19” LCD TV / DVD Combi Instruction Manual ACLTDVD1921W Customer Help Line: 01422 263313 Opening Hours: Mon-Fri 8am-8pm, Sat 9am-4pm, Sun 11am-4pm Or visit our website at www.ekey.co.uk...
Dear Customer. LCD TV OPERATION Thank you for purchasing this 19” LCD DVD/DVBt combi television. When unpacking please ensure you have the following items :- 1- Important Safety Precaution TV set. Remote Control. 2 x “AAA” battery cells. Mains Adaptor. Mains input connecting lead.
2- Main functions 1.User Safety Information 1. Receives Analog Tv signals. On/Off button. This button does not disconnect the Tv from the Mains Supply. To disconnect from the Mains supply, unplug the mains adaptor at the wall socket. Displays Teletext. 3.
Indicator Light Status 4- Product Overview When the unit is on, the indicator light turns green. The indicator light is red when the TV is in standby mode. (2) Illustration of Connector COAXIAL SCART PC AUDIO R AUDIO VIDEO VIDEO Connector Description.
5- Remote Control Overview 6- Connection between different input signals Remote control Illustration Keys description on the remote control A) Connect with PC signal You can use your LCD-TV as a monitor for your personal computer using a VGA cable (not supplied).
Connection steps 7- Basic operating instructions Read the user guide supplied with your AV devices and ensure that it has Composite or S-Video connectors; Make sure that the power of the LCD-TV and the AV device are off; Turn on the LCD-TV Connect a Composite video cable (supplied) to the yellow composite video connector input on the When the Power button is pressed and the LCD-TV is turned on, the indicator light on the front of the LCD-TV changes from red to green.
Press Reveal to reveal hidden words e.g. quiz page answers. Press again to hide. Select the TV channel you want Red/Green/Yellow/Blue Buttons You can use the number keys on the remote control to directly select TV channels. Fast Text operation. Press the required colour button to jump to the section required quickly. The LCD-TV can store up to 99 channels (1 to 99 ), and you can press the keys on the remote control or on the panel to make a selection.
Page 8
Name of menu Picture of menu Instructions Name of menu Picture of menu Instructions Picture Menu 1. Brightness : Adjusts the brightness of 1. Brightness : Adjusts the brightness the picture, the image becomes brighter of the picture, the image becomes as the number increases.
General Menu Name of menu Picture of menu Instructions 1. Language : Selects the OSD language. Chose between English, French, German Picture Menu , Spanish, Italian and Portuguese. 1. Brightness : Adjusts the brightness of the picture, the image becomes brighter 2.
Page 12
SYSTEM SETUP TV SYSTEM NTSC TV TYPE PASSWORD AUTO RATING RESUME DEFAULT SYSTEM SETUP TV SYSTEM TV TYPE PASSWORD RATING RESUME DEFAULT SYSTEM SETUP TV SYSTEM TV TYPE 4:3PS PASSWORD 4:3LB RATING 16:9 RESUME DEFAULT - 21 - - 22 -...
Page 13
SYSTEM SETUP TV SYSTEM TV TYPE PASSWORD RATING RESUME DEFAULT RESTORE LANGU. SETUP SYSTEM SETUP OSD LANGUAGE ENGLISH TV SYSTEM AUDIO LANG FRENCH TV TYPE SPANISH SUBTITLE LANG PASSWORD ---- MENU LANG GERMAN RATING ITALIAN RESUME PORTUGUESE DEFAULT SYSTEM SETUP 1 KID SAFE LANGU.
11- User Help Guide LANGU. SETUP ENGLISH OSD LANGUAGE FRENCH AUDIO LANG SPANISH SUBTITLE LANG GERMAN MENU LANG ITALIAN PORTUGUESE LANGU. SETUP ENGLISH OSD LANGUAGE FRENCH AUDIO LANG SPANISH SUBTITLE LANG GERMAN MENU LANG ITALIAN PORTUGUESE AUDIO SETUP DOWNMIX LT/RT AUDIO OUT STEREO AUDIO SETUP...
Connect the Brown wire to the (L) terminal adjacent to the fuse ( this may be coloured brown). manufacturers instructions. This appliance must have a 3A fuse fitted. Akura accept no responsibility for damage caused by faulty bracket installation. - 27 - - 28 -...
