Patch Release Note
Patch 86251-05
For Rapier Switches and AR800 Series
Modular Switching Routers
S im ply co nn ecti n g the worl d
Introduction
This patch release note lists the issues addressed and enhancements made in
patch 86251-05 for Software Release 2.5.1 on existing models of Rapier L3
managed switches and AR800 Series L3 modular switching routers. Patch file
details are listed in Table 1.
Table 1: Patch file details for Patch 86251-05.
Base Software Release File
Patch Release Date
Compressed Patch File Name
Compressed Patch File Size
This release note should be read in conjunction with the following documents:
Release Note: Software Release 2.5.1 for Rapier Switches, and AR800 Series
Modular Switching Routers (Document Number C613-10354-00 Rev A)
available from www.alliedtelesyn.co.nz/documentation/documentation.html.
Rapier Switch Documentation Set for Software Release 2.5.1 available on
the Documentation and Tools CD-ROM packaged with your switch, or
from www.alliedtelesyn.co.nz/documentation/documentation.html.
WARNING: Using a patch for a different model or software release may cause
unpredictable results, including disruption to the network. Information in this
release note is subject to change without notice and does not represent a
commitment on the part of Allied Telesyn International. While every effort has
been made to ensure that the information contained within this document and
the features and changes described are accurate, Allied Telesyn International
can not accept any type of liability for errors in, or omissions arising from the
use of this information.
86s-251.rez
15-May-2003
86251-05.paz
320764 bytes

Advertisement

loading
Need help?

Need help?

Do you have a question about the 86251-05 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Allied Telesis 86251-05

