Acer Aspire 1610 series User Manual

Hide thumbs Also See for Aspire 1610 series:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual
Acer Aspire 1610 series
User's guide

Advertisement

Table of Contents
loading

Related Manuals for Acer Aspire 1610 series

Summary of Contents for Acer Aspire 1610 series

  • Page 1 Acer Aspire 1610 series User’s guide...
  • Page 2 Copyright © 2004 All Rights Reserved Acer Aspire 1610 Series Notebook Computer User's Guide Original Issue: January 2004 Changes may be made periodically to the information in this publication without obligation to notify any person of such revision or changes. Such changes will be incorporated in new editions of this manual or supplementary documents and publications.

  • Page 3: First Things First

    You are advised to read it thoroughly and keep it handy for future reference. For more information on Acer’s products, services, and support, please visit the web site: http://www.acer.com Basic care and tips for using your computer...

  • Page 4: Taking Care Of Your Computer

    Note: If you are unable to shut down the computer in the usual way, press and hold the power button for more than four seconds. You should then wait at least two seconds before turning the computer on again. Taking care of your computer Your computer will serve you well if you take care of it.

  • Page 5: Taking Care Of Your Battery Pack

    Taking care of your battery pack It is also important that you look after your computer's battery pack. • Use the correct battery model for your computer. Do not use other kinds of batteries. • Turn the power off before removing or replacing the battery. •...

  • Page 7: Table Of Contents

    First things first Your guides Basic care and tips for using your computer Getting familiar with your computer A tour of your computer Front view Left view Right view Rear view Bottom view Features Indicators Keyboard Special keys Touchpad Touchpad basics Launch keys Storage Ejecting the optical drive tray...
  • Page 8 External keypad External pointing device USB devices IEEE 1394 Port Printer Audio devices Expansion devices PC Card Miscellaneous options Battery pack AC adapter Key component upgrades Memory upgrade Hard disk upgrade Moving with your computer Disconnecting from the desktop Moving around Preparing the computer What to bring to short meetings What to bring to long meetings...
  • Page 9 Requesting service International Traveler’s Warranty (ITW) Before you call Appendix A Specifications Appendix B Regulation & safety notices Index...

  • Page 11: Getting Familiar With Your Computer

    Getting familiar with your computer...
  • Page 12 Your Aspire 1610 series notebook computer combines solid performance, versatility, multimedia capabilities and portability with a stylish design. Increase your productivity by working wherever you are. This chapter provides an in-depth "tour" of your computer's features.

  • Page 13: A Tour Of Your Computer

    A tour of your computer After setting up your new Aspire notebook computer, as illustrated in the Just for starters… poster, take a few minutes to explore the unit. Front view Item Description Display screen Liquid-crystal display (LCD) provides visual output. Status indicators Light-emitting diodes (LEDs) that turn on and off to show the status of the...
  • Page 14 Getting familiar with your computer Item Description Launch keys Buttons for launching frequently used programs. See“Launch keys” on page 21 for more details. Power button Turns the computer on and off. Palmrest Comfortable support area for your hands when you use the computer. Click buttons &...

  • Page 15: Left View

    Left view Item Description PC Card slots Support two Type II or one Type III CardBus PC Card(s). Eject buttons Ejects the PC Card(s) from the slots. IEEE 1394 port Connects to IEEE 1394 devices. Infrared port Interfaces with infrared devices (e.g., infrared printer and IR-aware computer).

  • Page 16: Right View

    Getting familiar with your computer Right view Item Description Speaker Delivers stereo audio output. Security keylock Connects to a Kensington-compatible computer security lock.

  • Page 17: Rear View

    Rear view Item Description Power jack Connects to an AC adapter. Parallel port Connects to a parallel device (e.g., parallel printer). S-video port Connects to a television or display device with S-video input. External display port Connects to a display device (e.g., external VGA monitor and LCD projector).

  • Page 18: Bottom View

    Getting familiar with your computer Bottom view Item Description Battery bay Houses the computer's battery pack. Battery release latch Unlatches to remove the battery pack. Memory compartment Houses the computer's main memory.

