Page 1 Management Software AT-S79 User’s Guide For use with the AT-GS950/16 and AT-GS950/24 Smart Switches Version 1.0.0 613-000207 Rev. A...
Page 2 Copyright © 2005 Allied Telesyn, Inc. All rights reserved. No part of this publication may be reproduced without prior written permission from Allied Telesyn, Inc. Microsoft and Internet Explorer are registered trademarks of Microsoft Corporation. Netscape Navigator is a registered trademark of Netscape Communications Corporation.
Page 3: Table Of Contents
Viewing Switch Information ..........................39 Rebooting the Switch............................42 Pinging a Remote System ..........................44 Returning the AT-S79 Management Software to the Factory Default Values ..........47 Chapter 4: Port Configuration ........................49 Displaying the Port Parameters........................50 Enabling and Disabling a Port .......................... 53 Setting a Port’s Speed and Duplex Mode......................
Page 4 Contents Chapter 6: Port Mirroring ..........................65 Port Mirroring Overview ............................ 66 Configuring Port Mirroring ..........................67 Disabling Port Mirroring ............................ 69 Chapter 7: Virtual LANs ..........................71 VLAN Features ..............................72 Increased Performance ..........................72 Improved Manageability ..........................72 Increased Security............................
Page 5 Viewing System Information ........................... 150 Rebooting a Switch............................153 Pinging a Remote System ..........................154 Returning the AT-S79 Management Software to the Factory Default Values ..........156 Chapter 15: Port Configuration ........................157 Viewing and Configuring Ports Using the Port Configuration Page..............158 Viewing and Configuring Ports Using the Configuration of Port Page............
Page 6 Contents...
Page 7 Figure 32. Software Upgrade Menu (2 of 2) ........................131 Figure 33. Entering a Switch’s IP Address in the URL Field....................136 Figure 34. AT-S79 Login Dialog Box ..........................137 Figure 35. Home Page for the AT-GS950/24 ........................137 Figure 36. IP Configuration Page ............................142 Figure 37.
Page 8 Figures Figure 51. VLAN Information Page ............................183 Figure 52. Modify VLAN Page ............................184 Figure 53. QoS Configuration Page...........................188 Figure 54. Port Priority Configuration Page ........................190 Figure 55. 802.1x Configuration Page ..........................194 Figure 56. RADIUS Configuration Menu..........................198 Figure 57. Broadcast Storm Control Page .........................200 Figure 58.
Page 9 Tables Table 1. Menus Interface Operations ..........................26 Table 2. Default Mappings of IEEE 802.1p Priority Levels to Egress Port Priority Queues ..........97 Table 3. AT-S79 Default Settings .............................205...
Page 10 Tables...
Page 11: Preface
Preface This guide contains instructions on how to use the AT-S79 management software to manage and monitor the AT-GS950/16 and AT-GS950/24 Smart Switches. The AT-S79 management software has two management interfaces — a menus interface and a web browser interface. The menus interface is accessed through the Console port on the switch.
Page 12: Where To Find Web-Based Guides
Preface Where to Find Web-based Guides The installation and user guides for all Allied Telesyn products are available in portable document format (PDF) on our web site at www.alliedtelesyn.com. You can view the documents online or download them onto a local workstation or server.
Page 13: Document Conventions
AT-S79 Management Software User’s Guide Document Conventions This document uses the following conventions: Note Notes provide additional information. Caution Cautions inform you that performing or omitting a specific action may result in equipment damage or loss of data. Warning Warnings inform you that performing or omitting a specific action...
Page 14: Contacting Allied Telesyn
Preface Contacting Allied Telesyn This section provides Allied Telesyn contact information for technical support as well as sales and corporate information. Online Support You can request technical support online by accessing the Allied Telesyn Knowledge Base: http://kb.alliedtelesyn.com. You can use the Knowledge Base to submit questions to our technical support staff and review answers to previously asked questions.
Page 15: Chapter 1: Overview
Chapter 1 Overview This chapter provides an overview of the AT-S79 management software for the AT-GS950/16 and AT-GS950/24 switches. The chapter describes the different methods for accessing the software and the management access levels. This chapter contains the following sections: “Management Overview”...
Page 16: Management Overview
Chapter 1: Overview Management Overview The AT-S79 management software allows you to view and adjust the operating parameters of the AT-GS950/16 and AT-GS950/24 Smart Switches. Here are a few examples of the functions that you can perform with the management software: Enable and disable ports Configure a port’s speed and duplex mode...
Page 17: Local Management Connection
AT-S79 Management Software User’s Guide Local Management Connection To establish a local management connection with an AT-GS950/16 or AT-GS950/24 Smart Switch, you connect a terminal or a PC with a terminal emulator program to the terminal port on the front of the switch using the management cable included with the unit.
Page 18: Remote Management Connection
Chapter 1: Overview Remote Management Connection The AT-S79 management software has a web browser interface that you can use to manage an AT-GS950/16 or AT-GS950/24 Smart Switch from any management station on your network that has a web browser application. This is referred to as a remote connection.
Page 19: Management Access Level
AT-S79 Management Software User’s Guide Management Access Level The AT-S79 management software has one level of management access: manager. When you log in as a manager, you can view and configure all of a switch’s operating parameters. You log in as a manager by entering the appropriate username and password when you start an AT-S79 management session.
Page 20: Ports 15 And 16 On The At-Gs950/16 Switch And Ports 23 And 24 On The At-Gs950/24 Switch
Chapter 1: Overview Ports 15 and 16 on the AT-GS950/16 Switch and Ports 23 and 24 on the AT-GS950/24 Switch This section applies to the twisted pair and optional SFP ports 15 and 16 on the AT-GS950/16 switch and ports 23 and 24 on the AT-GS950/24 switch.
Page 21: Section I: Using The Menus Interface
Section I Using the Menus Interface The chapters in this section explain how to manage the switch using the menus interface of the AT-S79 management software. The chapters include: Chapter 2, “Getting Started with the Menus Interface” on page 23 Chapter 3, “Basic Switch Parameters”...
Page 22 Section I: Using the Menus Interface...
Page 23: Chapter 2: Getting Started With The Menus Interface
Getting Started with the Menus Interface This chapter provides information and instructions on how to access the menus interface of the AT-S79 management software by starting a local management session. This chapter contains the following sections: “Starting a Local Management Session” on page 24 “Using the Menus Interface”...
Page 24: Starting A Local Management Session
Chapter 2: Getting Started with the Menus Interface Starting a Local Management Session You establish a local management session with the switch by connecting a terminal or personal computer with a terminal emulation program to the the RS-232 console port on the front panel of the switch. Note You do not need to assign an IP address to the switch to manage the unit from a local management session.
Page 25: Figure 2. Login Menu
AT-S79 Management Software User’s Guide The Login Menu is shown in Figure 2. AT-GS950/16 Local Management System Enter the character in square brackets to select option Login Menu Login: Figure 2. Login Menu 4. Enter the manager login name and press Return. The default name is “manager”.
Page 26: Using The Menus Interface
Chapter 2: Getting Started with the Menus Interface Using the Menus Interface If you are using a DEC VT00 or ANSI (the default) terminal configuration, refer to Table 1 for instructions on how to move through the menus and select menu options. Table 1.
Page 27: Quitting From A Local Management Session
AT-S79 Management Software User’s Guide Quitting from a Local Management Session To quit a local management session, return to the Main Menu and type Q for Quit. When you are finished managing the switch, make sure you exit from a management session. Quitting from a local session prevents unauthorized changes to the switch’s configuration if you leave your...
Page 28 Chapter 2: Getting Started with the Menus Interface Section I: Using the Menus Interface...
Page 29: Chapter 3: Basic Switch Parameters
“Setting the User Interface Configuration” on page 36 “Viewing Switch Information” on page 39 “Rebooting the Switch” on page 42 “Pinging a Remote System” on page 44 “Returning the AT-S79 Management Software to the Factory Default Values” on page 47 Section I: Using the Menus Interface...
Page 30: Configuring The Ip Address, Subnet Mask, And Gateway Address
