- Page 5 Technology and all-new DVX woofer design, specifically addresses the needs of custom- ers in this market. From regional PA com- panies to high-end concert touring, Phoenix provides medium and long-throw solutions for applications including festivals, clubs and outdoor events—anywhere high SPL non-line...
- Page 6 Electro-Voice® Manifold Technology Unique to all Phoenix high-mid systems and monitors is patented Electro-Voice Manifold Technology. Borrowing from the innovations of the original MT series, yet employing the most advanced Electro-Voice technology, Phoenix manifolds boast major advantages over single compression driver designs. More drivers means higher power handling capacity and more SPL per horn, allowing the use of less overall cabinets for the same output.
- Page 8 Snapshots of Dynamic FEA for a high power signal (100V) for a conventional design (top) versus DVX (bottom). The changing colors in the gap indicate an extreme variation of the magnetic flux for the conventional design, while there is only slight variation with DVX.
- Page 9 DVX woofers needs to be heard to be believed. Combined with the output potential of manifold technology , DVX is the base for the outstanding acoustical performance of Phoenix. With every excursion, cool air is drawn through the voice coil, removing heat.
- Page 10 Intended for situations where very high SPL and maximum throw are desired, the PX2122 packs tremendous horsepower. Dual ND2 com- pression drivers are precisely summed in a manifold configuration for increased power handling, maximum high and mid frequency headroom, and lower distortion. Designed to reproduce the frequency range above 80 Hz, the PX2122 works perfectly with the PX2181 subwoofer.
- Page 13 M10 points provide flexibility in situa- tions where hanging is either necessary or optimal. accessories: Optional durable covers for Phoenix systems resist the normal wear and tear of the road. Shown from left - PXC-Sub, PXC-Top, PXC-15M and PXC-12M.
- Page 14 18-inch subwoofer intended for high-output low-frequency sound reinforcement. With the ability to perform in either portable or fixed installation applications, the flexibility of the PX2181 makes it usable within a Phoenix system, a club installation, or as an add-on to much larger con- cert touring systems.
- Page 17 Combining the punch of dual 12-inch DVX 3121, a narrow 45° x 30° horn pattern, and The PX1122M and PX1152M are versatile, dual ND2 manifold compression drivers, the PX2122 is designed to be used in medium to long throw applications with a minimum of two cabinets per side. The bi-amp only full-range, two-way multi-purpose loudspeakers designed for a wide array of applications.
- Page 18 Phoenix System Drive Phoenix has been designed and engineered as a complete system, tested and tuned with Electro- Voice power amplifiers and digital signal processors. While all Phoenix models are singularly ex- ceptional, maximum potential is truly realized with a combination of Phoenix tops and subs driven by world-class EV electronics.
- Page 19 3 way system (stereo) PX2122 (6) PX2181 (6) Dx38 (2) CP4000S (6) 3 way system (stereo) PX2122 (4) PX2181 (4) Dx38 (2) CP4000S (5) 2 way system (stereo) PX2152 (4) PX2181 (4) Dx38 (1) CP4000S (2) 3 way system (stereo) PX2152 (2) PX2181 (4) Dx38 (2)
- Page 20 Technical PX2122 Specifications Freq. Response (-3 dB) 80 Hz - 15 kHz Freq. Range (-10 dB) 60 Hz - 19 kHz Rec. Hi-pass Frequency 80 Hz Rec. Lo-pass Frequency Axial Sensitivity 102 dB (1W/1m) Max Calculated SPL 138 dB Horizontal Coverage 45°...
