Rear panel audio ports function variation

The functions of the Line Out (lime), Line In (blue), and Mic (pink) ports on
the rear panel change when you select the 4-channel or 6-channel audio
configuration as shown in the following table.
Light Blue
Lime
Pink
ASUS SK8V motherboard
Headphone/
2-channel 4-channel
Line In Rear Speaker Out
Line Out Front Speaker Out
Mic In Mic In
6-channel
Rear Speaker Out
Front Speaker Out
Bass/Center
5-15