Chapter 3: Basic Switch Parameters Configuring the IP Address, Subnet Mask, and Gateway Address This procedure explains how to manually assign an IP address, subnet mask, and gateway address to the switch. Before performing the procedure, note the following: An IP address and subnet mask are not required for normal network operations of the switch.
Page 31: Figure 5. System Ip Configuration Menu
AT-S79 Management Software User’s Guide 2. From the Basic Switch Configuration Menu, type I to select System IP Configuration. The System IP Configuration Menu is shown in Figure 5. AT-GS950/16 Local Management System Basic Switch Configuration -> System IP Configuration Menu...
Page 32 Chapter 3: Basic Switch Parameters b. Type the subnet mask for the switch and press Enter. 5. To set the switch’s gateway address, do the following: a. Type G to select Set Default Gateway. The following prompt is displayed: Enter new gateway IP address> b.
Page 33: Enabling And Disabling The Dhcp Client
AT-S79 Management Software User’s Guide Enabling and Disabling the DHCP Client This procedure explains how to activate and deactivate the DHCP client on the switch. When the client is activated, the switch obtains its IP configuration, such as its IP address and subnet mask, from a DHCP server on your network.
Page 34: Configuring System Administration Information
Chapter 3: Basic Switch Parameters Configuring System Administration Information This section explains how to assign a name to the switch, as well as specify the location of the switch and the name of the switch’s administrator. Entering this information is optional. To set a switch’s administration information, perform the following procedure: 1.
Page 35 AT-S79 Management Software User’s Guide b. Type a name for the switch (for example, Sales). The name is optional and can contain up to 50 characters. Note Allied Telesyn recommends that you assign names to the switches. Names can help you identify the switches when you manage them and can also help you avoid performing a configuration procedure on the wrong switch.
Page 36: Setting The User Interface Configuration
Change the console timer, used to automatically end inactive local management sessions. Change the AT-S79 management login user name and password. Enable and disable the web server, used to manage the switch from a remote management station with a web browser.
Page 37 If you disable the web server, you can not manage the switch from a remote management station using a web browser. 5. To change the AT-S79 management login user name, do the following: a. Type N to select Change Administrator User Name.
Page 38 Chapter 3: Basic Switch Parameters c. Type the new user name and press Enter. The default name is “manager.” The name can be from 0 to 12 characters. Spaces are allowed. The login name is case sensitive. Not entering a new login name deletes the current login name without assigning a new one.
Page 39: Viewing Switch Information
AT-S79 Management Software User’s Guide Viewing Switch Information To view general information about the switch, perform the following procedure: 1. From the Main Menu, type G to select General Information. The General Information menu is shown in Figure 8. AT-GS950/16 Local Management System Main Menu ->...
Page 40 Chapter 3: Basic Switch Parameters Hardware Information Section Version The hardware version number. Fixed Baud Rate The baud rate of the console port. DRAM Size The size of the DRAM, in megabytes. Flash Size The size of the flash memory, in megabytes. Administration Information Section Switch Name The name assigned to the switch.
Page 41 AT-S79 Management Software User’s Guide Automatic Network Features Section DHCP Mode The status of the DHCP client on the switch. For information about setting this parameter, refer to “Enabling and Disabling the DHCP Client” on page 33. 2. Press any key to return to the previous menu.
Page 42: Rebooting The Switch
Chapter 3: Basic Switch Parameters Rebooting the Switch This procedure reboots the switch and reloads the AT-S79 management software from flash memory. You might reboot the device if you believe it is experiencing a problem. Rebooting the device does not change any of the device’s parameter settings.
Page 43: Figure 10. System Reboot Menu
Select reboot option (F/I/N)> 4. Type N to select Normal. Note The F and I options are described in “Returning the AT-S79 Management Software to the Factory Default Values” on page 47. 5. Type R to select Start Reboot Process.
Page 44: Pinging A Remote System
Chapter 3: Basic Switch Parameters Pinging a Remote System This procedure instructs the switch to ping a node on your network. This procedure is useful in determining whether an active link exists between the switch and another network device. Note the following before performing the procedure: The switch where you are initiating the ping must have an IP address and subnet mask.
Page 45 AT-S79 Management Software User’s Guide 3. Type I to select Set Target IP Address. The following prompt is displayed: Enter new target IP address> 4. Type the IP address of the node you want the switch to ping and press Enter.
Page 46: Figure 12. Ping Results
Chapter 3: Basic Switch Parameters Figure 12 shows an example of the results of a ping. AT-GS950/16 Local Management System Switch Tools Configuration -> Ping Execution Target IP Address: 149.35.8.33 Number of Requests: Timeout Value (sec): ================Result================= No. 1 20 ms No.
Page 47: Returning The At-S79 Management Software To The Factory Default Values
This procedure returns all AT-S79 management software parameters to their default values and deletes all tagged and port-based VLANs on the switch. The AT-S79 management software default values are listed in Appendix A, ”AT-S79 Software Default Settings” on page 205.
Page 48 6. Type Y to start the reboot process. The switch returns its operating parameters to the default values and begins to reload the AT-S79 management software. This process takes approximately one minute to complete. You can not manage the device during the reboot. After the reboot is finished, you can log in again if you want to continue to manage the device.
Page 49: Chapter 4: Port Configuration
Chapter 4 Port Configuration This chapter contains the procedures for viewing and adjusting the parameter settings for the ports on the switch. This chapter contains the following sections: “Displaying the Port Parameters” on page 50 “Enabling and Disabling a Port” on page 53 “Setting a Port’s Speed and Duplex Mode”...
Page 50: Displaying The Port Parameters
Chapter 4: Port Configuration Displaying the Port Parameters To display the parameter settings for the ports on the switch, perform the following procedure: 1. From the Main Menu, type B to select Basic Switch Configuration. The Basic Switch Configuration Menu is shown in Figure 4 on page 30. 2.
Page 51 AT-S79 Management Software User’s Guide The Port Configuration Menu displays the following columns of information about the status of the ports: Port The port number. Trunk The trunk group number. This column contains the number of the port trunk if the port is a member of a trunk. To configure a trunk, refer to Chapter 5, “Port Trunking”...
Page 52 Chapter 4: Port Configuration 1000-HDx - 1000 Mbps in half-duplex mode To change a port’s speed and duplex mode setting, see “Setting a Port’s Speed and Duplex Mode” on page 54. Flow Ctrl Whether flow control is enabled on the port. Flow control is enabled by default.
Page 53: Enabling And Disabling A Port
AT-S79 Management Software User’s Guide Enabling and Disabling a Port This procedure enables and disables a port. You may want to disable a port and prevent packets from being forwarded if a problem occurs with the node or cable connected to the port. After the problem has been fixed, you can enable the port to resume normal operation.
Page 54: Setting A Port's Speed And Duplex Mode
Chapter 4: Port Configuration Setting a Port’s Speed and Duplex Mode To change a port’s speed or duplex mode, perform the following procedure: 1. From the Main Menu, type B to select Basic Configuration. The Basic Switch Configuration Menu is shown in Figure 4 on page 30 2.
Page 55 AT-S79 Management Software User’s Guide full-duplex. To avoid this problem when connecting an end node with a fixed duplex mode of full-duplex to a switch port, disable Auto-Negotiation on the port and set the port’s speed and duplex mode manually.
Page 56: Changing The Flow Control Setting
Chapter 4: Port Configuration Changing the Flow Control Setting Flow control applies to ports operating in full-duplex mode. A switch port uses flow control to control the flow of ingress packets from its end node. A port using flow control issues a special frame, referred to as a PAUSE frame, as specified in the IEEE 802.3x standard, to stop the transmission of data from an end node.
Page 57: Chapter 5: Port Trunking
Chapter 5 Port Trunking This chapter provides information and procedures for creating a port trunk and contains the following sections: “Port Trunking Overview” on page 58 “Creating a Port Trunk” on page 59 “Modifying a Port Trunk” on page 62 “Enabling and Disabling a Port Trunk”...
Page 58: Port Trunking Overview
Chapter 5: Port Trunking Port Trunking Overview Port trunking is an economical way for you to increase the bandwidth between two Ethernet switches. A port trunk is 2 to 8 ports that have been grouped together to function as one logical path. A port trunk increases the bandwidth between switches and is useful in situations where a single physical data link between switches is insufficient to handle the traffic load.
