ASROCK H61M-VS R2.0 User Manual

User manual
Hide thumbs Also See for H61M-VS R2.0:
Table of Contents

Advertisement

Quick Links

See also: User Manual
Enlarged version
H61M-VGS R2.0 /
H61M-VS R2.0

User Manual

Version 1.0
Published September 2011
Copyright©2011 ASRock INC. All rights reserved.
1

Advertisement

Table of Contents
loading

Related Manuals for ASROCK H61M-VS R2.0

Summary of Contents for ASROCK H61M-VS R2.0

  • Page 1: User Manual

    H61M-VGS R2.0 / H61M-VS R2.0 User Manual Version 1.0 Published September 2011 Copyright©2011 ASRock INC. All rights reserved.

  • Page 2: Copyright Notice

    fi tness for a particular purpose. In no event shall ASRock, its directors, offi cers, employees, or agents be liable for any indirect, special, incidental, or consequential damages (including damages for loss of profi...

  • Page 3: Table Of Contents

    1 Introduction ............5 1.1 Package Contents ............5 1.2 Specifi cations ..............6 1.3 Motherboard Layout (H61M-VGS R2.0 / H61M-VS R2.0) ......11 1.4 I/O Panel (H61M-VGS R2.0) ........12 1.5 I/O Panel (H61M-VS R2.0) .......... 13 2 Installation ............14 2.1 Screw Holes ..............
  • Page 4 3 UEFI SETUP UTILITY ..........32 3.1 Introduction ..............32 3.1.1 UEFI Menu Bar ............ 32 3.1.2 Navigation Keys ........... 33 3.2 Main Screen ..............33 3.3 OC Tweaker Screen ............35 3.4 Advanced Screen ............38 3.4.1 CPU Confi guration ..........39 3.4.2 North Bridge Confi...

  • Page 5: Introduction

    In case any modifi cations of this manual occur, the updated version will be available on ASRock website without further notice. You may fi nd the latest VGA cards and CPU support lists on ASRock website as well.

  • Page 6: Specifi Cations

    - 5.1 CH HD Audio (VIA VT1705 Audio Codec) - H61M-VGS R2.0 Realtek PCIE x1 Gigabit LAN RTL8111E, speed 10/100/1000 Mb/s - H61M-VS R2.0 Realtek PCIE x1 LAN RTL8105E, speed 10/100 Mb/s - Supports Wake-On-LAN - Supports PXE Rear Panel I/O...
  • Page 7 - Drivers, Utilities, AntiVirus Software (Trial Version), CyberLink MediaEspresso 6.5 Trial, ASRock Software Suite (CyberLink DVD Suite - OEM and Trial; Creative Sound Blaster X-Fi MB - Trial; ASRock MAGIX Multimedia Suite - OEM) Unique Feature - ASRock Extreme Tuning Utility (AXTU) (see CAUTION 5)
  • Page 8 Please check Intel website for the latest informa- tion. ASRock Extreme Tuning Utility (AXTU) is an all-in-one tool to fi ne-tune different system functions in a user-friendly interface, which is including Hardware Monitor, Fan Control, Overclocking, OC DNA and IES. In Hardware Monitor, it shows the major readings of your system.
  • Page 9 ASRock Instant Flash is a BIOS fl ash utility embedded in Flash ROM. This convenient BIOS update tool allows you to update system BIOS ® without entering operating systems fi rst like MS-DOS or Windows . With this utility, you can press <F6> key during the POST or press <F2> key to BIOS setup menu to access ASRock Instant Flash.
  • Page 10 12. Combo Cooler Option (C.C.O.) provides the fl exible option to adopt three different CPU cooler types, Socket LGA 775, LGA 1155 and LGA 1156. Please be noticed that not all the 775 and 1156 CPU Fan can be used. 13.

  • Page 11: Motherboard Layout (H61M-Vgs R2.0 / H61M-Vs R2.0)

    1.3 Motherboard Layout (H61M-VGS R2.0 / H61M-VS R2.0) 17.3cm (6.8 in) CPU_FAN1 ATX12V1 RoHS USB 2.0 T: USB0 B: USB1 USB 2.0 T: USB2 B: USB3 USB 2.0 Top: T: USB4 RJ-45 B: USB5 PCI Express 2.0 PWR_FAN1 PCIE1 Intel...

