Asus P8P67 PRO User Manual page 111

Using Advanced Mode
Click More Settings, and then click the Advanced Mode tab to adjust the advanced voltage
settings.
Advanced mode
Target values
Current values
Click to restore
all start-up
settings
CPU Ratio
Allows you to manually adjust the CPU ratio.
The first time you use CPU Ratio, go to AI Tweaker > CPU Power Management in BIOS
and set the Turbo Ratio item to [Maximum Turbo Ratio setting in OS], or activate CPU
Ratio by clicking the ON button on the CPU Ratio function screen.
1. Click More Settings, and then click the CPU Ratio tab.
2. Click the ON button to activate CPU Ratio.
You will requested to restart the system. Click Yes to make the change take effect.
3.
CPU Ratio
Click to restore
all start-up
settings
ASUS P8P67 PRO REV 3.1
Voltage
Adjustment
bars
Undoes all changes
without applying
Applies all changes
immediately
Click to activate the
CPU Ratio
Applies all changes
immediately
Undoes all changes
without applying
4-7