  • Page 1 Introduction This patch release note lists the issues addressed and enhancements made in patch 86251-05 for Software Release 2.5.1 on existing models of Rapier L3 managed switches and AR800 Series L3 modular switching routers. Patch file details are listed in Table 1.
  • Page 2 Level 3 Level 4 Features in 86251-05 Patch 86251-05 includes all issues resolved and enhancements released in previous patches for Software Release 2.5.1, and the following enhancements: PCR: 02583 UDP packets passed through the firewall by a reverse enhanced NAT rule were getting an incorrect IP checksum.
  • Page 3 Patch 86251-05 For Rapier Switches and AR800 Series Modular Switching Routers PCR: 03270 The inter-packet gap has been reduced by 4 bytes on the Rapier 48i stacking link. This allows for non-blocking operation with tagged packets. PCR: 03299 Under some circumstances, ISAKMP suffered a fatal error if more than 8 SA proposals were presented.
  • Page 4 Module: DHCP Module: IPV6 Module: SWI, VLAN Patch Release Note Level: 2 Level: 2 Level: 3 Level: 3 Level: 3 Level: 2 Level: 2 Level: 3 Level: 2 Level: 3 Level: 3 Patch 86251-05 for Software Release 2.5.1 C613-10356-00 REV F...
  • Page 5 Patch 86251-05 For Rapier Switches and AR800 Series Modular Switching Routers PCR: 03430 BGP traps were sent incorrectly when a BGP peer became Established, or moved into a lower state. This issue has been resolved. PCR: 03432 STP settings were not retained when a port was deleted from the VLAN that the STP belongs to.
  • Page 6 Module: PIM, PIM6 Module: IPG Module: IPV6 Patch Release Note Level: 3 Level: 2 Level: 2 Level: 2 Level: 3 Level: 3 Level: 3 Level: 3 Level: 3 Level: 3 Level: 2 Patch 86251-05 for Software Release 2.5.1 C613-10356-00 REV F...
  • Page 7 Patch 86251-05 For Rapier Switches and AR800 Series Modular Switching Routers PCR: 03473 The SET LAPD MODE=NONAUTOMATIC command did not change the LAPD mode from automatic to non-automatic. This issue has been resolved. PCR: 03474 The SMTP proxy did not correctly allow outgoing (private to public) SMTP sessions when the DIRECTION parameter was set to OUT or BOTH in the ADD FIREWALL PROXY command.
  • Page 8 Module: SWI Module: PIM Module: PIM Module: IPG Patch Release Note Level: 3 Level: 3 Level: 3 Level: 3 Level: 2 Level: 3 Level: 3 Level: 3 Level: 3 Level: 2 Patch 86251-05 for Software Release 2.5.1 C613-10356-00 REV F...
  • Page 9 Patch 86251-05 For Rapier Switches and AR800 Series Modular Switching Routers Features in 86251-04 Patch file details are listed in Table 2: Table 2: Patch file details for Patch 86251-04. Base Software Release File Patch Release Date Compressed Patch File Name...
  • Page 10 Module: FIREWALL Module: FIREWALL Module: CLASSIFIER Patch Release Note Level: 2 Level: 3 Level: 2 Level: 3 Level: 3 Level: 3 Level: 1 Level: 3 Level: 2 Level: 1 Level: 4 Patch 86251-05 for Software Release 2.5.1 C613-10356-00 REV F...
  • Page 11 Patch 86251-05 For Rapier Switches and AR800 Series Modular Switching Routers PCR: 03120 The SHOW IP INTERFACE command was showing ETH interfaces as up at startup, when SHOW INTERFACE and SHOW ETH STATE had them as down. This issue has been resolved.
  • Page 12 Module: SWI Module: IPV6 Module: IPG Module: IPG Module: DVMRP Patch Release Note Level: 3 Level: 4 Level: Level: 4 Level: 3 Level: 2 Level: 3 Level: 3 Level: 4 Level: 2 Patch 86251-05 for Software Release 2.5.1 C613-10356-00 REV F...
  • Page 13 Patch 86251-05 For Rapier Switches and AR800 Series Modular Switching Routers PCR: 03169 Duplicate Address Detection (DAD) was not sent on VLAN interfaces. This issue has been resolved. PCR: 03180 If all 32 VLAN interfaces had IP addresses attached, only 31 VLANs could be multihomed.
  • Page 14 Module: IPSEC Module: PIM, PIM6 Module: PIM, PIM6 Module: LOAD Patch Release Note Level: 2 Level: 3 Level: 2 Level: 2 Level: 3 Level: 3 Level: 2 Level: 2 Level: 3 Patch 86251-05 for Software Release 2.5.1 C613-10356-00 REV F...
  • Page 15 Patch 86251-05 For Rapier Switches and AR800 Series Modular Switching Routers PCR: 03232 Values for the KEEPALIVE and HOLDTIME parameters in the ADD BGP PEER and SET BGP PEER commands were not interacting correctly. This issue has been resolved. PCR: 03234 The PURGE IP command did not remove ENABLE IP IGMP from the configuration.
  • Page 16 Module: IPG Module: L2TP Patch Release Note Level: 3 Level: 3 Level: 3 Level: 4 Level: 4 Level: 3 Level: 2 Level: 4 Level: 3 Level: 3 Level: 4 Level: 2 Patch 86251-05 for Software Release 2.5.1 C613-10356-00 REV F...
  • Page 17 Patch 86251-05 For Rapier Switches and AR800 Series Modular Switching Routers PCR: 03291 A PAP authentication failure with PPPoE could cause a fatal error. This issue has been resolved. PCR: 03292 When adding static routes with the ADD IP ROUTE command, the order of the route in the route table was the reverse of the order entered.
  • Page 18 Module: SWI Module: BGP Module: IP, SWI Patch Release Note Level: 4 Level: 2 Level: 3 Level: 3 Level: 4 Level: 3 Level: 4 Level: 4 Level: 3 Level: 3 Level: 3 Patch 86251-05 for Software Release 2.5.1 C613-10356-00 REV F...
  • Page 19 Patch 86251-05 For Rapier Switches and AR800 Series Modular Switching Routers PCR: 03351 Several issues with the DHCP Server have been resolved. PCR: 03352 The MRU parameter in the SET PPP command was incorrectly handled as an interface parameter when the configuration script was generated. This meant that the OVER parameter was omitted.
  • Page 20 Module: IPSEC Module: PIM, PIM6 Module: DHCP Module: ISAKMP Module: SWI Patch Release Note Level: 3 Level: 3 Level: 2 Level: 3 Level: 2 Level: 3 Level: 3 Level: 3 Patch 86251-05 for Software Release 2.5.1 C613-10356-00 REV F...
  • Page 21 Patch 86251-05 For Rapier Switches and AR800 Series Modular Switching Routers Features in 86251-03 Patch file details are listed in Table 3: Table 3: Patch file details for Patch 86251-03. Base Software Release File Patch Release Date Compressed Patch File Name...
  • Page 22 86251-02.paz 28756 bytes Module: IPV6 Module: DVMRP Module: OSPF Patch Release Note Level: 2 Level: 1 Level: 2 Level: 1 Level: 4 Network affecting: No Network affecting: No Network affecting: No Patch 86251-05 for Software Release 2.5.1 C613-10356-00 REV F...
  • Page 23 Patch 86251-05 For Rapier Switches and AR800 Series Modular Switching Routers PCR: 03015 When ports were added to a trunk group on a Rapier 16, the ports operated in the wrong duplex mode. This issue has been resolved. PCR: 03029 Layer 3 filtering was not correctly modifying a packet's IPDSCP field.
  • Page 24: Static Igmp

    The user will also be able to filter some IGMP debug messages by source IP address and group destination address. Module: TCP Module: SWI Module: DVMRP Module: TM Patch Release Note Network affecting: No Network affecting: No Network affecting: No Network affecting: No Patch 86251-05 for Software Release 2.5.1 C613-10356-00 REV F...
  • Page 25: Configuration Example

    Patch 86251-05 For Rapier Switches and AR800 Series Modular Switching Routers Figure 2: Forwarding multicast data over a specified interface and port. Configuration Example The following configuration example illustrates the steps required to create a static IGMP association. It assumes that vlan1 has already been configured as an IP interface on the switch.
  • Page 26: Show Ip Igmp

