LCD Display panels

ISO speed
Highlight tone priority display
(Dust Delete Data acquisition (––––)
Shooting Mode
P
V
M
T
Metering Mode
Battery Level Mark
B
When the camera is ready to shoot, the ISO speed is now always displayed on the top
LCD panel. The mirror lockup icon and the Silent drive mode icon have also been added.
With the battery check detection system, the battery check indicator now shows 6 levels
instead of 4. This gives you a more precise indication of battery level. Since the Personal
Functions have been consolidated with the Custom Functions, the # (P. Fn) icon has
been discontinued.
The image size indicator for the external media and respective recording media and
icons for B/W shooting, white balance correction, and LAN connection have been added
to the rear LCD panel. You can rearrange the layout of the TFT panel yourself using the
Func. button to toggle the display.
The B/A and G/M bias icon for WB correction/bracketing have been discontinued. The WB
correction amount and BKT level indicator have also been discontinued.
Image Size

LCD Monitor

The large 3.0-in. TFT monitor (1.4 times larger in area than 2.5 inches) features approxi-
mately 230,000 pixels, a wide-viewing angle (140° both vertically and horizontally),
high-level brightness, and low power consumption. The LCD monitor is backlit with
four LED modules. The maximum brightness is about 1.8 times brighter than the
EOS-1D Mark II
even in bright outdoor conditions. The brightness adjustment has therefore been
increased to seven levels (from five) to make the camera more adaptable to environmental
IX. CONTROLS AND DISPLAY
: Program AE
: Aperture-priority AE
: Manual Exposure
: Shutter-priority AE
ISO speed
Evaluative Metering
Partial Metering
Spot Metering
Center-weighted
Average Metering
Flash Exposure Compensation
AEB
Mirror Lockup
sRAW
White Balance Correction
External Media Connection Icon
SD Card Indicator
CF card Indicator
Recording Media Selection Arrow
Large
Medium1
Medium2
Small
RAW
small RAW
Wired LAN Connection Status
Wireless LAN Connection Status
's LCD monitor, making it easier to see the image on the LCD monitor
N
Shutter Speed
Bulb ( )
Bulb Exposure Time (Min.:Sec.)
AF Point Selection Mode ([ ], SEL)
FE Lock
Busy ( ,PC )
Error ( )
Sensor Cleaning ( )
Aperture
AEB amount
(Dust Delete Data acquisition (––––)
AF point selection mode
( AF, SEL[ ], SEL AF)
Recording media indicator (Card*)
External Media Indicator
Shots Remaining
Self-timer Countdown
Bulb Exposure Time (Hours)
Recording Media Full (
Error Code
Remaining Images to Record
AF Mode
One-Shot AF
AI SERVO AF
Drive Modes
Single Shooting
High-speed Continuous
Shooting
Low-speed Continuous
Shooting
Self-timer (10 sec.)
Self-timer (2 sec.)
Silent Mode
Exposure Level Scale
Exposure Level Indicator
Exposure Compensation Amount
AEB Range
Flash Exposure Compensation Amount
Monochrome Shooting
Data Transfer Icon
White Balance
Auto
Daylight
Shade
Cloudy
Tungsten Light
White Fluorescent Light
Flash
Custom
Color Temperature
Custom White Balance
Acquistion Display ([ * ])
File No.
Color Temprature
Custom White Balance Number
Personal White Balance (PC1~PC5)
Folder Number
Recording Media Indicator
( )
)
