Acer LCD monitor User Manual page 12

PIN NO. DESCRIPTION
1. TMDS Data2-
2. TMDS Data2+
TMDS Data 2/4
3.
Shield
4. TMDS Data4-
5. TMDS Data4+
6. DDC Clock
7. DDC Data
Analogue Vertical
8.
Sync
9. TMDS Data1-
10. TMDS Data1+
TMDS Data 1/3
11.
Shield
12. TMDS Data3-
19-pin color display signal cable (Optional)
PIN NO. DESCRIPTION
1. TMDS Data2+
3. TMDS Data2–
5. TMDS Data1 Shield
7. TMDS Data0+
9. TMDS Data0–
11. TMDS Clock Shield
13. CEC
15. SCL
17. DDC/CEC Ground
19. Hot Plug Detect
24-Pin Color Display Signal Cable
PIN NO.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
PIN NO.
2.
4.
6.
8.
10.
12.
14.
16.
18.
EN- 11
G243HQ
DESCRIPTION
TMDS Data3+
+5V Power
GND(return for
+5V hsync.vsync)
Hot Plug Detect
TMDS Data0-
TMDS Data0+
TMDS Data 0/5
TMDS Data5-
TMDS Data5+
TMDS Clock Shield
TMDS Clock+
DDC TMDS Clock-
DESCRIPTION
TMDS Data2 Shield
TMDS Data1+
TMDS Data1–
TMDS Data0 Shield
TMDS Clock+
TMDS Clock–
Reserved (N.C. on device)
SDA
+5V Power
