Sharp LC-60C46U Service Manual

Lcd color television
Hide thumbs
Table of Contents

Advertisement

Quick Links

TopPage
SUPPLEMENT ATTACHED
This model is based on the LC-46D62U and is changed some parts. This Service Manual covers the modifications
alone. For the other points, refer to the LC-46/52D62U Service Manual.
LIST OF CHANGED PARTS .................. . ............i
[1]
SPECIFICATIONS ................................. . ....... 1-1
[1]
OPERATION MANUAL .......................... . ....... 2-1
[1]
DIMENSIONS ........................................ . ....... 3-1
[1]
REMOVING OF MAJOR PARTS ........... . ....... 4-1
Parts marked with "
safety and performance of the set.
In the interests of user-safety (Required by safety regulations in some countries) the set should
be restored to its original condition and only parts identical to those specified should be used.
" are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the

SERVICE MANUAL

LCD COLOR TELEVISION

MODEL
OUTLINE
CONTENTS
Parts Guide
LC-60C46U
No. S17B3LC60C46U
LC-60C46U
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LC-60C46U and is the answer not in the manual?

Questions and answers

Willie
January 24, 2025

Unit will not stay on

0
1 comments:
Mr. Anderson
May 14, 2025

Possible reasons why the Sharp LC-60C46U unit will not stay on include:

1. Firmware glitch – A reset by unplugging the unit for a few minutes may help, but if that does not work, the issue may persist due to internal software problems.

2. Power supply failure – The power supply unit (RDENCA184WJQZ) may be faulty and not providing stable power.

3. Overheating – Inadequate ventilation or heat buildup near the top vents can cause the unit to shut down to prevent damage.

4. Faulty main or terminal boards – Components like the MAIN Unit (DUNTKD934FM07) or TERMINAL Unit (DUNTKD935FM07) may be defective.

5. Physical or electrical damage – Internal components or connections could be damaged due to age or external factors.

This answer is automatically generated

0

Related Manuals for Sharp LC-60C46U

Summary of Contents for Sharp LC-60C46U

  • Page 1: Table Of Contents

    TopPage LC-60C46U SUPPLEMENT ATTACHED SERVICE MANUAL No. S17B3LC60C46U LCD COLOR TELEVISION LC-60C46U MODEL In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its original condition and only parts identical to those specified should be used.

  • Page 2: Differences From Base Model

    LC-60C46U LC-60C46U DIFFERENCES FROM BASE MODEL Service Manual LIST OF CHANGED PARTS Ref. No. Description LC-46D62U LC-60C46U Note PWB ASSEMBLIES ← R/C, LED Unit DUNTKD909FM02 — ← KEY Unit DUNTKD910FM02 — MAIN Unit DUNTKD934FM01 DUNTKD934FM07 No Internal parts change TERMINAL Unit...

  • Page 3: Safety Precaution Important Service Safety Pre- Caution

    LC-60C46U LC-60C46U SAFETY PRECAUTION Service Manual IMPORTANT SERVICE SAFETY PRECAUTION Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the servicing guidelines which follow: WARNING • Use an AC voltmeter having with 5000 ohm per volt, or higher, sen- sitivity or measure the AC voltage drop across the resistor.

  • Page 4: Precautions A Prendre Lors De La Reparation

    LC-60C46U PRECAUTIONS A PRENDRE LORS DE LA REPARATION Ne peut effectuer la réparation qu' un technicien spécialisé qui s'est parfaitement accoutumé à toute vérification de sécurité et aux conseils suivants. AVERTISSEMENT • A l'aide de deux fils à pinces, brancher une résistance de 1.5 kΩ...

  • Page 5: Precautions For Using Lead-Free Solder

    LC-60C46U PRECAUTIONS FOR USING LEAD-FREE SOLDER Employing lead-free solder • “PWBs” of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWBs and service manuals. The alphabetical character following LF shows the type of lead-free solder.

  • Page 6: Chapter 1. Specifications

    Emergency alert messages via Cable are unreceivable. As part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units.

  • Page 7: Chapter 2. Operation Manual

    LC-60C46U CHAPTER 2. LC-60C46U OPERATION MANUAL Service Manual [1] OPERATION MANUAL Part names TV (Front) Remote control sensor OPC indicator* OPC sensor* SLEEP indicator** POWER indicator** TV (Rear) Channel buttons INPUT button HDMI terminal (INPUT 5) Volume POWER button buttons...
  • Page 8 LC-60C46U Part names Remote control unit TV POWER: Switch the TV power on or enters standby mode. DISPLAY: Display the channel information. SOURCE POWER: Turns the power of the external equipment on and off. External equipment operational buttons: Operate the external equipment.

  • Page 9: Chapter 3. Dimensions Dimensions

    LC-60C46U CHAPTER 3. LC-60C46U DIMENSIONS Service Manual [1] DIMENSIONS Unit: inch/(mm) (1128) (1021.4) (681) (117) (125) (200) (341) 3 – 1...