  • Page 19: Features

    Features Performance • Intel® Pentium® 4 processor 3.06 GHz with 512 KB L2 cache. • Two memory slots supporting 333 MHz DDR, upgradeable to 2GB • High-capacity, Enhanced-IDE hard disk. Display • 15.0” SXGA+ (1400x1050 resolution) TFT LCD panel provides a large viewing area for maximum efficiency and ease-of-use.
  • Page 20 Getting familiar with your computer Human-centric design • Rugged, yet extremely portable, construction. • Stylish appearance. • Full-size keyboard with four programmable launch keys. • Comfortable palm rest area with well-positioned touchpad. Expansion • PC card slot enables a range of add-on options. •...

  • Page 21: Indicators

    Indicators Your computer provides an array of seven indicators located below the dispaly screen, showing the status of the computer and its components. The Power and Sleep status icons are visible even when you close the display cover so you can see the status of the computer while the cover is closed.

  • Page 22: Indicators On Cover

    Getting familiar with your computer Icon Function Description Num Lock Lights when Num Lock is activated. Indicators on cover When the cover of your computer is closed, 2 easy-to-read icons are shown, indicating which state or feature is enabled or disabled. Icon Description Lights up when the computer is on.

  • Page 23: Keyboard

    Keyboard The keyboard features full-size keys with an embedded keypad, separate cursor control keys, two Windows keys, and twelve function keys (hot keys). Special keys Lock keys The keyboard has three lock keys which you can toggle on and off Lock Key Description Caps Lock...

  • Page 24: Embedded Keypad

    Getting familiar with your computer Embedded keypad The embedded numeric keypad functions like a desktop numeric keypad. It is indicated by small characters located on the upper right corner of the keycaps. To simplify the keyboard legend, cursor-control key symbols are not printed on the keys. Desired Access Num Lock On Num Lock Off...

  • Page 25: Windows Keys

    Windows keys The keyboard features two keys that provide Windows-specific functions. Description Windows key Pressed alone, this key has the same effect as clicking on the Windows Start button; it launches the Start menu. It can also be used with other keys to provide a variety of functions: + Tab activates the next Taskbar button.

  • Page 26: Hot Keys

    Getting familiar with your computer Hot keys Using the Fn key with another key creates a hot key, providing a quick and convenient method for controlling various functions. To use a hot key, first hold down the Fn key. Next, press the second key in the combination.
  • Page 27 Hot Key Icon Function Description Fn-F6 Screen blank Turns the display screen backlight off to save power. Press any key to return. Fn-F7 Touchpad toggle Turns the internal touchpad on and off. Fn-F8 Speaker toggle Turns the speakers on and off. Fn-↑...
  • Page 28 Getting familiar with your computer The Euro symbol If your keyboard layout is set to United States-International or United Kingdom or if you have a keyboard with a European layout, you can type the Euro symbol on your keyboard. Note for US keyboard users: The keyboard layout is set when you first set up Windows.

  • Page 29: Touchpad

    Touchpad The built-in touchpad is a PS/2- compatible pointing device that senses movement on its surface. The cursor responds to your finger movements on the touchpad. In addition, the two click buttons provide the same functionality as a computer mouse, while the scroll key enables easy 4-way scrolling in documents and web pages.
  • Page 30 Getting familiar with your computer Right 4-Way Function Left Button Button Scroll Key Execute Click twice Tap twice quickly. quickly. Select Click once. Tap once. Drag Click and hold. Tap twice Then, slide your quickly. On the finger across second tap, the touchpad to slide your drag the cursor...

  • Page 31: Launch Keys

    They are designated as mail button, Web browser button, P1, P2, Bluetooth and Wireless buttons. The Wireless and Bluetooth buttons cannot be set by the user. To set the other four launch keys, run the Acer Launch Manager. Launch Key Default application Email Launches your email application.

  • Page 32: Storage

    Getting familiar with your computer Storage Your computer's design offers a variety of data storage options: • The high capacity Enhanced-IDE hard disk drive. The hard drive is upgradeable, enabling you to increase your storage capacity in the future. Consult your dealer if you need to upgrade.

  • Page 33: Ejecting The Optical Drive Tray

    Ejecting the optical drive tray To eject the optical drive tray: • With the computer turned on, press the optical drive eject button. • The tray will be released, and partially popped open. • Gently pull the tray out to its limit. To load an optical disc: •...

  • Page 34: Connectivity Options

    Getting familiar with your computer Connectivity options Your computer has built-in connectivity options, enabling you to hook up to a network or communicate over a phone line. Ethernet and LAN The integrated network feature allows you to connect your computer to an Ethernet-based (10/100 BASE-T) network.