Page 59: Creating A Port Trunk
AT-S79 Management Software User’s Guide Creating a Port Trunk This procedure explains how to create a port trunk. Caution Do not connect the cables to the ports on the switches until after you have configured the trunk with the management software.
Page 60: Figure 15. Trunk Configuration Menu
Chapter 5: Port Trunking The Trunk Configuration Menu is shown in Figure 15. AT-GS950/24 Local Management System Advanced Switch Configuration -> Trunk Configuration Menu Group Status Port Members Trunk ID ------- -------------- --------------------- ---------- Disabled Disabled Disabled Disabled Disabled Disabled Disabled ----------------------- <COMMAND>...
Page 61 AT-S79 Management Software User’s Guide The following prompt is displayed: Enable or Disable trunk group number (E/D)> 8. Type E to enable the trunk. 9. Type Q to select Quit to previous menu and save your changes. The trunk is now operational on the switch.
Page 62: Modifying A Port Trunk
Chapter 5: Port Trunking Modifying a Port Trunk This procedure adds and removes ports from a port trunk. Note You should disconnect the cables from the ports of the trunk on the switch before modifying it. Adding or removing ports from a trunk without first disconnecting the cables can create loops in your network topology, which can cause broadcast storms and poor network performance.
Page 63: Enabling And Disabling A Port Trunk
AT-S79 Management Software User’s Guide Enabling and Disabling a Port Trunk This procedure enables and disables a port trunk. Note the following before performing this procedure: Do not enable a port trunk until after you have configured the trunk on both switches.
Page 64 Chapter 5: Port Trunking Section I: Using the Menus Interface...
Page 65: Chapter 6: Port Mirroring
Chapter 6 Port Mirroring This chapter contains the procedure for setting up port mirroring. Port mirroring allows you to unobtrusively monitor the ingress and egress traffic on a port by having the traffic copied to another port. This chapter contains the following sections: “Port Mirroring Overview”...
Page 66: Port Mirroring Overview
Chapter 6: Port Mirroring Port Mirroring Overview The port mirroring feature allows you to unobtrusively monitor the ingress and egress traffic on a port on the switch by having the traffic copied to another switch port. By connecting a network analyzer to the port where the traffic is being copied to, you can monitor the traffic on the other port without impacting its performance or speed.
Page 67: Configuring Port Mirroring
AT-S79 Management Software User’s Guide Configuring Port Mirroring To set up port mirroring, perform the following procedure: 1. From the Main Menu, type A to select Advanced Switch Configuration. The Advanced Switch Configuration Menu is shown in Figure 14 on page 59.
Page 68 Chapter 6: Port Mirroring 7. Type E to select Enable/Disable Port Mirroring. The following prompt is displayed: Enable or Disable monitoring (E/D)> 8. Type E to enable port mirroring. You can now connect your data analyzer to the mirroring port. 9.
Page 69: Disabling Port Mirroring
AT-S79 Management Software User’s Guide Disabling Port Mirroring To disable port mirroring, perform the following procedure: 1. From the Main Menu, type A to select Advanced Switch Configuration. The Advanced Switch Configuration Menu is shown in Figure 14 on page 59.
Page 70 Chapter 6: Port Mirroring Section I: Using the Menus Interface...
Page 71: Chapter 7: Virtual Lans
Chapter 7 Virtual LANs This chapter contains the procedures for creating, modifying, and deleting port-based and tagged Virtual Local Area Networks (VLANs). This chapter contains the following sections: “VLAN Features” on page 72 “Port-based VLAN Overview” on page 74 “Tagged VLAN Overview” on page 80 “Creating a VLAN”...
Page 72: Vlan Features
Chapter 7: Virtual LANs VLAN Features A Virtual Local Area Network (VLAN) is a logical grouping of devices on different physical LAN segments that allows users to communicate as if they were physically connected to a single LAN, independent of the physical configuration of the network.
Page 73: Types Of Vlans
AT-S79 Management Software User’s Guide VLANs can be used to control the flow of data in your network, since the traffic generated by an end-node in a VLAN is restricted to the other end- nodes in the same VLAN. In addition, VLANs can prevent data from flowing to unauthorized end-nodes.
Page 74: Port-Based Vlan Overview
Chapter 7: Virtual LANs Port-based VLAN Overview As explained in “VLAN Features” on page 72, a VLAN consists of a group of ports on one or more Ethernet switches that form an independent traffic domain. Traffic generated by the end nodes of a VLAN remains within the VLAN and does not cross over to the end nodes of other VLANs unless there is an interconnection device, such as a router or Layer 3 switch.
Page 75: Untagged Ports
AT-GS950 Series switches, you would assign the Marketing VLAN on each switch the same VID. You can assign this number manually or allow the AT-S79 management software to do it automatically. If you allow the management software to do it automatically, it selects the next available VID.
Page 76: Drawbacks Of Port-Based Vlans
Chapter 7: Virtual LANs Each port must be assigned a PVID. This value must match the VLAN’s VID and it must be the same for all the ports in a port-based VLAN. You must manually configure this value on a port after you assign the port to a VLAN.
Page 77: Port-Based Example 1
AT-S79 Management Software User’s Guide Port-based Figure 17 illustrates an example of one AT-GS950/24 Gigabit Ethernet Switch with three port-based VLANs. (For purposes of the following Example 1 examples, the Default VLAN is not shown.) Engineering VLAN (VID 3) Production VLAN...
Page 78: Port-Based Example 2
Chapter 7: Virtual LANs Each VLAN has one port connected to the router. The router interconnects the various VLANs and functions as a gateway to the WAN. Port-based Figure 18 illustrates more port-based VLANs. In this example, Sales and Engineering VLANs span two AT-GS950/24 Gigabit Ethernet switches, Example 2 while Production VLAN is limited to just one switch.
Page 79 AT-S79 Management Software User’s Guide The table below lists the port assignments for the Sales, Engineering, and Production VLANs on the switches: Sales VLAN Engineering VLAN Production VLAN (VID 2) (VID 3) (VID 4) AT-GS950/24 Ports 1 - 6 Ports 9 - 13...
Page 80: Tagged Vlan Overview
Chapter 7: Virtual LANs Tagged VLAN Overview The second type of VLAN supported by the AT-S79 management software is the tagged VLAN. VLAN membership in a tagged VLAN is determined by information within the frames that are received on a port. This differs from a port-based VLAN, where the PVIDs assigned to the ports determine VLAN membership.
Page 81: Tagged And Untagged Ports
AT-S79 Management Software User’s Guide Note For explanations of VLAN name and VLAN identifier, refer back to “VLAN Name” on page 74 and “VLAN Identifier” on page 74. Tagged and You need to specify which ports will be members of the VLAN. In the case...
Page 82: Tagged Vlan Example
Chapter 7: Virtual LANs Tagged VLAN Figure 19 illustrates how tagged ports can be used to interconnect IEEE 802.1Q-based products. Example Engineering VLAN (VID 3) Sales VLAN (VID 2) Production VLAN (VID 4) Legacy Server 11 13 21 23 AT-GS950/24 Gigabit Ethernet Switch 8 10 12 14 18 20 22 24 IEEE 802.1Q-compliant...
Page 83 AT-S79 Management Software User’s Guide The port assignments for the VLANs are as follows: Engineering VLAN Production VLAN Sales VLAN (VID 2) (VID 3) (VID 4) Untagged Tagged Untagged Tagged Untagged Tagged Ports Ports Ports Ports Ports Ports AT-GS950/ 1, 3, 5, 6...
Page 84: Creating A Vlan
Chapter 7: Virtual LANs Creating a VLAN This section contains the procedure for creating a new port-based or tagged VLAN. This procedure assigns the VLAN a name, a VID number, and the untagged and tagged member ports. After you have performed this procedure, you must configure the untagged ports of the VLAN by adjusting their PVID values to match the virtual LAN’s VID number.
Page 85: Figure 21. Vlan Creation Menu
AT-S79 Management Software User’s Guide 3. From the VLAN Management Menu, type C to select Create VLAN. The VLAN Creation Menu is shown in Figure 21. AT-GS950/16 Local Management System VLAN Management -> VLAN Creation Menu VLAN ID : VLAN Name:...
Page 86 Chapter 7: Virtual LANs The following prompt is displayed: Enter port number > 9. Enter the untagged and tagged ports of the VLAN. You can specify the ports individually separated by commas, for example, 2,7,15, as a range of ports separated by a hyphen, for example, 2-4, or both, for example, 2-7,15,17.
Page 87: Configuring The Pvid Of Untagged Ports
AT-S79 Management Software User’s Guide Configuring the PVID of Untagged Ports This procedure adjusts a port’s VID value. The PVID value determines the VLAN in which the port is an untagged member. A port can be an untagged member of only one VLAN at a time. A port is an untagged member of the VLAN whose VID value matches its PVID.
Page 88 Chapter 7: Virtual LANs Note If you specify a PVID that does not correspond to any VIDs on the switch, the management software creates a new VLAN with a VID that equals the PVID. The VLAN is not assigned any name. 7.
Page 89: Displaying The Vlans
AT-S79 Management Software User’s Guide Displaying the VLANs To display a list of the port-based and tagged VLANs on the switch, perform the following procedure: 1. From the Main Menu, type A to select Advanced Switch Configuration. The Advanced Switch Configuration Menu is shown in Figure 14 on page 59.
