CPU Power Management

The sub-items in this menu allow you to set the CPU ratio and features.
CPU Ratio [Auto]
Allows you to manually adjust the maximum non-turbo CPU ratio. Use <+> and <-> keys to
adjust the value. The valid value ranges vary according to your CPU model.
Enhanced Intel SpeedStep Technology [Enabled]
Allows you to enable or disable the Enhanced Intel
[Disabled] Disables this function.
[Enabled] The operating system dynamically adjusts the processor voltage and
core frequency which may result in decreased average consumption and
decreased average heat production.
Turbo Mode [Enabled]
This item appears only when you set the EIST item to [Enabled].
[Enabled] Allows processor cores to run faster than marked frequency in specific
condition.
[Disabled] Disables this function.
The following five items appear only when you set the EIST and Turbo Mode items to
[Enabled].
Turbo Ratio [Auto]
Allows you to manually adjust the Trubo CPU ratio.
[Auto]
[By ALL Cores (Can Adjust in OS)]
[By Per Core (Cannot Adjust in OS)]
Maximum Turbo Ratio setting in OS [Auto]
This item appears only when you set the Turbo Ratio item to [By ALL Cores (Can
Adjust in OS)]. Use the <+> and <-> keys to adjust the value.
1-/2-/3-/4-Core Ratio Limit
This item appears only when you set the Turbo Ratio item to [By Per Core (Cannot
Adjust in OS)]. Use the <+> and <-> keys to adjust the value.
Long Duration Power Limit [Auto]
Use the <+> and <-> keys to adjust the value.
Long Duration Maintained [Auto]
Use the <+> and <-> keys to adjust the value.
Short Duration Power Limit [Auto]
Use the <+> and <-> keys to adjust the value.
Additional Turbo Voltage [Auto]
Use the <+> and <-> keys to adjust the value.
ASUS P8P67 PRO REV 3.1
SpeedStep Technology (EIST).
®
All Turbo ratio are set by Intel CPU default
settings
All numbers of active cores will be set to one
single Turbo ratio in OS
All numbers of active cores can be set to an
individual Turbo ratio in BIOS.
3-9