  • Page 35: Fax/Data Modem

    Fax/data modem Your computer features a built-in fax/data modem, enabling you to communicate over a phone line. This means that you can connect to the Internet via a dialup account with an ISP, log in to your network from a remote location, or send faxes. Warning: Your modem is not compatible with digital phone lines.

  • Page 36: Audio

    Getting familiar with your computer Audio Your computer includes an integrated stereo audio system. Built-in stereo speakers are located at the front on both sides of the unit. Volume is adjusted using software, such as Volume Control in Windows, Volume Fn keys, or any other application that provides a volume adjustment control.

  • Page 37: Securing Your Computer

    Securing your computer Your computer features hardware and software security solutions, in the form of a slot for a Kensington lock and a password facility. Security slot A slot for a Kensington slot enables you to physically protect your computer from theft. Use this feature as follows: •...
  • Page 38 Getting familiar with your computer...

  • Page 39: Operating On Battery Power

    Operating on battery power...
  • Page 40 Your Aspire 1610 series notebook computer operates on battery or AC power. This chapter provides information for operating on battery power, as well as information on how your computer manages and saves power.

  • Page 41: Battery Pack

    Battery pack The computer uses a battery pack that gives you long use between charges. Battery pack characteristics The battery pack has the following characteristics: • Employs current battery technology standards. • Delivers a battery-low warning. The battery is recharged whenever you connect the computer to the mains power supply.

  • Page 42: Installing And Removing The Battery Pack

    Operating on battery power Follow these steps again until the battery has been charged and discharged three times. Use this conditioning process for all new batteries, or if a battery hasn't been used for a long time. If the computer is to be stored for more than two weeks, you are advised to remove the battery pack from the unit.

  • Page 43: Charging The Battery

    To remove a battery pack: Slide the battery release latch to release the battery. Pull the battery from the battery bay. Charging the battery To charge the battery, first make sure that it is correctly installed in the battery bay. Plug the AC adapter into the computer, and connect to a mains power outlet.

  • Page 44: Battery-Low Warning

    Operating on battery power Battery-low warning When using battery power pay attention to the Windows Power Meter. Warning: Connect the AC adapter as soon as possible after the battery-low warning appears. Data will be lost if the battery to become fully depleted and the computer shuts down.

  • Page 45: Power Management

    Power management Your computer features a built-in power management unit that constantly monitors system activity. System activity refers to any activity involving one or more of the following devices: keyboard, touchpad/mouse, floppy disk drive, hard disk drive, optical drive, peripherals connected to the computer, and video memory. If no activity is detected for a period of time (the settings are controlled in Windows Power Management), the computer turns off some, or all, of these devices in order to conserve power.
  • Page 46 Operating on battery power...

  • Page 47: Peripherals And Options

    Peripherals and options...
  • Page 48 Your Aspire 1610 series notebook computer offers good expansion capabilities. This chapter provides information on connecting peripherals to expand your system. It also describes how to upgrade key components to enhance system performance and keep your computer in step with the latest technology. You are advised to consult your dealer for information on peripherals.

  • Page 49: External Display Devices

    External display devices You can connect an external (VGA) monitor or projector to your computer's external display port. Use the Fn + F5 hot key to toggle the display setting between the computer's LCD panel and the external display device. See “Hot keys” on page 16 for more information.

  • Page 50: Usb Devices

    Peripherals and options USB devices Your computer features four USB (Universal Serial Bus) 2.0 ports for connecting a range of USB peripherals. See “External input devices” on page 39, and “Printer” on page 42 for information on connecting a USB keyboard, keypad, mouse or printer. Other common USB devices include digital cameras, scanners, and external storage devices.

  • Page 51: Ieee 1394 Port

    IEEE 1394 Port The computer’s IEEE 1394 port allows you to connect to an IEEE 1394 supported device like a digital video camera. See your video or digital camera’s documentation for details.

  • Page 52: Printer

    Peripherals and options Printer Your computer supports both parallel and USB printers. Refer to the printer's manual for information on: • Setting up the hardware. • Installing the necessary drivers in Windows. • Operating instructions. To use a USB printer, simply connect the device to one of your computer's USB ports, and then wait for Windows to find the new hardware.

  • Page 53: Expansion Devices

    Expansion devices PC Card Your computer features two PC card slots that support two standard Type II or one Type III CardBus (PCMCIA). This greatly increases your computer's usability and expandability. A variety of PC cards are available, such as flash memory, SRAM, fax/data modem, LAN, and SCSI cards.
  • Page 54 Peripherals and options To remove a PC card: Close the application that is using the PC card. Double click on the PC card icon on the taskbar, and then select the option to safely remove the card. Wait for the message telling you that it is now safe to remove the card.

