- Page 1 Powered by Accton EC3802-WDM Media Converter Installation Guide www.edge-core.com...
- Page 3 Installation Guide FTTH Media Converter - EC3802-WDM with One Fixed 100BASE-BX Single-Fiber Line Connection, and One 10BASE-T / 100BASE-TX (RJ-45) Port...
- Page 4 EC3802-WDM E012008/ST-R01 150200065000A...
- Page 5 Compliances and Safety Warnings FCC - Class B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 6 CE Mark Declaration of Conformance for EMI and Safety (EEC) This information technology equipment complies with the requirements of the Council Directive 89/336/EEC on the Approximation of the laws of the Member States relating to Electromagnetic Compatibility and 73/23/EEC for electrical equipment used within certain voltage limits and the Amendment Directive 93/68/EEC.
-
Page 7: Safety Compliance
Safety Compliance Warning: Fiber Optic Port Safety When using a fiber optic port, never look at the transmit laser while it is powered on. Also, never look directly at the fiber TX port and fiber cable ends when they are powered on. Avertissment: Ports pour fibres optiques - sécurité... -
Page 8: About This Guide
About This Guide Purpose This guide details the hardware features of this device, including the physical and performance-related characteristics, and how to install it. Audience The guide is intended for use by network administrators who are responsible for installing and setting up network equipment; consequently, it assumes a basic working knowledge of LANs (Local Area Networks). -
Page 9: Table Of Contents
Contents Introduction Key Features Description of Hardware Fiber Cable Connection UTP Port Power Connector External DIP Switch Settings LED Indicators Installing the FTTH CPE Package Contents System Requirements Mounting the CPE Desktop Mounting Wall Mounting Connecting to the CPE Making a Connection to the UTP Port Powering On the CPE Configuring the TCP/IP Protocol Windows 95/98/NT... - Page 10 Contents...
-
Page 11: Introduction
Introduction Fiber-To-The-Home (FTTH) has always been an attractive option for Internet access. It has all the benefits of optical fiber. It provides a future-proof network, in that you do not have to go through the hassles of upgrading from ADSL to xDSL, or digital co-ax to digital wireless. -
Page 12: Key Features
Introduction Key Features • High-speed Internet access • Optical fiber port supports transmission distances up to 15 km (9.32 miles) • Built-in transparent bridging between different media segments • Supports 1K MAC addresses forwards packets only if necessary — • Always-on fast optical fiber connection eliminates dial-up delays, providing transparent Internet access •... -
Page 13: Description Of Hardware
Description of Hardware Description of Hardware The EC3802-WDM is an FTTH CPE product for high-speed Internet access applications. This CPE includes an embedded fiber cable connection, an RJ-45 Ethernet LAN port, PoE on the LAN port, a DIP-switch for LAN port settings, LED status indicators, and an AC power adapter connection. -
Page 14: Utp Port
Description of Hardware UTP Port The RJ-45 Ethernet port labeled “UTP” operates at 10 or 100 Mbps, and supports auto-negotiation of speed, duplex mode (i.e., half or full duplex), flow control, and MDI/X pinout selection. Automatic configuration of MDI or MDI-X pinout operation, allows you to use straight-through cable for all connections. -
Page 15: External Dip Switch Settings
Description of Hardware External DIP Switch Settings The CPE has a four-bit DIP switch located on its rear panel next to the UTP port (see figure below). The DIP switch allows you to enable/disable auto-negotiation for the UTP port and manually force the speed and duplex mode setting. Also, there is one switch for enabling link down notification for the fiber connection. -
Page 16: Led Indicators
Description of Hardware LED Indicators The CPE includes seven LED status indicators on the top panel. The LEDs are detailed in the following figure and table. Description ON: Power is on. OFF: Power is off. ON: Fiber link is up. OFF: Fiber link down. -
Page 17: Installing The Ftth Cpe