Page 90: Figure 22. Config Vlan Member Menu
Chapter 7: Virtual LANs The Config VLAN Member Menu is shown in Figure 22. AT-GS950/16 Local Management System VLAN Management -> Config VLAN Member VLAN ID : 3 VLAN Name: Marketing Port Tagging ---------------------------------------------------------------------- ----------------------- <COMMAND> ------------------------------------ [N]ext Page [C]hange VLAN Name [A]dd VLAN Member [P]revious page [R]emove VLAN Member...
Page 91: Modifying A Vlan
AT-S79 Management Software User’s Guide Modifying a VLAN This procedure allows you to perform the following functions: Change the name of a VLAN. Add or remove tagged ports from a VLAN. Before performing this procedure, note the following: You cannot change the VID of a VLAN.
Page 92 Chapter 7: Virtual LANs b. Type the new name for the VLAN and press Enter. A VLAN name can be up to 32 characters and can include spaces. 6. To add a tagged port to the VLAN, do the following: a.
Page 93: Deleting A Vlan
AT-S79 Management Software User’s Guide Deleting a VLAN To delete a VLAN, perform the following procedure: 1. From the Main Menu, type A to select Advanced Switch Configuration. The Advanced Switch Configuration Menu is shown in Figure 14 on page 59.
Page 94 Chapter 7: Virtual LANs Section I: Using the Menus Interface...
Page 95: Chapter 8: Quality Of Service (Qos)
Chapter 8 Quality of Service (QoS) This chapter contains the procedures for configuring the Quality of Service (QoS) parameters of the switch. This chapter contains the following sections: “QoS Overview” on page 96 “Mapping CoS Priorities to Egress Queues” on page 99 “Configuring CoS”...
Page 96: Qos Overview
The priorities are 0 to 7, with 0 the lowest priority and 7 the highest. When a tagged packet is received on a port on the switch, it is examined by the AT-S79 software for its priority. The switch software uses the priority to determine which egress priority queue the packet should be stored in on the egress port.
Page 97 Note QoS is disabled by default on the switch. You can customize these priority-to-queue assignments using the AT-S79 management software. The procedure for changing the default mappings is found in “Mapping CoS Priorities to Egress Queues” on page 99. Note that because all ports must use the same priority-to-egress queue mappings, these mappings are applied at the switch level.
Page 98 Chapter 8: Quality of Service (QoS) One last thing to note is that CoS does not change the priority level in a tagged packet. The packet leaves the switch with the same priority it had when it entered. This is true even if you change the default priority-to- egress queue mappings.
Page 99: Mapping Cos Priorities To Egress Queues
AT-S79 Management Software User’s Guide Mapping CoS Priorities to Egress Queues This procedure explains how to change the default mappings of CoS priorities to egress priority queues, shown in Table 2 on page 97. This is set at the switch level and applies to all ports. This procedure also enables and disables QoS.
Page 100: Figure 24. Traffic Class Configuration Menu
Chapter 8: Quality of Service (QoS) The Traffic Class Configuration Menu is shown in Figure 24. AT-GS950/16 Local Management System Quality of Service Configuration -> Traffic Class Configuration Menu QoS Status : Disabled Traffic Class Queue ------------- ----- 3 : Highest 0 : Lowest ----------------------- <COMMAND>...
Page 101 AT-S79 Management Software User’s Guide The following prompt is displayed: Enter queue for traffic class > c. Enter the new egress queue number for the traffic class. The range is 0 to 3. 0 is the lowest priority queue and 3 is the highest. You can specify only one egress queue.
Page 102: Configuring Cos
Chapter 8: Quality of Service (QoS) Configuring CoS As explained in “QoS Overview” on page 96, a packet received on a port is placed it into one of four priority queues on the egress port according to the switch’s mapping of 802.1p priority levels to egress priority queues. The default mappings are shown in Table 2 on page 97.
Page 103: Figure 25. Port Priority Configuration Menu
AT-S79 Management Software User’s Guide The Port Priority Configuration Menu is shown in Figure 25. AT-GS950/16 Local Management System Quality of Service Configuration -> Port Priority Configuration Menu QoS Status : Disabled Port Trunk Queue Override ---- ----- ----- --------...
Page 104 Chapter 8: Quality of Service (QoS) 4. To configure a port that is not a member of a trunk, type R to select Set Priority Queue. To configure the ports of a port trunk, type T to select Set Trunk Priority Queue. The following prompt is displayed if you are configuring a port: Set Priority Queue->Enter port number>...
Page 105 AT-S79 Management Software User’s Guide Note The tagged information in a frame is not changed as the frame traverses the switch. A tagged frame leaves a switch with the same priority level that it had when it entered. The default for this parameter is disabled, meaning that the priority level of tagged frames is determined by the priority level specified in the frames themselves.
Page 106 Chapter 8: Quality of Service (QoS) Section I: Using the Menus Interface...
Page 107: Chapter 9: 802.1X Port-Based Network Access Control
Chapter 9 802.1x Port-based Network Access Control This chapter contains information about and the procedure for configuring 802.1x Port-based Network Access Control. It includes the following sections: “802.1x Port-based Network Access Control Overview” on page 108 “Configuring 802.1x Port-based Network Access Control” on page 114 Section I: Using the Menus Interface...
Page 108: Port-Based Network Access Control Overview
Chapter 9: 802.1x Port-based Network Access Control 802.1x Port-based Network Access Control Overview 802.1x Port-based Network Access Control (IEEE 802.1x) is used to control who can send traffic through and receive traffic from a switch port. With this feature, the switch will not allow an end node to send or receive traffic through a port until the user of the node logs on by entering a username and password.
Page 109: Authentication Process
AT-S79 Management Software User’s Guide Authentication Below is a brief overview of the authentication process that occurs between a supplicant, authenticator, and authentication server. For further Process details, refer to the IEEE 802.1x standard. Either the authenticator (that is, a switch port) or the supplicant can initiate an authentication prompt exchange.
Page 110: Figure 26. Example Of The Authenticator Role
Chapter 9: 802.1x Port-based Network Access Control Force-unauthorized - Places the port in the unauthorized state, ignoring all attempts by the client to authenticate. This port control setting blocks all users from accessing the network through the port and is similar to disabling a port and can be used to secure a port from use.
Page 111: General Steps
House Aegis client software have been verified as fully compatible with the AT-S79 management software. 3. You must configure and activate the RADIUS client software in the AT-S79 management software. The default setting for the authentication protocol is disabled. You will need to provide the following information: The IP address of a RADIUS servers.
Page 112 Chapter 9: 802.1x Port-based Network Access Control Allied Telesyn does not support connecting more than one supplicant to an authenticator port on the switch. The switch allows only one supplicant to log on per port. Note Connecting multiple supplicants to a switch port set to the Auto setting does not conform to the IEEE 802.1x standard.
Page 113: Figure 27. Port-Based Authentication Across Multiple Switches
AT-S79 Management Software User’s Guide Ports used to interconnect switches should be set to the port control setting of Force-authorized. This is illustrated in Figure 27. Switch A Port 22: Port 6: 802.1x Port Control 802.1x Port Control Setting: Force-authorized...
Page 114: Configuring 802.1X Port-Based Network Access Control
Chapter 9: 802.1x Port-based Network Access Control Configuring 802.1x Port-based Network Access Control To configure 802.1x port-based network access control, perform the following procedure: 1. From the Main Menu, type A to select Advanced Switch Configuration. The Advanced Switch Configuration Menu is shown in Figure 14 on page 59.
Page 115 AT-S79 Management Software User’s Guide 3. Type P to select Port No. The following prompt is displayed: Enter port number> 4. Enter the number of the port on the switch you want to configure. You can configure only one port at a time.
Page 116 Chapter 9: 802.1x Port-based Network Access Control Supplicant Timeout. Sets the switch-to-client retransmission time for the EAP-request frame. The default value for this parameter is 30 seconds. The range is 1 to 600 seconds. Server Timeout. Sets the timer used by the switch to determine authentication server timeout conditions.
Page 117 AT-S79 Management Software User’s Guide b. Typing Y returns the port to the unauthenticated state and the re- authentication period to zero. The user must enter a valid username and password to continue to use the switch port. Typing N cancels the reauthentication.
Page 118 Chapter 9: 802.1x Port-based Network Access Control Section I: Using the Menus Interface...
Page 119: Chapter 10: Radius Authentication Protocol