  • Page 12: I/O Panel (H61M-Vgs R2.0)

    1.4 I/O Panel (H61M-VGS R2.0) PS/2 Mouse Port (Green) USB 2.0 Ports (USB45) LAN RJ-45 Port USB 2.0 Ports (USB23) Line In (Light Blue) USB 2.0 Ports (USB01) ** 4 Front Speaker (Lime) VGA Port Microphone (Pink) PS/2 Keyboard Port (Purple) * There are two LED next to the LAN port.

  • Page 13: I/O Panel (H61M-Vs R2.0)

    1.5 I/O Panel (H61M-VS R2.0) PS/2 Mouse Port (Green) USB 2.0 Ports (USB45) LAN RJ-45 Port USB 2.0 Ports (USB23) Line In (Light Blue) USB 2.0 Ports (USB01) ** 4 Front Speaker (Lime) VGA Port Microphone (Pink) PS/2 Keyboard Port (Purple) * There are two LED next to the LAN port.

  • Page 14: Installation

    Chapter 2: Installation This is a Micro ATX form factor (8.9" x 6.8", 22.6 x 17.3 cm) motherboard. Before you install the motherboard, study the confi guration of your chassis to ensure that the motherboard fi ts into it. Make sure to unplug the power cord before installing or removing the motherboard.

  • Page 15: Cpu Installation

    2.3 CPU Installation For the installation of Intel 1155-Pin CPU, please follow the steps below. Load Plate Load Lever Socket Body Contact Array 1155-Pin Socket Overview Before you insert the 1155-Pin CPU into the socket, please check if the CPU surface is unclean or if there is any bent pin on the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 16 Step 3. Insert the 1155-Pin CPU: Step 3-1. Hold the CPU by the edge where is marked with black line. Step 3-2. Orient the CPU with IHS (Integrated Heat Sink) up. Locate Pin1 and the two orientation key notches. orientation key notch alignment key Pin1 Pin1...

  • Page 17: Installation Of Cpu Fan And Heatsink

    Installation of CPU Fan and Heatsink This motherboard is equipped with 1155-Pin socket that supports Intel 1155-Pin CPU. Please adopt the type of heatsink and cooling fan compliant with Intel 1155- Pin CPU to dissipate heat. Before you installed the heatsink, you need to spray thermal interface material between the CPU and the heatsink to improve heat dis- sipation.

  • Page 18: Installation Of Memory Modules (Dimm)

    2.5 Installation of Memory Modules (DIMM) This motherboard provides two 240-pin DDR3 (Double Data Rate 3) DIMM slots, and supports Dual Channel Memory Technology. For dual channel configuration, you always need to install two identical (the same brand, speed, size and chip- type) memory modules in the DDR3 DIMM slots to activate Dual Channel Memory Technology.

  • Page 19: Expansion Slots (Pci Express Slots)

    2.6 Expansion Slots (PCI Express Slots) There are 2 PCI Express slots on this motherboard. PCIE slots: PCIE1 (PCIE x16 slot; Blue) is used for PCI Express x16 lane width graphics cards. PCIE2 (PCIE x1 slot; White) is used for PCI Express cards with x1 lane width cards, such as Gigabit LAN card, SATA2 card, etc.

  • Page 20: Multi Monitor Feature

    2.7 Multi Monitor Feature This motherboard supports multi monitor upgrade. With the internal VGA output sup- port and external add-on PCI Express VGA cards, you can easily enjoy the benefi ts of multi monitor feature. Please refer to the following steps to set up a multi monitor environment: 1.
  • Page 21 F. Set the “Screen Resolution” and “Color Quality” as appropriate for the second monitor. Click “Apply” or “OK” to apply these new values. G. Repeat steps C through E for the diaplay icon identifi ed by the number one, two and three. ®...

  • Page 22: Jumpers Setup

    2.8 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on pins, the jumper is “Short”. If no jumper cap is placed on pins, the jumper is “Open”. The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short”...

