NEC Touch-Integrated V Series
46" & 65" touch-integrated, commercial-grade LCD displays
Experience top-of-the-line touchscreen capability
without having to maximize your budget. The
46" V462-TM
and
65" V651-TM
conscious, fully integrated touchscreen solution
for your digital signage and interactive screen
applications. Their integrated 4-camera optical imaging
touch components and double-sided anti-reflective
protective glass, combined with a high-performance
panel and advanced technologies, make these displays
ideal for any multi-touch application. Utilize up to six
simultaneous touches to provide interactivity within the
classroom, exhibit wayfinding in retail environments,
build brand awareness or turn heads during hands-on presentations. The V462-TM and V651-TM also support Open
Pluggable Pluggable Specification (OPS), the first industry-wide standardization in option slots, simplifying installation,
use and maintenance of digital content.
Integrated optical imaging allows for up to six simultaneous touch points*
Four 2-megapixel sensors with a total height of 4mm are embedded into each corner of active area, allowing for an extremely
low-profile touch solution
Infrared light guides are installed along each side of the panel and emit a thin, planar beam of light to fill the sensing region
Double-sided AR Glass is integrated on the panel, protecting the liquid crystal display, while providing high brightness
transmittance and low glass reflectance
Expanded connectivity with built-in expansion slot allows for seamless integration of current and future NEC accessories and
third-party components
Commercial-grade design leads to the displays' extended use for various applications
Public-display-grade panel protects against permanent image retention
Comprehensive input panel, including DisplayPort, HDMI, 5 BNC (RGBHV, DVD/HD, or composite video), DVI-D (in/out),
and 15-pin D-sub in/out, connects you to the latest peripherals
High brightness and contrast ratio help create eye-catching images and crisp, easy-to-read text
Integrated 10W speakers provide stereo audio for those applications requiring sound
Extensive control, diagnostic and communication provide the highest level of remote display management. These include:
· RS-232-enabling multi-display control and daisy chain allows for individual and group-addressable control, and simple,
effective setup and monitoring of the display
· Ethernet connectivity adds the same RS-232 control plus automatic email notification for diagnostic purposes
· NaViSet™ software offers an intuitive graphical interface, allowing for easy adjustment of display settings via mouse and
keyboard. NaViSet Administrator provides all the advanced control to remotely located IT professionals.
· DDC/CI standard allows for PC control of the display based on the VESA command set
Scheduler with round-the-clock feature allows for 7-day scheduling of content and powering of the display
Extensive environment-friendly components contribute to significant energy savings and a lower total cost of ownership
Built-in handles, available with larger-sized models, allow for easier transport and installation
* Dependent upon the operating system in use.
provide a cost-
