VCCSA Voltage [Auto]
Allows you to set the VCCSA voltage. The values range from 0.80V to 1.70V with a 0.00625V
interval.
VCCIO Voltage [Auto]
Allows you to set the VCCIO voltage. The values range from 0.80V to 1.70V with a 0.00625V
interval.
CPU PLL Voltage [Auto]
Allows you to set the CPU and PCH PLL voltage. The values range from 1.20V to 2.20V with
a 0.00625V interval.
PCH Voltage [Auto]
Allows you to set the Platform Controller Hub volage. The values range from 0.80V to 1.70V
with a 0.01V interval.
•
•
CPU Manual Voltage
CPU Offset Voltage
DRAM Voltage
VCCSA Voltage
VCCIO Voltage
CPU PLL Voltage
PCH Voltage
CPU Spread Spectrum [Auto]
[Auto]
[Disabled]
[Enabled]
3-12
The values of the CPU Manual Voltage, CPU Offset Voltage, DRAM Voltage, VCCSA
Voltage, VCCIO Voltage, 1.8FSR Voltage, and PCH Voltage items are labeled in
different color, indicating the risk levels of high voltage settings.
The system may need better cooling system to work stably under high voltage settings.
Black
0.8V–1.22V
0.005V–0.060V
1.20000V–
1.57500V
0.80000V–
0.96875V
0.80000V–
1.10000V
1.20000V–
1.88750V
0.80000V–
1.10000V
Automatic configuration.
Enhances the BCLK overclocking ability.
Sets to [Enabled] for EMI control.
Yellow
Pink
1.225V–1.280V
1.285V–1.335V
0.065V–0.120V
0.125V–0.175V
1.58125V–
1.65625V–
1.65000V
1.72500V
0.97500V–
1.01875V–
1.01250V
1.06250V
1.10625V–
1.15625V–
1.15000V
1.20625V
1.89375V–
1.98125V–
1.97500V
2.06875V
1.11000V–
1.16000V–
1.15000V
1.20000V
Red
1.340V–1.990V
0.180V–0.635V
1.73125V–
2.20000V
1.06875V–
1.70000V
1.21250V–
1.70000V
2.07500V–
2.20000V
1.21000V–
1.70000V
Chapter 3: BIOS setup