  • Page 10: Chapter 4. Removing Of Major Parts

    LC-60C46U CHAPTER 4. LC-60C46U REMOVING OF MAJOR PARTS Service Manual [1] REMOVING OF MAJOR PARTS 1. Detach the SD Card Cover 2. Remove the 4 lock screws and detach the Stand. 3. Remove the 5 lock screws 4. Remove the 13 lock screws and detach the Rear Cabinet.
  • Page 11 LC-60C46U 5. Remove the 12 lock screws and detach the Bridge Angle and Chassis Fix Angle. 6. Remove the 8 lock screws 8 lock point and detach the Stand St Cover-R. 7. Remove the 4 hook and detach the Stand Assist Holder.
  • Page 12 LC-60C46U 10.Disconnect all the connectors from all the PWBs. 11.Remove the 2 lock screws and detach the KEY PWB. Top Cover [KM] KEY PWB [KM] [LB] [PH] [PD] [PD] [PH] [MA][FC] [SA] [LA] [SP] [RA] [LA] [LA] [LB] [LC] [LC] [RA] 4 –...
  • Page 13 LC-60C46U 12.Remove the 1 rivet and detach the earth plate. 13.Remove the 9 lock screws and detach the Tray Chassis. 14.Disconnect the 3 connectors (MA, FC, SA), and COAXIAL Wire. 15.Remove the 2 lock screws , 3 lock screws and detach the Terminal Angle.
  • Page 14 LC-60C46U 22.Remove the 4 lock screws and detach the LCD Panel Module. 23.Remove the 8 lock screws and detach the Chassis Fix Angle T/B. Chassis Fix Angle T/B LCD Panel Module 4 – 5...
  • Page 15 LC-60C46U PartsGuide PARTS GUIDE No. S17B3LC60C46U Note: The reference numbers on the PWB LC-60C46U are arranged in alphabetical order. MODEL CONTENTS PRINTED WIRING BOARD PACKING PARTS (NOT ASSEMBLIES REPLACEMENT ITEM) CABINET AND MECHANICAL SERVICE JIG (USE FOR PARTS SERVICING) SUPPLIED ACCESSORIES Parts marked with "...
  • Page 16 LC-60C46U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [1] PRINTED WIRING BOARD ASSEMBLIES R/C, LED Unit DUNTKD909FM02 KEY Unit DUNTKD910FM02 MAIN Unit DUNTKD934FM07 TERMINAL Unit DUNTKD935FM07 POWER SUPPLY Unit (Unit exchange) RDENCA184WJQZ...
  • Page 17 LC-60C46U [2] CABINET AND MECHANICAL PARTS 1-12 1-10 1-11 19-3 19-3 19-1 19-2 19-1 19-3 19-3 22-2 19-2 22-4 22-3 22-3 22-1 35 28...
  • Page 18 LC-60C46U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [2] CABINET AND MECHANICAL PARTS Front Cabinet Ass'y CCABAB523WJ01 Front Cabinet Not Available Front Cover Not Available LED Cover Not Available Badge, "SHARP" HBDGBA061WJSA Corner Cover, x4 Not Available Punching Net...
  • Page 19 LC-60C46U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [2] CABINET AND MECHANICAL PARTS Support Ass'y, x2 CDAI-A310WJ01 Connecting Cord (for P2003) QCNW-F382WJQZ [3] SUPPLIED ACCESSORIES Cable Band Cable Clamp AC Cord Remote Control Unit Operation Manual "AAA" Size Battery...
  • Page 20 LC-60C46U [4] PACKING PARTS (NOT REPLACEMENT ITEM)
  • Page 21 LC-60C46U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [4] PACKING PARTS (NOT REPLACEMENT ITEM) Packing Case SPAKCD141WJZZ Bottom Case SPAKCD142WJZZ Stand Case SPAKFB058WJZZ Stand Pad SPAKFB061WJZZ Top Pad SPAKFB148WJZZ Wrapping Paper for Monitor SPAKPA711WJZZ Mirror Mat Sup SPAKPA727WJZZ Mirror Mat Base SPAKPA728WJZZ Packing Add.
  • Page 22 LC-60C46U COPYRIGHT 2007 BY SHARP CORPORATION ALL RIGHTS RESERVED. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.
  • Page 23 TopPage LC-46D62U/LC-60C46U SERVICE MANUAL No. S37D1LC46D62U SUPPLEMENT LCD COLOR TELEVISION LC-46D62U LC-46D62U LC-60C46U MODELS LC-60C46U In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its orig- inal condition and only parts identical to those specified should be used.
  • Page 24 OUTLINE AND ADJUSTMENT Service Manual [1] Outline In this Service Manual, only parts in the LCD module are shown. For the other points, refer to the LC-46D62U/LC-60C46U (S86V8LC52D62U/ S17B3LC60C46U) Service Manual. [2] Adjustment When replacing the LCD control PCB, follow these steps to adjust VCOM.
  • Page 25 LC-46D62U/LC-60C46U PartsGuide PARTS GUIDE No. S37D1LC46D62U LCD COLOR TELEVISION LC-46D62U LC-60C46U MODELS LC-46D62U LC-60C46U CONTENTS LCD MODULE Assembly Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the safety and performance of the set.
  • Page 26 LC-46D62U/LC-60C46U [1] LCD MODULE Assembly 27-22 27-21 27-22 27-17 27-14 27-22 27-15 27-14 27-22 27-18 27-19 27-20 27-1 27-16 27-4 27-5 27-5 27-12 27-2 27-3 27-4 27-13 27-5 27-2 27-3 27-4 27-2 27-5 27-4 27-6 27-13...
  • Page 27 LC-46D62U/LC-60C46U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [1] LCD MODULE Assembly LCD Module Ass'y R1LK460D3LZ10Y Frame LHLDZ3351TPXZ Frame LHLDZ3352TPXZ Plate, x2 LHLDZ3364TPXZ Clip, x6 LHLDZ3350TPXZ Clip LHLDZ3363TPXZ Screw, x10 LX-HZ2076TPZZ Screw, x8 LX-BZ2146TPZZ CS-FPC1, x2 QPWBM0327TPZZ CPWBX3520TPXA LCD CONTROL Unit...
  • Page 28 LC-46D62U/LC-60C46U COPYRIGHT © 2007 BY SHARP CORPORATION ALL RIGHTS RESERVED. No Part of this publication may be reproduced, stored in a retrieval system, or transmitted in any from or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.
