Summary of Contents for Electra Accessories U02004 EL 235
-
Page 3: Preface
PREFACE Welcome to your new Electra cooker. Its stylish and practical design will enhance your kitchen and make "cooking electric" a pleasure. Features include a radiant hob for responsive, economical cooking with two large and two small radiant rings, full width grill and a side element heated oven and two removable shelves. -
Page 4: Technical Details
TECHNICAL DETAILS MODEL NO. Voltage: Wattage: Height: Width: Depth: Weight: This appliance complies with: European Council Directive 73/23/EEC. EMC Directive 89/336/EEC. CE Marking Directive 93/68/EEC. EL 235 230/240 Volts AC 50Hz 9.6 / 10.7kW 1240mm 460mm 585mm 51.4kg... -
Page 5: Table Of Contents
CONTENTS Preface ................... 1 Technical Details . -
Page 6: Safety
SAFETY THESE WARNINGS ARE PROVIDED IN THE INTERESTS OF YOUR SAFETY. ENSURE THAT THEM ALL BEFORE INSTALLING OR USING THE COOKER. PLEASE READ CAREFULLY BEFORE INSTALLATION This cooker is heavy and care must be taken when moving it. Ensure that all packaging, both inside and outside the cooker has been removed before the cooker is used. -
Page 7: After Use
Ensure that all vents are left unobstructed to ensure ventilation of the oven cavity. Ensure that the anti-tilt shelves are put in place correctly. Refer to instructions on pages 16. Never line any part of the cooker with aluminium foil. Always stand back from the cooker when opening the oven door to allow any build up of steam or heat to... -
Page 8: Introduction
INTRODUCTION WARNING: THIS COOKER MUST BE EARTHED RATING PLATE Record the model, product and serial numbers inside the back cover of this instruction book from the rating plate. This is situated on the lower front frame of the cooker and can be seen upon opening the oven door. -
Page 9: Reversible Oven Door
REVERSIBLE OVEN DOOR If you require the oven door to be hinged on the opposite side, you will need to contact your local Electricity Company's Service Department. PLEASE NOTE that a charge may be made. GENERAL NOTES ON USING YOUR COOKER We suggest that you run the oven elements for 10 - 15 minutes at 220°C to burn off any residue from... -
Page 10: Getting To Know Your Cooker
GETTING TO KNOW YOUR COOKER THE CONTROL PANEL FEATURES Hotplate Controls Grill Control Oven Indicator Neon Oven Temperature Control Automatic Timer... -
Page 11: The Automatic Timer
THE AUTOMATIC TIMER START TIME SETTING KNOB SECOND HAND CLOCK SYMBOL CLOCK/MINUTE MINDER/LENGTH OF COOKING TIME SETTING KNOB START TIME INDICATOR HOUR HAND DISPLAY WINDOW MANUAL SYMBOL MINUTE HAND 1. TO SET THE TIME OF DAY The clock will operate when the cooker is switched ON at the wall. - Page 12 4. TO CANCEL MINUTE MINDER/BUZZER Turn setting knob (D) clockwise, without pulling it out until "O" or the manual symbol appears in the window (G) as Fig.4. 5. HOW TO SET THE OVEN TIMER When using the oven timer for the very first time, it is advisable to let it operate while you are at home.
- Page 13 B) TO START COOKING NOW, THEN SWITCH OFF AUTOMATICALLY Follow the first 3 points under section 5. (A) above, and then; iv) To set the length of time you want the food to cook; turn setting knob without pulling it out, until the required cooking period can be seen in window (G), e.g.
-
Page 14: The Radiant Hob
THE RADIANT HOB USING THE HOB To operate the hotplates, turn the control knobs clockwise from the OFF position to the required setting. The highest number represents the hottest setting and the lowest number the coolest setting. Choose a setting appropriate to the quantity and type of food to be cooked. -
Page 15: Preserving
1. Preparing the food. Seal the food by coating with flour, egg and breadcrumbs or batter. Do not use a basket with batter coated foods as they will stick. 2. Amount of oil. For safety purposes fill the pan only one-third full of oil. -
Page 16: The Grill
THE GRILL CAUTION - ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS IN USE. CHILDREN SHOULD BE KEPT AWAY. To operate the grill, turn the grill control clockwise from the 'OFF' position to the required setting. The highest number represents the hottest setting and the lowest the coolest setting. -
Page 17: Grilling Chart
When toasting bread use the top runner position. Adjust the grill pan grid to suit. Accompaniments such mushrooms may be placed underneath the grid when grilling meats. Preheat the grill on a full setting for a few minutes before cooking. Adjust the heat setting and runner position as necessary during cooking. -
Page 18: The Oven
THE OVEN SELECTING THE OVEN To operate the oven turn the oven temperature control to the required setting. The oven indicator neon will glow until the oven has reached the required temperature and then go out. It will turn ON and OFF periodically during cooking showing that the temperature is being maintained. - Page 19 Do not place dishes or baking trays directly on the oven floor as it interferes with the oven air circulation and can lead to base burning; use the lower shelf position. However non critical dishes can be placed on the oven base when more space is required.
-
Page 20: Oven Cooking Chart
OVEN COOKING CHART The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the temperature by 10°C to suit individual preferences and requirements. Shelf positions are counted from the bottom of the oven. FOOD Biscuits Flapjacks... -
Page 21: Roasting Chart
ROASTING CHART The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the temperatures by 10° C to suit individual preferences and requirements. The roasting temperatures and times given in the chart should be adequate for most joints, but slight adjustments may be required to allow for personal requirements and the shape and texture of the meat. -
Page 22: Care And Cleaning
CARE AND CLEANING ALWAYS SWITCH OFF THE SUPPLY AT THE MAIN WALL SWITCH AND ALLOW THE COOKER TO COOL BEFORE CLEANING CLEANING MATERIALS Before using any cleaning materials on your cooker, check that they are suitable and that their use is recommended by the manufacturer. -
Page 23: Things To Note
THINGS TO NOTE When operating the cooker at higher temperatures than used in normal cooking the surfaces of the cooker may get hotter than usual. Children should be kept away. HINTS AND TIPS Manual cleaning of the Stayclean coating is not recommended. -
Page 24: Something Not Working
SOMETHING NOT WORKING We strongly recommend that you carry out the following checks on your cooker before calling a Service Engineer. It may be that the problem is a simple one which you can solve yourself without the expense of a Service call. If our Service Engineer finds that the problem is listed below you will be charged for the call whether or not the cooker is under guarantee. -
Page 25: Guarantee
GUARANTEE Your Electra cooker is covered by the terms of your Electricity Company's guarantee for the period of one year. In the event of a defect please contact the Service Department of your local Electricity Company. It is suggested that you record the model number, product number, serial number and date of purchase on the following page. -
Page 26: Service Call Record
SERVICE CALL RECORD How to obtain Remember that you may be charged for a service call (even during the guarantee After Sales Service period) if nothing is found to be wrong with the cooker. So always check the quickly instructions to make sure you have not missed anything. Make a note of your nearest Electricity Company Service Depot and their telephone number here: The receptionist will need the answer to certain questions, so to save you time and... - Page 28 MODEL NO. PART NO. 311493200 EL 235 "...
