American DJ TP-1201 User Instructions

TP-1201
12-CHANNEL TOUCH CONTROL PANEL
(WITH CHASE FUNCTION)

MAIN FUNCTIONS:

•
12CH 24 TOUCH SENSORS.
•
FLASH AND HOLD MODES.
•
3 SETS OF SYNCHRONOUS OR RANDOM CHASE
CONTROLS THAT CAN BE INDIVIDUALLY
OPERATED.

GENERAL FUNCTIONS (FRONT):

1 2
HOLD
American
DJ
TP-1201
TOUCH
PANEL
FLASH
1. HOLD MODE:
Touch to turn channel on,
Touch again to turn channel off.
FLASH BUTTON:
2.
3. CHANNEL INDICATOR LED:
4. CHASE:
Adjusts chase speed
5. MIC:
Internal microphone.
6. AUDIO:
Audio sensitivity.

GENERAL FUNCTIONS (BACK):

AUDIO
EXT.
11
12
11. AUDIO EXT./INT. SWITCH:
Select ext. to use the external audio line input jack,
Select int. to use with internal microphone.
12. EXT. AUDIO INPUT:
external connection for audio line input.
13. 8 PIN SIGNAL OUTPUT JACK FOR
CHANNELS 9-12.
3
Holds channel on while touching it.
Indicates selection.
.
INT.
1
EXT.
AUDIO
INPUT
13
RCA jack to acommidate
American DJ
•
CHASE SPEED CONTROL.
•
AUDIO SELECT INTERNAL OR
EXTERNAL.
7. 1-4:
Selects channels 1-4 to chase.
5-8:
Selects channels 5-8 to chase.
9-12:
Selects channels 9-12 to chase.
8. CHASE INDICATOR LED:
9. AUDIO/CHASE:
mode, push chase to select chase mode.
10. AUDIO/CHASE INDICATOR LED:
Indicates selection.
16
TOUCH SENSITIVITY ADJ.
L H
2
3
14 15
14. 8 PIN SIGNAL OUTPUT FOR CHANNELS 5-8.
15. 8 PIN SIGNAL OUTPUT FOR CHANNELS 1-4.
16. TOUCH SENSITIVITY ADJ. POT:
and flash pads on panel.
17. DC 20V INPUT:
4 5
CHASE
1-4
5-8
9-12
8
Indicates selection.
Push audio to select audio sensitive
DC 20V
INPUT
17
To use external power supply.
TP-1201 Instructions page 1 0f 2
©American DJ Los Angeles, CA 90058
®
®
6
MIC
AUDIO
AUDIO
10
9
10
CHASE
7
To adjust hold
