer screws as the internal parts of the TV may be damaged). Akura Ltd accepts no responsibility for any damage, caused to or by, incorrect mounting of the wall bracket. Fig 41... -
Page 24: Specification
15. Specifications. ITEM DESCRIPTION Power Requirements TV 100-240V AC 50/60 Hz (70W) Standby Power <1W Screen Size 31.5" (80cm) diagonal Case dimensions 777 x 548 x 208 mm inc base Weight 9.14 Kg’s Screen resolution 1366 x 768 pixels Viewing angle V 176º... -
Page 25: Trouble Shooting Guide
16. Trouble shooting guide. Should you experience difficulties operating this product please consult the guide below before calling the Customer Help Line. SYMPTOM POSSIBLE CAUSE REMEDY Check power lead and mains supply connections Power not connected to TV Dead. No led lit and supply to the TV is turned On Press Power button on TV or Power button on No Picture.
