AT-GS950/48 Gigabit Ethernet Smart Switch
Please read this document before you begin to use the management software.
Supported Platforms
AT-S87 Version 1.0.0 Management Software is supported on the AT-GS950/48 Gigabit Ethernet
Smart Switch only.
The AT-GS950/48 Gigabit Ethernet Smart Switch supports the following ATI 100 MB SFP
modules:
AT-SPFX/2
ATSPFX/15
AT-SPFX/40
The AT-GS950/48 Gigabit Ethernet Smart Switch supports the following ATI 1000 MB SFP
modules:
AT-SPSX
AT-SPLX10
AT-SPLX40
AT-SPZX80
Product Documentation
Refer to the Allied Telesis web site at www.alliedtelesis.com for the latest installation and user
guides.
New Features
Version 1.0.0:
LEDs for unit and port status
48 Auto-Negotiating 10/100/1000Base-T twisted pair ports with RJ-45 connectors
Four small form-factor pluggable (SFP) ports
Auto MDI/MDI-X on the twisted pair ports
IEEE 802.3 and IEEE 802.3u compliant
IEEE 802.3x flow control in full-duplex operation; back pressure in half-duplex operation
Store and forward switching mode
MAC address table capacity of up to 8K addresses with automatic aging
Web-based configuration using the AT-S87 management software
SNMPv1 and SNMPv2c management
Port Trunking
Port Mirroring
VLANs
PN 613-000911 Rev B
AT-S87 Version 1.0.0
Software Release Notes
1
AT-S87 Version 1.0.0 Software Release Notes
Allied Telesis, Inc.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Allied Telesis AT-S87
Summary of Contents for Allied Telesis AT-S87
-
Page 1: Software Release Notes
AT-SPSX AT-SPLX10 AT-SPLX40 AT-SPZX80 Product Documentation Refer to the Allied Telesis web site at www.alliedtelesis.com for the latest installation and user guides. New Features Version 1.0.0: LEDs for unit and port status 48 Auto-Negotiating 10/100/1000Base-T twisted pair ports with RJ-45 connectors... - Page 2 7. To permanently save these settings in the configuration file and activate the change, select Save Configuration from the main menu on the left hand side of the web manage- ment page and then click the Save button. PN 613-000911 Rev B AT-S87 Version 1.0.0 Software Release Notes Allied Telesis, Inc.
- Page 3 3. To activate these changes and permanently save these settings to the configuration file, go to the Save Configuration page and click on the Save button. The port configuration changes will only take affect after completing this step. PN 613-000911 Rev B AT-S87 Version 1.0.0 Software Release Notes Allied Telesis, Inc.
- Page 4 Products for return or repair must first be assigned a return materials authorization (RMA) number. A product sent to Allied Telesis without an RMA number will be returned to the sender at the sender’s expense. For instructions on how to obtain an RMA number, go to the Support section on our web site at www.alliedtelesis.com.
