Table 3 Installed components
Installation configuration
Windows management server
Windows non-management server
Linux non-management server

EZPilot installation prerequisites

Before installing the EZPilot software, be sure to:
• Record the switch IP address, gateway, and subnet mask.
You will use this information during installation.
• Uninitialize the storage system.
If it has been initialized, you must uninitialize it before installing EZPilot.
• Verify that the switch configuration (including the default password) has not been changed
from the factory default.
• Remove any Emulex or Brocade software installed on the server.
• Remove any MPIO software installed on the server.

System configuration recommendations

• The HP EVA4000 SAN Starter Kit provides a specific configuration for implementing a SAN
using an EVA4000 storage system. This configuration provides a simple SAN solution for
Windows. The EZPilot management software supports a broader range of configurations. Not
all configuration options discussed in the Emulex EZPilot User Manual apply to the HP EVA4000
SAN Starter Kit.
• If you require uninterrupted access to your data, add a second HP StorageWorks SAN Switch
4/8 base to create a high-availability SAN configuration. This dual fabric ensures that a switch
failure, EVA controller failure, or HBA failure will not interrupt EVA access. Contact HP for
information about ordering a second switch.
• Adding a second disk enclosure helps to create a high-availability SAN by providing protection
against disk enclosure failure. Contact HP for information about ordering additional disk
enclosures.
• To protect against power loss, HP recommends that you use uninterruptible power supplies
(UPS) with the EVA4000. For information about UPS products offered by HP, see the HP
Rack-mountable UPS website:
http://h18004.www1.hp.com/products/servers/proliantstorage/power-protection/rackups/
index.html

Installed components

• Emulex Windows Storport driver
• EZPilot Manager
• Sun Java JRE 1.5
• Brocade WebToolsEZ
• HP Command View EVA 6.0.2
• HP EVA VDS provider
• HP MPIO software
• Emulex Windows Storport driver (Server 2003)
• HBAnyware 3.0
• HP MPIO software
• MultiPulse 2.1 (which includes Emulex Linux 8.0.16.21
driver), Emulex 2.1.6 MultiPulse driver module, HBAnyware
2.1a35 (multipathing driver for Red Hat Enterprise Linux 4
and SUSE Linux Enterprise Server 9)
• Emulex Linux 8.0.16.21 driver with HBAnyware 2.1a35
(standard driver for Red Hat Enterprise Linux 4 and SUSE
Linux Enterprise Server 9)
HP StorageWorks EVA4000 SAN Starter Kit release notes
