Page 3: Preface
PREFACE Welcome to your new Electra cooker. Its stylish and practical design will enhance your kitchen and make "cooking electric" a pleasure. Features include four sealed hotplates, a full width grill, a fan assisted oven for economical cooking and three removable shelves. -
Page 4: Technical Details
TECHNICAL DETAILS MODEL NO. EL305C Voltage: 230/240 Volts AC 50Hz Wattage: 9.8/10.7kW Height: 900mm Width: 500mm Depth: 600mm This appliance complies with: European Council Directive 73/23/EEC. EMC Directive 89/336/EEC. CE Marking Directive 93/68/EEC. -
Page 5: Table Of Contents
CONTENTS Preface ................... 1 Technical Details . - Page 6 CONTENTS Defrosting ..................18 Uses of Defrost Feature .
-
Page 7: Safety
SAFETY THESE WARNINGS ARE PROVIDED IN THE INTERESTS OF YOUR SAFETY. ENSURE THAT THEM ALL BEFORE INSTALLING OR USING THE COOKER. PLEASE READ CAREFULLY BEFORE INSTALLATION This cooker is heavy and care must be taken when moving it. Ensure that all packaging, both inside and outside the cooker has been removed before the appliance is used. -
Page 8: After Use
Always use oven gloves to remove and replace the grill pan handle when grilling. Recommendations given on page 12. Ensure that you support the grill pan when it is in the withdrawn or partially withdrawn position. Ensure that all vents are left unobstructed to ensure ventilation of the oven. -
Page 9: Introduction
INTRODUCTION WARNING: THIS COOKER MUST BE EARTHED RATING PLATE Record the model, product and serial numbers on page 23 from the rating plate. This is situated on the lower front frame of the cooker and can be seen upon opening the fan oven door. The cooker must be protected by a suitably rated fuse or circuit breaker. -
Page 10: Reversible Oven Door
Note: Vapours from the oven vent may in time cause discolouration of wallcoverings behind the cooker. For ease of cleaning it may be preferable to tile behind the cooker. Overhanging surfaces or a cooker hood should be a minimum of 685mm above the hob. It is important to ensure that the appliance is level after installation. -
Page 11: Getting To Know Your Cooker
GETTING TO KNOW YOUR COOKER THE CONTROL PANEL FEATURES Fan Oven Control Fan Oven Indicator Neon Grill Control Hotplate Controls EL305... -
Page 12: The Sealed Hotplates
THE SEALED HOTPLATES BEFORE USING THE HOTPLATES FOR THE FIRST TIME Turn the control knob to a medium/high setting and allow the hotplate to heat uncovered by a saucepan for 3-5 minutes. This hardens the protective coating on the hotplates and makes it more resistant to normal use. A harmless smoke will be given off from the hotplates. -
Page 13: Deep Fat Frying
DEEP FAT FRYING SPECIAL FRYING NOTE: For safety purposes when deep fat frying, fill the pan one-third full of oil, DO NOT cover the pan with a lid and DO NOT leave the pan unattended. unfortunate event of a fire, switch the cooker OFF at the electricity supply and cover the pan with a lid or damp cloth to assist in smothering the flames. -
Page 14: The Grill
THE GRILL USES OF THE GRILL CAUTION - ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS IN USE. CHILDREN SHOULD BE KEPT AWAY. SELECTING THE GRILL To operate the grill open the grill door and turn the grill control in either direction. The highest number represents the hottest setting and the lowest the coolest setting. -
Page 15: Hints And Tips
To correctly locate the grill pan on the shelf, ensure that the cut out on the underside of the handle bracket locates over the front bar of the shelf. To check the progress of the food being grilled, the grill pan should be withdrawn on the shelf to attend to food during cooking or the carrier shelf can be lifted away from the cooker and rested on a heat resistant work surface. -
Page 16: The Fan Oven
THE FAN OVEN USES OF THE FAN OVEN PREHEATING The fan oven quickly reaches its temperature, so it is not usually necessary to preheat the oven. Without preheating however, you may find you need to add an extra 5 - 10 minutes on the recommended cooking times. For recipes needing high temperatures, e.g. -
Page 17: To Fit The Oven Shelves
TO FIT THE OVEN SHELVES The shelves should be fitted with the straight rods uppermost on the frame and the forms towards the back of the oven. If not fitted correctly the anti-tilt and safety stop mechanism will be affected. HINTS AND TIPS Arrange the shelves in the required positions before switching the oven ON. -
Page 18: Oven Cooking Chart
FAN OVEN COOKING CHART The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the temperature by 10° C to suit individual preferences and requirements. FOOD Biscuits Bread Bread rolls/buns Cakes: Small & Queen Sponges Victoria Sandwich Madeira... -
Page 19: Roasting Chart
ROASTING CHART ROASTING CHART INTERNAL TEMPERATURES Rare : 50-60°C; Medium : 60-70°C; Well : 70-80°C MEAT Beef Beef, boned Mutton and Lamb Pork and veal Chicken Turkey and goose Duck Pheasant Rabbit Potatoes with meat Potatoes without meat The roasting temperatures and times given in the chart should be adequate for most joints, but slight adjustments may be required to allow for personal requirements and the shape and texture of the meat. -
Page 20: Defrosting
DEFROSTING USES OF DEFROST FEATURE This fan oven function defrosts most foods faster than more conventional methods. It is particularly suitable for delicate frozen foods which are to be served cold e.g. cream filled gateaux, cakes covered with icings or frostings, cheesecakes, biscuits, scones etc. -
Page 21: Care And Cleaning
CARE AND CLEANING ALWAYS SWITCH OFF THE ELECTRICITY SUPPLY AT THE MAIN WALL SWITCH AND ALLOW THE COOKER TO COOL BEFORE CLEANING CLEANING MATERIALS Before using any cleaning materials on your cooker, check that they are suitable and that their use is recommended by the manufacturer. -
Page 22: Cleaning The Grill, Grill Pan, Grill Pan Grid And Oven Shelves
CLEANING GRILL, GRILL PAN, GRILL PAN GRID AND OVEN SHELVES All removable parts, except the grill pan handle can be washed in the dishwasher. The grill pan may be cleaned using a soap impregnated steel wool pad. The grill pan grid and oven shelves should be cleaned using hot soapy water. -
Page 23: Something Not Working
SOMETHING NOT WORKING? We strongly recommend that you carry out the following checks on your cooker before calling a Service Engineer. It may be that the problem is a simple one which you can solve yourself without the expense of a service call. If our Service Engineer finds that the problem is listed below you will be charged for the call whether or not the cooker is under guarantee. -
Page 24: Guarantee
GUARANTEE Your Electra cooker is covered by the terms of your Electricity Company's guarantee for the period of one year. In the event of a defect please contact the Service Department of your local Electricity Company. It is suggested that you record the model number, product number, serial number and date of purchase on the following page. -
Page 25: Service Call Record
SERVICE CALL RECORD How to obtain Remember that you may be charged for a service call (even during the guarantee After Sales Service period) if nothing is found to be wrong with the cooker. So always check the quickly instructions to make sure you have not missed anything. Make a note of your nearest Electricity Company Service Depot and their telephone number here: The receptionist will need the answer to certain questions, so to save you time and... - Page 26 EL305 311507900...
- Page 28 MODEL NO. PART NO. 311507900 EL 305C "...