  • Page 23: Onboard Headers And Connectors

    2.9 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage of the motherboard! Serial ATAII Connectors These four Serial ATAII SATA2_3 SATA2_1...
  • Page 24 Front Panel Audio Header This is an interface for front PRESENCE# MIC_RET panel audio cable that allows (9-pin HD_AUDIO1) OUT_RET convenient connection and (see p.11 No. 22) control of audio devices. OUT2_L J_SENSE OUT2_R MIC2_R MIC2_L 1. High Defi nition Audio supports Jack Sensing, but the panel wire on the chassis must support HDA to function correctly.
  • Page 25 The front panel design may differ by chassis. A front panel module mainly consists of power switch, reset switch, power LED, hard drive activity LED, speaker and etc. When connecting your chassis front panel module to this header, make sure the wire assignments and the pin assign-ments are matched correctly.
  • Page 26 ATX 12V Power Connector Please connect an ATX 12V power supply to this connector. (4-pin ATX12V1) (see p.11 No. 2) Serial port Header This COM1 header supports a serial port module. (9-pin COM1) (see p.11 No. 17)

  • Page 27: Serial Ata (Sata) / Serial Ataii (Sataii) Hard Disks Installation

    2.10 Serial ATA (SATA) / Serial ATAII (SATAII) Hard Disks Installation ® This motherboard adopts Intel H61 chipset that supports Serial ATA (SATA) / Serial ATAII (SATAII) hard disks. You may install SATA / SATAII hard disks on this mother- board for internal storage devices.

  • Page 28: Sata / Sataii Hdd Hot Plug Feature And Operation Guide

    3. Please make sure the SATA / SATAII driver is installed into system properly. The latest SATA / SATAII driver is available on our support website: www.asrock.com 4. Make sure to use the SATA power cable & data cable, which are from our motherboard package.

  • Page 29: How To Hot Plug A Sata / Sataii Hdd

    How to Hot Plug a SATA / SATAII HDD: Points of attention, before you process the Hot Plug: Please do follow below instruction sequence to process the Hot Plug, improper procedure will cause the SATA / SATAII HDD damage and data loss. Step 1 Step 2 Please connect SATA power cable 1x4-pin end...

  • Page 30: Driver Installation Guide

    2.13 Driver Installation Guide To install the drivers to your system, please insert the support CD to your optical drive fi rst. Then, the drivers compatible to your system can be auto-detected and listed on the support CD driver page. Please follow the order from up to bottom side to install those required drivers.

  • Page 31: 64-Bit / Vista

    ® STEP 3: Install Windows XP / XP 64-bit OS on your system. ® After making a SATA / SATAII driver diskette, you can start to install Windows ® / XP 64-bit on your system. At the beginning of Windows setup, press F6 to install a third-party AHCI driver.

  • Page 32: Uefi Setup Utility

    Chapter 3: UEFI SETUP UTILITY Introduction This section explains how to use the UEFI SETUP UTILITY to confi gure your system. The UEFI chip on the motherboard stores the UEFI SETUP UTILITY. You may run the UEFI SETUP UTILITY when you start up the computer. Please press <F2>...

  • Page 33: Navigation Keys

    3.1.2 Navigation Keys Please check the following table for the function description of each navigation key. Navigation Key(s) Function Description Moves cursor left or right to select Screens Moves cursor up or down to select items + / - To change option for the selected items <Enter>...
  • Page 34 H61M-VS R2.0...

  • Page 35: Oc Tweaker Screen

    3.3 OC Tweaker Screen In the OC Tweaker screen, you can set up overclocking features. Load GPU EZ OC Setting Use this item to load GPU EZ overclocking setting. Please note that overclocking may cause damage to your GPU and motherboard. It should be done at your own risk and expense.
  • Page 36 Turbo Boost Power Limit Use this item to adjust Turbo Boost power limit. Confi guration options: [Auto] and [Manual]. The default value is [Auto]. Core Current Limit Use this item to add voltage when CPU is in Turbo mode. DRAM Timing Control DRAM Frequency If [Auto] is selected, the motherboard will detect the memory module(s) inserted and assigns appropriate frequency automatically.
  • Page 37 Four Activate Window (tFAW) Use this item to change Four Activate Window (tFAW) Auto/Manual set- ting. The default is [Auto]. Memory Power Down Mode Use this item to adjust DDR power down mode. Configuration options: [Auto], [Slow] and [Fast]. The default value is [Auto]. ODT WR (CHA) Use this item to change ODT WR (CHA) Auto/Manual setting.

  • Page 38: Advanced Screen

    Setting wrong values in this section may cause the system to malfunction. ASRock Instant Flash ASRock Instant Flash is a UEFI flash utility embedded in Flash ROM. This convenient UEFI update tool allows you to update system UEFI ® without entering operating systems fi rst like MS-DOS or Windows .