Chapter 10 RADIUS Authentication Protocol This chapter describes how to configure the RADIUS client software on the switch. You can use the RADIUS client with 802.1x port-based network access control to control who can forward packets through the switch. Sections in the chapter include: “RADIUS Overview”...
Page 120: Radius Overview
The AT-S79 management software comes with RADIUS client software. You can use the client software together with 802.1x port-based network access control, described in Chapter 9, “802.1x Port-based Network Access Control”...
Page 121: Configuring The Radius Client
AT-S79 Management Software User’s Guide Configuring the RADIUS Client To configure the RADIUS client, perform the following procedure: 1. From the Main Menu, type B to select Basic Switch Configuration. The Basic Switch Configuration Menu is shown in Figure 4 on page 30.
Page 122 Chapter 10: RADIUS Authentication Protocol 7. Enter the encryption key of the RADIUS server. 8. Type R to select Set Response Time. The following prompt is displayed: Enter response time> 9. Enter the amount of time in seconds the switch should wait for a response from the RADIUS server.
Page 123: Displaying The Radius Client Settings
AT-S79 Management Software User’s Guide Displaying the RADIUS Client Settings To display the RADIUS client status and settings, perform the following procedure: 1. From the Main Menu, type B to select Basic Switch Configuration. The Basic Switch Configuration Menu is shown in Figure 4 on page 30.
Page 124 Chapter 10: RADIUS Authentication Protocol Section I: Using the Menus Interface...
Page 125: Chapter 11: Broadcast Storm Control
Chapter 11 Broadcast Storm Control This chapter describes how to configure the broadcast storm control feature on the switch and includes the following sections: “Broadcast Storm Control Overview” on page 126 “Configuring Broadcast Storm Control” on page 127 Section I: Using the Menus Interface...
Page 126: Broadcast Storm Control Overview
Chapter 11: Broadcast Storm Control Broadcast Storm Control Overview The broadcast storm control feature limits the number of broadcast frames forwarded by the switch. The feature can help improve network performance in situations where broadcast frames are consuming a significant portion of network bandwidth, to a degree where the remaining bandwidth is insufficient for efficiently carrying the unicast and multicast frames.
Page 127: Configuring Broadcast Storm Control
AT-S79 Management Software User’s Guide Configuring Broadcast Storm Control To configure the broadcast storm control feature, perform the following procedure: 1. From the Main Menu, type B to select Basic Switch Configuration. The Basic Switch Configuration Menu is shown in Figure 4 on page 30.
Page 128 Chapter 11: Broadcast Storm Control L for Low (100 broadcast packets per second) 7. Type Q to quit to the previous menu and save your changes. Section I: Using the Menus Interface...
Page 129: Chapter 12: Management Software Updates
AT-S79 management software onto the switch. The procedure is: “Downloading a New Management Software Image Using TFTP” on page 130 Note For information on how to obtain new releases of the AT-S79 management software, refer to “Management Software Updates” on page 14. Section I: Using the Menus Interface...
Page 130: Downloading A New Management Software Image Using Tftp
Both models of the AT-GS950 Series use the same AT-S79 management software image. The current configuration of a switch is retained when a new AT-S79 software image is installed. To return a switch to its default configuration values, refer to “Returning the AT-S79 Management Software to the Factory Default Values”...
Page 131: Figure 31. Software Upgrade Menu (1 Of 2)
AT-S79 Management Software User’s Guide The Software Upgrade Menu is shown in Figure 31. AT-GS950/16 Local Management System Switch Tools Configuration -> Software Upgrade Menu [T]FTP Software Upgrade [Q]uit to previous menu Command> Figure 31. Software Upgrade Menu (1 of 2) 3.
Page 132 6. Type F to select Set Image File Name. The following prompt is displayed: Enter file name> 7. Enter the file name of the AT-S79 image file on the TFTP server and press Enter. 8. Type R to select Set Retry Count.
Page 133: Section Ii: Using The Web Browser Interface
Section II Using the Web Browser Interface The chapters in this section provide information and procedures for using the web browser interface in the AT-S79 management software. The chapters include: Chapter 13, “Starting a Web Browser Management Session” on page Chapter 14, “Basic Switch Parameters”...
Page 134 Section II: Using the Web Browser Interface...
Page 135: Chapter 13: Starting A Web Browser Management Session
Chapter 13 Starting a Web Browser Management Session This chapter contains the procedures for starting, using, and quitting a web browser management session on the AT-GS950/16 and AT-GS950/24 Smart Switches. Sections in the chapter include: “Establishing a Remote Connection to Use the Web Browser Interface” on page 136 “Web Browser Tools”...
Page 136: Establishing A Remote Connection To Use The Web Browser Interface
Chapter 13: Starting a Web Browser Management Session Establishing a Remote Connection to Use the Web Browser Interface In order for you to manage an AT-GS950/16 or AT-GS950/24 Smart Switch using the web browser interface, the switch must have an IP address and subnet mask.
Page 137: Figure 34. At-S79 Login Dialog Box
The AT-S79 management software displays the login dialog box, shown in Figure 34. Figure 34. AT-S79 Login Dialog Box 3. Enter the AT-S79 management login user name and password. The default user name and password are both “manager”. The login name and password are case-sensitive.
Page 138 Chapter 13: Starting a Web Browser Management Session The main menu is on the top of the home page. It consists of the following selections: General Info. Basic Config. Advanced Config. Tools Statistics A web browser management session remains active even if you link to other sites.
Page 139: Web Browser Tools
AT-S79 Management Software User’s Guide Web Browser Tools You can use the web browser tools to move around the management pages. Selecting Back on your browser’s toolbar returns you to the previous display. You can also use the browser’s bookmark feature to save the link to the switch.
Page 140: Quitting A Web Browser Management Session
Chapter 13: Starting a Web Browser Management Session Quitting a Web Browser Management Session To exit a web browser management session, close the web browser. Section II: Using the Web Browser Interface...
Page 141: Chapter 14: Basic Switch Parameters
“Setting the User Interface Configuration” on page 147 “Viewing System Information” on page 150 “Rebooting a Switch” on page 153 “Pinging a Remote System” on page 154 “Returning the AT-S79 Management Software to the Factory Default Values” on page 156 Section II: Using the Web Browser Interface...
Page 142: Configuring An Ip Address, Subnet Mask And Gateway Address
Chapter 14: Basic Switch Parameters Configuring an IP Address, Subnet Mask and Gateway Address This procedure explains how to change the IP address, subnet mask, and gateway address to the switch. Before performing the procedure, note the following: An IP address and subnet mask are not required for normal network operations of the switch.
Page 143 AT-S79 Management Software User’s Guide System IP Address Enter the IP address for the switch. System Subnet Mask Enter the subnet mask for the switch. System Default Gateway Enter the default gateway’s IP address. DHCP Mode For information about setting this parameter, refer to “Enabling and Disabling the DHCP Client”...
Page 144: Enabling And Disabling The Dhcp Client
Chapter 14: Basic Switch Parameters Enabling and Disabling the DHCP Client This procedure explains how to activate and deactivate the DHCP client on the switch. When the client is activated, the switch obtains its IP configuration, such as its IP address and subnet mask, from a DHCP server on your network.
Page 145: Configuring System Administration Information
AT-S79 Management Software User’s Guide Configuring System Administration Information This section explains how to assign a name to the switch, as well as the location of the switch and the name of the switch’s administrator. Entering this information is optional.
Page 146: System Contact
Chapter 14: Basic Switch Parameters System Contact Specifies the name of the network administrator responsible for managing the switch. This contact name is optional and may contain up to 50 characters. 3. Click Apply. Section II: Using the Web Browser Interface...
Page 147: Setting The User Interface Configuration
Change the console timer, used to automatically end inactive local management sessions. Change the AT-S79 management login user name and password. Enable and disable the web server, used to manage the switch from a remote management station with a web browser.
Page 148 Disabling the web browser automatically ends your remote management session. b. Click Apply. 4. To change the AT-S79 management login name or password, do the following: a. Enter the existing name and password in the User Name and Password fields. The default name and password are both “manager”.
Page 149 AT-S79 Management Software User’s Guide c. Click the New Password field and enter a new login password or, if you do not want to change the password, enter the current password. The password can be from 0 to 12 characters. Allied Telesyn recommends not using special characters, such as spaces and exclamation points.
Page 150: Viewing System Information