    Examples To display information about all group destination addresses starting with “224” on vlan1, use the command: SHOW IP IGMP INTERFACE=VLAN1 DESTINATION=224.*.*.* Patch Release Note Patch 86251-05 for Software Release 2.5.1 C613-10356-00 REV F...
  • Page 27 Patch 86251-05 For Rapier Switches and AR800 Series Modular Switching Routers Figure 3: Example output from the SHOW IP IGMP DESTINATION command showing Static Groups. IGMP Protocol ---------------------------------------------------------------------------------- Status ... Enabled Default Query Interval ... 125 secs Default Timeout Interval ... 270 secs Last Member Query Interval ...
  • Page 28: New Commands

    To add port 5 to the list of ports through which multicast data for 224.1.2.3 will be forwarded over vlan1, use the command: ADD IP IGMP DESTINATION=224.1.2.3 INTERFACE=VLAN1 PORT=5 See Also DELETE IP IGMP DESTINATION SHOW IP IGMP Patch Release Note Patch 86251-05 for Software Release 2.5.1 C613-10356-00 REV F...
  • Page 29 Patch 86251-05 For Rapier Switches and AR800 Series Modular Switching RoutersCREATE IP IGMP DESTINATION CREATE IP IGMP DESTINATION Syntax CREATE IP IGMP DESTINATION=ipaddress INTERFACE=interface [PORT={ALL|port-list}] where: ■ ipaddress is an existing IGMP group destination address. ■ interface is the name of the interface over which multicast data is forwarded.
  • Page 30 INTERFACE parameters must already exist for this command to succeed. Examples To stop the switch forwarding all multicast data for 224.1.2.3 over vlan1, use the command: DESTROY IP IGMP DESTINATION=224.1.2.3 INTERFACE=VLAN1 See Also CREATE IP IGMP DESTINATION Patch Release Note Patch 86251-05 for Software Release 2.5.1 C613-10356-00 REV F...
  • Page 31 Patch 86251-05 For Rapier Switches and AR800 Series Modular Switching RoutersENABLE IP IGMP DEBUG DISABLE IP IGMP DEBUG Syntax DISABLE IP IGMP DEBUG Description This command disables all IGMP debugging messages and resets the DESTINATION and SOURCEIPADDRESS parameters set in the ENABLE IP IGMP DEBUG command to ALL.
  • Page 32 The source IP address specified by the SOURCEIPADDRESS parameter in the ENABLE IP IGMP DEBUG command. If the parameter was not given, "No" is displayed instead of the IP address. Patch Release Note Patch 86251-05 for Software Release 2.5.1 C613-10356-00 REV F...
  • Page 33 Patch 86251-05 For Rapier Switches and AR800 Series Modular Switching RoutersSHOW IP IGMP DEBUG ■ software release 86s-251 and patch 86251-04 are loaded, but the patch was corrupted after a restart or reboot. The Rapier16fi requires the 86251-04 patch to operate correctly. Without this patch the port map is incorrect.
  • Page 34 Down Down Down Down Down Down Down RESTART REBOOT Patch Release Note 00:01:22 ifLastChange 00:00:00 00:00:00 00:00:00 00:00:00 00:00:00 00:00:00 00:00:00 00:00:00 00:00:00 00:00:00 00:00:00 00:00:00 00:00:00 00:00:00 00:00:00 00:00:00 00:00:00 Patch 86251-05 for Software Release 2.5.1 C613-10356-00 REV F...
  • Page 35 Patch 86251-05 For Rapier Switches and AR800 Series Modular Switching RoutersSHOW IP IGMP DEBUG Figure 3: Router startup messages INFO: Self tests beginning. INFO: RAM test beginning. PASS: RAM test, 4096k bytes found. INFO: BBR tests beginning. PASS: BBR test, 128k bytes found.
  • Page 36 PPP interface 1, and enable STAC LZS compression on the synchronous link with a check mode of LCB, use the command: ADD PPP=1 OVER=vlan2-any COMP=LINK STACCHECK=LCB SYNn DS3n ISDN-callname ACC-callname MIOXn-circuitname TDM-groupname TNL-callname VLANn-servicename Patch Release Note Patch 86251-05 for Software Release 2.5.1 C613-10356-00 REV F...
  • Page 37 Patch 86251-05 For Rapier Switches and AR800 Series Modular Switching Routers CREATE PPP Syntax CREATE PPP=ppp-interface OVER=physical-interface [other parameters] where: ■ ppp-interface is the PPP interface number, from 0 to 511. ■ physical-interface is: • • • • • •...
  • Page 38 PPP interface number, from 0 to 511. ■ physical-interface is: • • • • • • • • SYNn DS3n ISDN-callname ACC-callname MIOXn-circuitname TDM-groupname TNL-callname VLANn-servicename SYNn DS3n ISDN-callname ACC-callname MIOXn-circuitname TDM-groupname TNL-callname VLANn-servicename Patch Release Note Patch 86251-05 for Software Release 2.5.1 C613-10356-00 REV F...
  • Page 39: Show Ppp

    Patch 86251-05 For Rapier Switches and AR800 Series Modular Switching Routers Description This command is used to change the configuration parameters of a PPP interface running over: ■ a synchronous port ■ a DS3 port ■ an ISDN call ■...
  • Page 40 SHOW PPP Patch Release Note Patch 86251-05 for Software Release 2.5.1 C613-10356-00 REV F...