  • Page 55: Miscellaneous Options

    Miscellaneous options Battery pack It is a good idea to have a spare battery, especially when you travel with your computer. This greatly increases your productive range when you are on the move. AC adapter Having a spare AC adapter allows you to keep one in two different places.

  • Page 56: Key Component Upgrades

    Peripherals and options Key component upgrades Your computer is designed to deliver solid performance. However, in time, you might find that your applications demand even more computing power. For this reason, you are able to upgrade key components. Note: Contact your authorized dealer if you decide to perform a key component upgrade.

  • Page 57: Hard Disk Upgrade

    Insert the memory module diagonally in the slot (1), and then press down gently until it clicks in place (2). Replace the memory compartment door, and fasten the screw. The computer automatically detects the new module and reconfigures the memory. Hard disk upgrade It is possible to replace your hard disk with a higher capacity drive when you need more storage space.
  • Page 58 Peripherals and options...

  • Page 59: Moving With Your Computer

    Moving with your computer...
  • Page 60 Your Aspire 1610 series notebook computer is ideal for taking with you when you move around. This chapter provides tips on things to consider when traveling with your computer.

  • Page 61: Disconnecting From The Desktop

    Disconnecting from the desktop Before moving with your computer, you must turn it off and disconnect all peripherals: Save your work and close all applications. Shut down Windows to turn off your computer. Unplug the AC adapter from the mains outlet, and then disconnect it from the computer.

  • Page 62: Moving Around

    Moving with your computer Moving around Sometimes you might need to move your computer a short distance. For example, you might need to move from your office desk to a meeting room. In these situations, you don't have to shut down the operating system.

  • Page 63: Taking The Computer Home

    Taking the computer home When you move between your office and home you will need to prepare your computer for the short trip. Preparing the computer After disconnecting your computer from the desktop, prepare the unit as follows: Remove all media from the drives. Loaded media can damage the drive heads during transit.

  • Page 64: Setting Up A Home Office

    Moving with your computer Setting up a home office If you frequently work on your computer at home, as well as at work, it may be worthwhile purchasing a second AC adapter. This will allow you to travel lighter, as you can keep an AC adapter in each location. You might also find it worthwhile keeping a second set of peripherals at home, such as a keyboard, keypad, mouse and printer.

  • Page 65: Traveling Internationally With Your Computer

    Traveling internationally with your computer Occasionally you might need to travel between countries with your computer. Preparing the computer Prepare the computer as you would for normal travel. Remember to take special precautions for air travel. What to take with you It is advisable to take the following items with you: •...
  • Page 66 Moving with your computer...

  • Page 67: Software

    Software...
  • Page 68 Your Aspire 1610 series notebook computer includes system utilities. This chapter provides information on the important software that comes with your computer.

  • Page 69: System Software

    System software Your computer comes preloaded with the following software: • Microsoft Windows operating system. • Hardware BIOS setup utility. • System utilities, drivers and application software. Note: To run software applications in Windows, first click on the Start button. Next, select the appropriate folder, and then click on the application icon.

  • Page 70: Bios Setup Utility

    Software BIOS Setup Utility The BIOS (basic input/output system) contains important information used to configure the hardware and system software settings. Your computer reads the BIOS when it first starts up, before it loads the operating system. Your computer's BIOS includes a built-in setup utility called Phoenix Software SCU (system configuration utility).

  • Page 71: Troubleshooting

    Troubleshooting...
  • Page 72 This chapter instructs you on how to deal with common system problems. Please read it before calling a technician. Solutions to more serious problems may require opening the computer. Do not attempt to open and service the computer by yourself. Contact your dealer or an authorized service center for assistance.

  • Page 73: Frequently Asked Questions

    Frequently asked questions This section suggests solutions to commonly encountered problems. I press the power button, but my computer does not start or boot-up. Look at the Power status indicator: • If it is not lit, no power is being delivered to the computer. Check the following: If you are running on battery power, the battery may be low and unable to power the computer.
  • Page 74 Troubleshooting There is no audio coming from my computer. Check the following: • The volume may be muted. In Windows, look at the volume control icon on the taskbar. If it is crossed-out, click on the icon and deselect the Mute option. •...
  • Page 75 The optical drive cannot read a disc. Check the following: • Make sure that the disc is supported by the drive. If your computer has a CD-ROM drive, it can read CDs but cannot read DVDs. If your computer has a DVD drive, it can read both CDs and DVDs. •...