  • Page 39: Cpu Confi Guration

    3.4.1 CPU Configuration Intel Hyper Threading Technology To enable this feature, it requires a computer system with an Intel processor that supports Hyper-Threading technology and an operating ® system that includes optimization for this technology, such as Microsoft ® ® ®...
  • Page 40 CPU Thermal Throttling You may select [Enabled] to enable CPU internal thermal control mechanism to keep the CPU from overheated. Intel Virtualization Technology When this option is set to [Enabled], a VMM (Virtual Machine Architecture) can utilize the additional hardware capabilities provided by Vanderpool Technology.

  • Page 41: North Bridge Confi Guration

    3.4.2 North Bridge Configuration Low MMIO Align Low MMIO resources align at 64MB/1024MB. The default value is [64MB]. VT-d ® ® Use this to enable or disable Intel VT-d technology (Intel Virtualization Technology for Directed I/O). The default value of this feature is [Disabled]. Primary Graphics Adapter This allows you to select the boot graphic adapter priority.
  • Page 42 DVMT Memory You are allowed to adjust the shared memory size in this item. Configuration options: [128MB], [256MB] and [Maximum]. The option [Maximum] only appears when you adopt the memory module with 1024MB or above.

  • Page 43: South Bridge Confi Guration

    3.4.3 South Bridge Configuration Restore on AC/Power Loss This allows you to set the power state after an unexpected AC/power loss. If [Power Off] is selected, the AC/power remains off when the power recovers. If [Power On] is selected, the AC/power resumes and the system starts to boot up when the power recovers.

  • Page 44: Storage Confi Guration

    3.4.4 Storage Configuration SATA Mode Use this to select SATA mode. Confi guration options: [IDE Mode], [AHCI Mode] and [Disabled]. The default value is [IDE Mode]. AHCI (Advanced Host Controller Interface) supports NCQ and other new features that will improve SATA disk perfor- mance but IDE mode does not have these advantages.

  • Page 45: Super Io Confi Guration

    3.4.5 Super IO Configuration Serial Port Use this item to enable or disable the onboard serial port. Serial Port Address Use this item to set the address for the onboard serial port. Confi guration options: [3F8 / IRQ4] and [3E8 / IRQ4]. Parallel Port Use this item to enable or disable the onboard parallel port.

  • Page 46: Acpi Confi Guration

    3.4.6 ACPI Configuration Suspend to RAM Use this item to select whether to auto-detect or disable the Suspend-to- RAM feature. Select [Auto] will enable this feature if the OS supports it. Check Ready Bit Use this item to enable or disable the feature Check Ready Bit. PS/2 Keyboard Power On Use this item to enable or disable PS/2 keyboard to turn on the system from the power-soft-off mode.

  • Page 47: Usb Confi Guration

    3.4.7 USB Configuration USB 2.0 Controller Use this item to enable or disable the use of USB 2.0 controller. Legacy USB Support Use this option to select legacy support for USB devices. There are four confi guration options: [Enabled], [Auto], [Disabled] and [UEFI Setup Only]. The default value is [Enabled].

  • Page 48: Hardware Health Event Monitoring Screen

    3.5 Hardware Health Event Monitoring Screen In this section, it allows you to monitor the status of the hardware on your system, including the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed, and the critical voltage. CPU Fan Setting This allows you to set the CPU fan speed.

  • Page 49: Boot Screen

    3.6 Boot Screen In this section, it will display the available devices on your system for you to confi g- ure the boot settings and the boot priority. Setup Prompt Timeout This shows the number of seconds to wait for setup activation key. 65535(0XFFFF) means indefi...

  • Page 50: Security Screen

    3.7 Security Screen In this section, you may set or change the supervisor/user password for the system. For the user password, you may also clear it.

  • Page 51: Exit Screen

    3.8 Exit Screen Save Changes and Exit When you select this option, it will pop-out the following message, “Save confi guration changes and exit setup?” Select [OK] to save the changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option, it will pop-out the following message, “Discard changes and exit setup?”...

  • Page 52: Software Support

    Click on a specifi c item then follow the installation wizard to install it. 4.2.4 Contact Information If you need to contact ASRock or want to know more about ASRock, welcome to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer for further information.
  • Page 53 Installing OS on a HDD Larger Than 2TB ® This motherboard is adopting UEFI BIOS that allows Windows OS to be installed on a large size HDD (>2TB). Please follow below procedure to install the operating system. ® 1. Please make sure to use Windows Vista 64-bit (with SP1 or above) or ®...

This manual is also suitable for:

H61m-vgs r2.0
