24-Pin Color Display Signal Cable
PIN
Meaning
1.
TMDS Data2-
2.
TMDS Data2+
TMDS Data 2/4
3.
Shield
4.
NC
5.
NC
6.
DDC Clock
7.
DDC Data
8.
NC
9.
TMDS Data1-
10.
TMDS Data1+
TMDS Data 1/3
11.
Shield
12.
NC
PIN
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
TMDS Clock Shield
23.
24.
DDC TMDS Clock-
EN-10
P241W A
Meaning
NC
+5V Power
GND(return for
+5V hsync.vsync)
Hot Plug Detect
TMDS Data0-
TMDS Data0+
TMDS Data 0/5
Shield
NC
NC
TMDS Clock+
