  6. Operator's manual

Alamo AXTREME2 Operator's Manual

Boom arm
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Rev 02-12
An Operator's Manual was shipped with the equipment in the Manual Canister.
This Operator's Manual is an integral part of the safe operation of this machine
and must be maintained with the unit at all times. READ, UNDERSTAND, and
FOLLOW the Safety and Operation Instructions contained in this manual before
operating the equipment. If the Operator's Manual is not with the equipment,
contact your dealer or Alamo Industrial (800-356-6286) to obtain a Free copy
before operating the equipment.
ALAMO INDUSTRIAL
1502 E. Walnut
Seguin, Texas 78155
210-372-3551
PART'S MANUAL
© 2012 Alamo Group Inc.
Boom Arm
Part
No.02988075P
®
®