Installing the FTTH CPE Installing the FTTH CPE Before installing the CPE, verify that you have all the items listed under “Package Contents.” If any of the items are missing or damaged, contact your service provider. Also, be sure you have all the necessary tools and cabling before installing the CPE. Package Contents The package includes the following items: •... -
Page 18: Mounting The Cpe
Installing the FTTH CPE Mounting the CPE Caution: The EC3802-WDM CPE is for indoor mounting only. Do not mount the unit on the outside of a building. The CPE includes rubber feet for desktop mounting. Horizontal mounting using Wall mounting using the rubber feet wall-mounting slots Desktop Mounting... -
Page 19: Desktop Mounting
Installing the FTTH CPE Desktop Mounting The CPE can be mounted horizontally on any flat surface, such as a desktop or shelf. For horizontal mounting, simply stick the self-adhesive rubber foot pads (that come with this package) on each of the four concave spaces located on the bottom of the CPE. -
Page 20: Connecting To The Cpe
Installing the FTTH CPE Connecting to the CPE Caution: The CPE fiber line should be connected to the unit by a qualified technician only. Do not attempt to remove the fiber cable from the CPE. If there are any problems with the fiber cable connection, contact your service provider. You can connect any computer with an Ethernet network interface card, a LAN switch, hub, or other network device to the CPE’s UTP port. -
Page 21: Powering On The Cpe
Installing the FTTH CPE Notes: 1. Make sure each twisted-pair cable does not exceed 100 meters (328 feet). 2. We advise using Category 5 cable for all network connections to avoid any confusion or inconvenience in the future when you upgrade devices to Fast Ethernet. -
Page 22: Windows Xp
Installing the FTTH CPE Windows XP 1. Select Start/Settings/Control Panel. 2. Click on the Network and Internet Connections icon. 3. Double click “LAN or High-Speed Internet.” 4. Click on “Properties.” 5. Double click “Internet Protocol (TCP/IP).” 6. Select the option “Obtain an IP Address automatically.” Mac OS Systems 1. -
Page 23: Product Specifications
Product Specifications Product Specifications Standards Conformance IEEE 802.3-2005 Ethernet, Fast Ethernet, Full-duplex flow control Fiber Specifications Fiber Cable ITU-T G.985 single-fiber single-mode (WDM) Connector SC and splice (internal) Wavelengths 1310 nm transmit, 1550 nm receive Data Rate 100 Mbps full duplex Transmit Power -14 to -8 dBm Receive Power... -
Page 24: Troubleshooting
Troubleshooting Troubleshooting Diagnosing CPE Indicators The FTTH CPE can be easily monitored through panel indicators to identify problems. The table below describes common problems you may encounter and possible solutions. Symptom Cause Solution PWR indicator does Power outlet, or external •... -
Page 25: Upgrading Firmware
Upgrading Firmware Upgrading Firmware You can upgrade new CPE software from a local file on a PC attached to the LAN port. New software may be provided periodically from your distributor. The IP address for the CPE’s web interface is 192.168.252.1. Before upgrading new software, verify that your PC is configured with an IP address within the same network subnet (that is, 192.168.252.x). -
Page 26: Port And Cable Assignments
Port and Cable Assignments 5. Click Apply to start the download process. After the download process is completed, the following message will be displayed. Upgrade Successful, Rebooting ... Please wait a minium of 30 seconds while the system restarts. 6. After the system restarts, the Default Page is displayed. Click System, and then click Firmware Upgrade to verify that the new firmware is now loaded in the CPE. -
Page 27: Straight-Through Wiring
Port and Cable Assignments Straight-Through Wiring If the twisted-pair cable is to join two ports and only one of the ports has an internal crossover (MDI-X), the two pairs of wires must be straight-through. (The CPE RJ-45 port auto-negotiates MDI or MDI-X pinout selection, allowing you to use either straight-thorough or crossover cable when connecting to another network device.) EIA/TIA 568B RJ-45 Wiring Standard 10/100BASE-TX Straight-through Cable... - Page 28 Port and Cable Assignments...
- Page 30 EC3802-WDM E012008/ST-R01 150200065000A...
