AT60J / AT61J
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AT60J and is the answer not in the manual?

Questions and answers

Related Manuals for AudioBahn AT60J

Summary of Contents for AudioBahn AT60J

  • Page 1 AT60J / AT61J OWNER’S MANUAL...
  • Page 2 Judge for yourself, and remember what it’s all about, “If it’s not Bigger, Bad- der & Better, it’s not Audiobahn.” If audio is your life, Audiobahn is the brand for you! We make you look as good as you sound. People never stop trying to get the best...

  • Page 3: Table Of Contents

    Other infor- mation can be located by using the table of contents. We at Audiobahn have worked very hard to make sure that all information in this manual is current, but, as we are con- stantly finding new ways to improve our product, this information is subject to change without notice.

  • Page 4: Introduction

    Dear Customer, Congratulations on your purchase of the worlds finest brand of car audio products. Here at Audiobahn Inc. we are devoted to making our musical reproduction the vert best, and we are pleased you have chosen our product. Through years of engineering expertise, hand craftsmanship, and critical testing procedures, we have created a wide range of products that reproduce music with all the clarity and richness you deserve.

  • Page 5: Specifications

    SPECIFICATIONS AT60J BLACK STEEL CASE FERRO FLUID COOLED, HIGH-FLUX NEODYMIUM MAGNET FLUSH, SURFACE AND FLEX MOUNT HARDWARE 12dB CROSSOVER WITH AUDIOPHILE GRADE CAPACITORS AND POLYSWITCH PROTECTION 4 OHM IMPEDANCE FREQUENCY RESPONSE: 2kHz - 22kHz POWER HANDLING 100 WATTS RMS PER PAIR SENSITIVITY 90dB 1W / 1M AT61J BLACK STEEL CASE FERRO FLUID COOLED, HIGH-FLUX NEODYMIUM MAGNET FLUSH AND ANGLE SURFACE MOUNT HARDWARE 12dB CROSSOVER WITH AUDIOPHILE GRADE CAPACITORS AND POLYSWITCH PROTECTION 4 OHM IMPEDANCE FREQUENCY RESPONSE: 2.5kHz - 25kHz POWER HANDLING 100 WATTS RMS PER PAIR SENSITIVITY 90dB 1W / 1M...

  • Page 6: Wiring

    Wiring Audiobahn recommends using at least 18-gauge wire with your new speaker system. Thinner gauge wire may easily be severed and can cause damage to your system should any bare wires come in contact with the vehicles chassis. Makes sure that your audio system is off while installing and connecting your new Au- diobahn Speakers.
  • Page 7 Installation (AT60J MODEL ONLY) A T 6 0 4 O H M S...

  • Page 8: Installation

    Installation Angled Surface Mount This will allow you to mount your tweeter on the surface and give you the ability to have the tweeter facing in almost any direction that you desire. 1. You will need to remove the center part of the double sided sticky tape 2. Remove one side of the protective backing of the tape and place it on the back of the angled mounting piece 3.
  • Page 9 Installation The crossover will allow the tweeter to play the Wiring the tweeter to the crossover correct frequencies without sending harmful low frequencies to the tweeter. 1. Make sure that you match the solid blue wire with the solid blue wire (Positive) 2.

  • Page 10: Troubleshooting

    Troubleshooting In the event that your Audiobahn speakers appear to require service we ask that you first do a little troubleshooting to determine if the problem is actually the speaker, or a problem located in a different part of the vehicle such as the amplifier, wiring, fusing or possibly the source unit. If your Audiobahn speakers have been installed professionally by an authorized Audio- bahn Dealer, we recommend that you return to the dealer and demonstrate the problem to a qualified installer or repair technician. If you installed the speaker yourself, use the...

  • Page 11: Warning And Disclaimer

    If you need to replace the power fuse, replace it only with a fuse identical to that supplied with the system. Using a fuse of a different type or rating may result in damage to this system which is not covered by the warranty. Disclaimer Specifications are subject to change without notice. For the most updated Specifications call Audiobahn, your local Authorized Audiobahn Dealer, or check the Audiobahn web site. www.audiobahn.com...

  • Page 12: Warranty

    Because of this we recommend that you have your new products installed by an Au- thorized Audiobahn Dealer. (A list of Authorized Audiobahn Dealers can be found on our web page). Warranty Period: One year from the original date of purchase.
  • Page 13 This might include having an Authorized Audiobahn Dealer look at the product to confirm the source of the problem. Any product found to have a manufacturer defect will be replaced with a new piece of the same or similar model, or repaired at the discretion of Audiobahn. Any product found to have no manufacturer defect will be returned to the sender at their cost.

  • Page 14: Notes

    NOTES...
  • Page 15 NOTES...
  • Page 16 7050 Village Drive, Bldg G Buena Park, CA 90621 714-452-1476 o ce 888-880-8469 fax info@audiobahn.com PROUD SPONSOR OF Follow us on Facebook and Twitter...
