Intel Desktop Board D945GPM Product Guide
Table 2.

Desktop Boards D945GPM Components

Label Description
A Front panel audio header
B PCI bus add-in card connectors
C PCI Express x16 connector
D 12 V processor core voltage connector (2x2)
E Rear fan (3-pin, fan speed control)
F Processor socket
G Processor fan header (4-pin, fan speed control)
H Main power connector (2x12)
I Diskette drive connector
J IDE connector
K Front chassis fan header (fan speed control)
L BIOS configuration jumper
M Serial ATA connectors (four)
N Alternate power LED header
O Front panel header
P Hi-speed USB 2.0 header
Q Chassis intrusion header
R Hi-speed USB 2.0 header
S IEEE 1394 headers (two)
T PCI Express x1 connector
Related Links:
Go to the following links for more information about:
•
Desktop board D945GPM
•
Supported processors
•
Audio software and utilities
•
LAN software and drivers
12
http://www.intel.com/design/motherbd
http://support.intel.com/support/motherboards/desktop
http://support.intel.com/support/motherboards/desktop
http://www.intel.com/design/motherbd
http://www.intel.com/design/motherbd