Chapter 14: Basic Switch Parameters Viewing System Information To view general information about the switch, perform the following procedure: 1. From General Info. menu, select Switch Information. The Switch Information page is shown in Figure 39. Figure 39. Switch Information Page The Switch Information page displays the following information: System Up Time The number of days, hours, and minutes that the switch has been...
Page 151 AT-S79 Management Software User’s Guide Hardware Information Section: Reversion The hardware version number. DRAM Size The size of the DRAM, in megabytes. Flash Size The size of the flash memory, in megabytes. Fixed Baud Rate The baud rate of the console port.
Page 152 Chapter 14: Basic Switch Parameters DHCP Mode The status of the DHCP client on the switch. For information about setting this parameter, refer to “Enabling and Disabling the DHCP Client” on page 144. Section II: Using the Web Browser Interface...
Page 153: Rebooting A Switch
Values” on page 156. 3. For the Reboot Status, select Start to start the reboot. 4. Click Apply. The switch immediately begins to reload the AT-S79 management software. This process takes approximately one minute to complete. You can not manage the device during the reboot. After the reboot is finished, you can log in again if you want to continue to manage the device.
Page 154: Pinging A Remote System
Chapter 14: Basic Switch Parameters Pinging a Remote System This procedure instructs the switch to ping a node on your network. This procedure is useful in determining whether an active link exists between the switch and another network device. Note the following before performing the procedure: The switch where you are initiating the ping must have an IP address.
Page 155: Figure 42. Ping Test Results Page
AT-S79 Management Software User’s Guide 4. To view the ping results, click Show Ping Results. A sample Ping Test Results page is shown in Figure 42. Figure 42. Ping Test Results Page 5. Click Back to Ping Test to return to the Ping Test Configuration page.
Page 156: Returning The At-S79 Management Software To The Factory Default Values
This procedure returns all AT-S79 management software parameters to their default values and deletes all tagged and port-based VLANs on the switch. The AT-S79 management software default values are listed in Appendix A, “AT-S79 Software Default Settings” on page 205.
Page 157: Chapter 15: Port Configuration
Chapter 15 Port Configuration The sections in this chapter explain the two methods to viewing and changing the parameter settings of the individual ports on the switch. The first method shows how to use the Port Configuration page to view and configure multiple ports at one time.
Page 158: Viewing And Configuring Ports Using The Port Configuration Page
Chapter 15: Port Configuration Viewing and Configuring Ports Using the Port Configuration Page This procedure explains how to configure the ports on the switch using the Port Configuration page. This page allows you to view and configure the parameter settings of all the switch ports at one time. To configure the ports, perform the following procedure: 1.
Page 159 AT-S79 Management Software User’s Guide Type The port type. The port type is 1000TX for 10/100/1000Base-T twisted pair ports and 1000BaseF for an optional SFP fiber port. Link Status The status of the link between the port and the end node connected to the port.
Page 160 Chapter 15: Port Configuration prevent a duplex mode mismatch. A switch port using Auto- Negotiation defaults to half-duplex if it detects that the end node is not using Auto-Negotiation. This can result in a mismatch if the end node is operating at a fixed duplex mode of full-duplex. To avoid this problem when connecting an end node with a fixed duplex mode of full-duplex to a switch port, disable Auto-Negotiation on the port and set the port’s speed and duplex mode manually.
Page 161: Viewing And Configuring Ports Using The Configuration Of Port Page
AT-S79 Management Software User’s Guide Viewing and Configuring Ports Using the Configuration of Port Page The procedure in this section is used to view or configure the parameter settings of a port on the switch. To view and configure the parameter settings for more than one port at a time, refer to “Viewing and Configuring...
Page 162 Chapter 15: Port Configuration Port Type The port type. The port type is 1000TX for 10/100/1000Base-T twisted pair ports and 1000BaseF for an optional SFP fiber optic port. Trunk ID The trunk group number. A number in this column indicates that the port is a member of a port trunk.
Page 163 AT-S79 Management Software User’s Guide When selecting a setting, note the following: When a twisted pair port is set to Auto-Negotiation, the default setting, the end node should also be using Auto-Negotiation to prevent a duplex mode mismatch. A switch port using Auto- Negotiation defaults to half-duplex if it detects that the end node is not using Auto-Negotiation.
Page 164: Displaying Port Statistics
Chapter 15: Port Configuration Displaying Port Statistics To display port statistics, perform the following procedure: 1. Select Statistics. The Statistics page opens as shown in Figure 45. Figure 45. Statistics Page 2. To view statistics for a port, select a port from the Select Port pull- down menu and click Apply.
Page 165 AT-S79 Management Software User’s Guide Good Broadcast Number of valid broadcast packets received on the port. Good Multicast Number of valid multicast packets received on the port. CRC/Align Errors Number of packets with a cyclic redundancy check (CRC) error but with the proper length (64-1518 bytes) received on the port.
Page 166 Chapter 15: Port Configuration Section II: Using the Web Browser Interface...
Page 167: Chapter 16: Port Trunking
Chapter 16 Port Trunking This chapter contains the following procedures for working with port trunking: “Creating a Port Trunk” on page 168 “Modifying a Port Trunk” on page 170 “Enabling and Disabling a Port Trunk” on page 171 Note For background information, refer to “Port Trunking Overview” on page 58.
Page 168: Creating A Port Trunk
Chapter 16: Port Trunking Creating a Port Trunk This procedure explains how to create a port trunk. Note Do not connect the cables of a port trunk to the ports on the switch until after you have configured the ports on both the switch and the end node.
Page 169 AT-S79 Management Software User’s Guide 2. In any one of the unused Trunk ID rows, click the dialog boxes of the ports that will make up the port trunk. A check in a box indicates the port is a member of the trunk. No check means the port is not a member.
Page 170: Modifying A Port Trunk
Chapter 16: Port Trunking Modifying a Port Trunk This procedure adds and removes ports from a port trunk. Note You should disconnect the cables from the ports of the trunk on the switch before modifying it. Adding or removing ports from a trunk without first disconnecting the cables can create loops in your network topology, which can cause broadcast storms and poor network performance.
Page 171: Enabling And Disabling A Port Trunk
AT-S79 Management Software User’s Guide Enabling and Disabling a Port Trunk This procedure enables and disables a port trunk. Note the following before performing this procedure: Do not enable a port trunk until after you have configured the trunk on both switches.
Page 172 Chapter 16: Port Trunking Section II: Using the Web Browser Interface...
Page 173: Chapter 17: Port Mirroring
Chapter 17 Port Mirroring This chapter contains the procedure for setting up port mirroring. Port mirroring allows you to unobtrusively monitor the ingress and egress traffic on a port by having the traffic copied to another port. This chapter contains the following sections: “Configuring Port Mirroring”...
Page 174: Configuring Port Mirroring
Chapter 17: Port Mirroring Configuring Port Mirroring To set up port mirroring, perform the following procedure: 1. From the Advanced Config menu, select Port Mirroring. The Port Mirroring page is shown in Figure 47. Figure 47. Port Mirroring Page 2. In the Mirroring Port section, click Port and from the pull-down menu select the port where the network analyzer is connected.
Page 175: Disabling Port Mirroring
AT-S79 Management Software User’s Guide Disabling Port Mirroring To disable port mirroring, perform the following procedure: 1. From the Advanced Config menu, select Port Mirroring. The Port Mirroring page is shown in Figure 47 on page 174. 2. From the Mirroring Status list, select Disable and click Apply.
Page 176 Chapter 17: Port Mirroring Section II: Using the Web Browser Interface...
Page 177: Chapter 18: Virtual Lans
Chapter 18 Virtual LANs This chapter contains the procedures for creating, modifying, and deleting port-based and tagged Virtual Local Area Networks (VLANs) from a web browser management session. This chapter contains the following sections: “Creating a VLAN” on page 178 “Configuring the PVID of Untagged Ports”...
Page 178: Creating A Vlan
Chapter 18: Virtual LANs Creating a VLAN This section contains the procedure for creating a new port-based or tagged VLAN. This procedure assigns the VLAN a name, a VID number, and the untagged and tagged member ports. After performing this procedure, the PVID values of the untagged ports of the VLAN must be adjusted to match the virtual LAN’s VID number.
Page 179 AT-S79 Management Software User’s Guide If the VLAN will be unique in you network, then the name should be unique as well. If the VLAN will be part of a larger VLAN that spans multiple switches, then the name for the VLAN should be the same on each switch where nodes of the VLAN are connected.
