Sharp UP-X500XP Installation Manual

q
1. Removing the rear cover unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2. Removing the side cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
3. Removing the LCD unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
4. Removing the MCR unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
5. Fixing the HDD unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
6. Removing the AC cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
7. Removing the AC adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
8. Removing the Main board (Extention RAM module) . . . . . . . . . . . . . . . . 3
9. COM port connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
9-1. FIXING THE REAR DISPLAY UP-I20DP. . . . . . . . . . . . . . . . . . . . . . . . . . . 4
9-2. FIXING THE POLE DISPLAY: UP-P20DP/DPB . . . . . . . . . . . . . . . . . . . . . 4
9-3. FIXING THE DRAWER UNIT: ER-03DW/04DW . . . . . . . . . . . . . . . . . . . . . 4
9-4. FIXING THE LAN CABLE
10. Removing the contactless clerk key. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
11. Specification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Parts marked with "!" are important for maintaining the safety of the set. Be sure to replace these parts with specified
ones for maintaining the safety and performance of the set.
INSTALLATION MANUAL
CONTENTS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
SHARP CORPORATION
CODE : 00Z
POS TERMINAL
UP-X500
MODEL
(V version)
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
UPX500VIME