  • Page 76: Requesting Service

    Place your proof-of- purchase in the flap located inside the front cover of the ITW passport. If the country you are traveling in does not have an Acer-authorized ITW service site, you can still get in contact with our offices worldwide.

  • Page 77: Appendix A Specifications

    Appendix A Specifications...
  • Page 78 This appendix lists the general specifications of your computer.
  • Page 79 Microprocessor • Intel® Pentium® 4 processor 3.06 GHz with 512 KB L2 cache. Memory • Main memory expandable to 2GB • Dual 200-pin soDIMM sockets. • PC2700 DDR SDRAM (Double Date Rate-Synchronous Dynamic Random Access Memory) support. • 512 KB flash ROM BIOS. Data storage •...
  • Page 80 Appendix A Specifications Audio • Two built-in stereo speakers. • MS DirectSound compatible. • Audio ports for microphone-in and headphones. Keyboard and pointing device • 84/85-key Windows keyboard. • Ergonomically-centered touchpad pointing device. I/O ports • Two Type II or one Type III PC CardBus (PCMCIA) slot. •...
  • Page 81 Environment • Temperature: Operating: 5°C ~ 35°C. Non-operating: -20°C ~ 65°C. • Humidity (non-condensing): Operating: 20% ~ 80% RH. Non-operating: 10% ~ 90% RH. Operating system • Microsoft Windows XP operating system. Power • 59.2W 8-cell Li-Ion battery pack. • 120W AC adapter 20V/6A.
  • Page 82 Appendix A Specifications...

  • Page 83: Regulation Safety Notices

    Appendix B Regulation & safety notices...
  • Page 84 This appendix lists the general notices for your computer.

  • Page 85: Energy Star Guidelines Compliance

    Energy Star Guidelines Compliance As an Energy Star Partner, Acer Inc. has determined that this product meets the Energy Star guidelines for energy efficiency. Declaration of Conformity for EU countries Hereby, Acer, declares that this Aspire 1610 series is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
  • Page 86 Appendix B Regulation & safety notices Do not place this product on an unstable cart, stand, or table. The product may fall, causing serious damage to the product. Slots and openings are provided for ventilation; to ensure reliable operation of the product and to protect it from overheating. These openings must not be blocked or covered.

  • Page 87: Laser Compliance Statement

    Replace the battery with the same type as the product's battery we recommend. Use of another battery may present a risk of fire or explosion. Warning! Batteries may explode if not handled properly. Do not disassemble or dispose of them in fire. Keep them away from children and dispose of used batteries promptly.

  • Page 88: Lcd Pixel Statement

    Appendix B Regulation & safety notices LCD pixel statement The LCD unit is produced with high-precision manufacturing techniques. Nevertheless, some pixels may occasionally misfire or appear as black or red dots. This has no effect on the recorded image and does not constitute a malfunction.
  • Page 89 EN 55024 • • EN 61000-3-2/-3 99/5/EC Radio & Telecommunications Terminal Equipment (R&TTE) Directive Art.3.1a) EN 60950 • Art.3.1b) EN 301 489 -1/-17 • Art.3.2) EN 300 328-2 • • List of Applicable Countries EU member states as of April 2003 are: Belgium, Denmark, Germany, Greece, Spain, France, Ireland, Italy, Luxembourg, the Netherlands, Austria, Portugal, Finland, Sweden, and the United Kingdom.
  • Page 90 2004/1/9 --------------------------- ------------------ Easy Lai/ Director Date Qualification Center Product Assurance, Acer Inc.

  • Page 91: Index

    Index on indicator security setting up a home office taking home traveling internationally ACPI traveling on local trips audio turning off connecting externally connections controlling volume audio troubleshooting external display devices external input devices keyboard, external battery pack keypad, external battery-low warning mouse caring for...
  • Page 92 Index printer connecting keyboard troubleshooting connecting externally problems hotkeys audio lock keys troubleshooting diskette Windows keys display keypad connecting externally floppy drive keyboard launch keys printer left view startup media access rear view on indicator right view memory installing 46– 47 safety upgrading CD or DVD...
  • Page 93 international flights local trips volume adjusting connecting warranty utility International Traveler’s Warran- BIOS Setup Windows keys...
  • Page 94 Index...