Page 180: Configuring The Pvid Of Untagged Ports
Chapter 18: Virtual LANs Configuring the PVID of Untagged Ports This procedure adjusts a port’s VID value. The PVID value determines the VLAN in which the port is an untagged member. A port is an untagged member of the VLAN whose VID value matches its PVID. A port can be an untagged member of only one VLAN at a time.
Page 181 AT-S79 Management Software User’s Guide 2. Click the PVID field of the port whose value you want to change and enter the new PVID value for the port. The PVID must be equal to the VID of the VLAN where you want the port to be an untagged member.
Page 182: Displaying The Vlans
Chapter 18: Virtual LANs Displaying the VLANs To display the VLANs, perform the following procedure: 1. From the Advanced Config menu, select VLAN Config and then VLAN Port Config. The VLAN Information page is shown in Figure 51 on page 183 and provides the following columns of information: VLAN ID The VLAN ID number.
Page 183: Modifying A Vlan
AT-S79 Management Software User’s Guide Modifying a VLAN This procedure allows you to perform the following functions: Change the name of a VLAN. Add or remove tagged ports from a VLAN. Before performing this procedure, note the following: You cannot change the VID of an existing VLAN.
Page 184: Figure 52. Modify Vlan Page
Chapter 18: Virtual LANs The Modify VLAN page is shown in Figure 52. Figure 52. Modify VLAN Page 3. To change the VLAN’s name, click the VLAN Name field and enter the new name. The name can contain up to 32 characters including spaces but not including special characters such as asterisks (*) or exclamation points (!).
Page 185: Deleting A Vlan
AT-S79 Management Software User’s Guide Deleting a VLAN To delete a VLAN, perform the following procedure: 1. From the Advanced Config menu, select VLAN Info. The VLAN Information page is shown in Figure 51 on page 183. 2. In the VLAN Action column, click Delete next to the VLAN you want to delete.
Page 186 Chapter 18: Virtual LANs Section II: Using the Web Browser Interface...
Page 187: Chapter 19: Quality Of Service (Qos)
Chapter 19 Quality of Service (QoS) This chapter contains the procedure for configuring Quality of Service (QoS). This chapter includes the following procedures: “Mapping CoS Priorities to Egress Queues” on page 188 “Configuring CoS” on page 190 Note For background information, refer to “QoS Overview” on page 96 Section II: Using the Web Browser Interface...
Page 188: Mapping Cos Priorities To Egress Queues
Chapter 19: Quality of Service (QoS) Mapping CoS Priorities to Egress Queues This procedure explains how to change the default mappings of CoS priorities to egress priority queues, as shown in Table 2 on page 97. This is set at the switch level. You cannot set this at the per-port level. This procedure also enables and disables QoS.
Page 189 AT-S79 Management Software User’s Guide Note The switch does not alter the original priority level in tagged frames. Frames leave the switch with the same priority level they had when they entered the switch. Section II: Using the Web Browser Interface...
Page 190: Configuring Cos
Chapter 19: Quality of Service (QoS) Configuring CoS As explained in “QoS Overview” on page 96, a packet received on a port is placed it into one of four priority queues on the egress port according to the switch’s mapping of 802.1p priority levels to egress priority queues. The default mappings are shown in Table 2 on page 97.
Page 191 AT-S79 Management Software User’s Guide The columns in the menu display the following information: Port Displays the port number. Trunk Displays the trunk number if the port is a member of a trunk. QoS Priority Displays the number of the queue where untagged packets received on the port are stored on the egress queue.
Page 192 Chapter 19: Quality of Service (QoS) Section II: Using the Web Browser Interface...
Page 193: Chapter 20: 802.1X Port-Based Network Access Control
Chapter 20 802.1x Port-based Network Access Control This chapter contains the procedure for configuring 802.1x port-based network access control: “Configuring 802.1x Port-based Network Access Control” on page 194 Note For background information, refer to “802.1x Port-based Network Access Control Overview” on page 108. Section II: Using the Web Browser Interface...
Page 194: Configuring 802.1X Port-Based Network Access Control
Chapter 20: 802.1x Port-based Network Access Control Configuring 802.1x Port-based Network Access Control To configure 802.1x port-based network access control, perform the following procedure: 1. From the Advanced Config menu, select 802.1x. The 802.1x Configuration page is shown in Figure 55. Figure 55.
Page 195 AT-S79 Management Software User’s Guide 3. Configure the following parameters as needed. The parameters are defined here: NAS ID. This parameter assigns an 802.1x identifier to the switch that applies to all ports. The NAS ID can be up to sixteen characters. Valid characters are 0 to 9, a to z, and A to Z.
Page 196 Chapter 20: 802.1x Port-based Network Access Control timeout conditions. The default value for this parameter is 10 seconds. The range is 1 to 60 seconds. Maximum Request. Sets the maximum number of times that the switch retransmits an EAP Request packet to the client before it times out the authentication session.
Page 197: Chapter 21: Radius Authentication Protocol
Chapter 21 RADIUS Authentication Protocol This chapter explains how to configure the RADIUS client on the switch. You can use the RADIUS client with 802.1x port-based network access control to control who can forward packets through the switch. The chapter contains the following section: “Configuring the RADIUS Client”...
Page 198: Configuring The Radius Client
Chapter 21: RADIUS Authentication Protocol Configuring the RADIUS Client To configure the RADIUS client, perform the following procedure: 1. From the Basic Config menu, select RADIUS Config. The RADIUS Server Configuration Menu is shown in Figure 56. Figure 56. RADIUS Configuration Menu 2.
Page 199: Chapter 22: Broadcast Storm Control
Chapter 22 Broadcast Storm Control This chapter contains the procedure for configuring the broadcast storm control feature on the switch. The procedure is: “Configuring Broadcast Storm Control” on page 200 Note For background information, refer to “Broadcast Storm Control Overview” on page 126. Section II: Using the Web Browser Interface...
Page 200: Configuring Broadcast Storm Control
Chapter 22: Broadcast Storm Control Configuring Broadcast Storm Control To configure the broadcast storm control feature, perform the following procedure: 1. From the Basic menu, select Storm Control. The Broadcast Storm Control page is shown in Figure 57. Figure 57. Broadcast Storm Control Page 2.
Page 201: Chapter 23: Management Software Updates
“Downloading a New Management Software Image Using TFTP” on page 202 Note For information on how to obtain new releases of the AT-S79 management software, refer to “Management Software Updates” on page 14. Section II: Using the Web Browser Interface...
Page 202: Downloading A New Management Software Image Using Tftp
Both models of the AT-GS950 Series use the same AT-S79 software image. The current configuration of a switch is retained when a new AT-S79 software image is installed. To return a switch to its default configuration values, refer to “Returning the AT-S79 Management Software to the Factory Default Values”...
Page 203: Figure 58. Ip Configuration Page
The IP address of the TFTP server from which you are downloading the new software. Download File Name The name of the AT-S79 file you are downloading. 3. Click Apply. The software immediately begins to download onto the switch. This process takes a few minutes.
Page 204 Chapter 23: Management Software Updates Section II: Using the Web Browser Interface...
Page 205: Appendix A: At-S79 Software Default Settings
Appendix A AT-S79 Software Default Settings Table 3 lists the factory default settings for the management software. AT-S79 Default Settings Table 3 Parameter Default Setting IP Configuration IP Address 0.0.0.0 Subnet Mask 0.0.0.0 Default Gateway Address 0.0.0.0 DHCP Client Disabled...
Page 206 Appendix A: AT-S79 Software Default Settings AT-S79 Default Settings Table 3 Parameter Default Setting Speed Auto-Negotiation Duplex Mode Auto-Negotiation Flow Control (Full-duplex Mode) Enabled Backpressure (Half-duplex Mode) Enabled (not adjustable) Port Mirroring Status Disabled VLAN Name Default VLAN Ports All Ports (Untagged)
Page 207 AT-S79 Management Software User’s Guide AT-S79 Default Settings Table 3 Parameter Default Setting Response Time 10 seconds Maximum Retransmissions Broadcast Storm Control Status Disabled Threshold Upgrade Configuration TFTP Server IP Address 0.0.0.0 Image Filename (blank) Retry Count...
Page 208 Appendix A: AT-S79 Software Default Settings...
Page 209: Index
108 login name, configuring 36 guidelines 111 login password, configuring 36 supplicant, described 108 management access level 19 AT-S79 management software manager access, defined 19 features 16 menus interface, using 26 resetting to factory defaults 47 mirrored port, defined 66...
Page 210 Index starting 136 web browser tools 139 Quality of Service (QoS) web server, configuring 36 configuring 99 RADIUS configuring 121 displaying settings 123 guidelines 120 overview 120 rebooting the switch 42 remote management session explained 18 quitting 140 starting 136 SNMP application program 18 software information 39 subnet mask, configuring 30...

This manual is also suitable for:

At-s79 1.0.0

Allied Telesis AT-S79 User Manual

Preface

Chapter 1: Overview

Section I: Using the Menus Interface

Chapter 2: Getting Started with the Menus Interface

Chapter 3: Basic Switch Parameters

Chapter 4: Port Configuration

Chapter 5: Port Trunking

Chapter 6: Port Mirroring

Chapter 7: Virtual Lans

Chapter 8: Quality of Service (Qos)

Chapter 9: 802.1X Port-Based Network Access Control

Chapter 10: RADIUS Authentication Protocol

Chapter 11: Broadcast Storm Control

Chapter 12: Management Software Updates

Section II: Using the Web Browser Interface

Chapter 13: Starting a Web Browser Management Session

Chapter 14: Basic Switch Parameters

Chapter 15: Port Configuration

Chapter 16: Port Trunking

Chapter 17: Port Mirroring

Chapter 18: Virtual Lans

Chapter 19: Quality of Service (Qos)

Chapter 20: 802.1X Port-Based Network Access Control

Chapter 21: RADIUS Authentication Protocol

Chapter 22: Broadcast Storm Control

Chapter 23: Management Software Updates

Appendix A: AT-S79 Software Default Settings

Index

Quick Links

Need help?

Questions and answers

Related Manuals for Allied Telesis AT-S79

Summary of Contents for Allied Telesis AT-S79
