BAS-761
PARTS BOOK
AUTOMATIC POCKET SETTER <JEANS>

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BAS-761 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Brother BAS-761

Summary of Contents for Brother BAS-761

  • Page 1 BAS-761 PARTS BOOK AUTOMATIC POCKET SETTER <JEANS>...

  • Page 2: Table Of Contents

    Notes for using this parts book 1. This book was prepared based on information available in February 1999. 2. Parts are subject to changes in design without prior notice. 3. Parts supplied as complete assemblies are circled by a dotted line CONTENTS Machine body...........

  • Page 3: Machine Body

    A . Machine body 21 40 19 20 40 151-761-050...
  • Page 4 A . Machine body REF.NO. CODE NAME OF PARTS Q'TY S24695109 1 TOP COVER, S 062401016 4 SCREW, PAN M4X10 S24696009 1 TOP COVER, L 062401016 4 SCREW, PAN M4X10 S29885009 1 REAR COVER ASSY 062401216 4 SCREW, PAN M4X12 S24699101 1 THREAD BLOWER S00955001...

  • Page 5: Needle Bar And Thread Take-Up Mechanism

    B . Needle bar and thread take-up mechanism 29 4 32 31 151-761-101...
  • Page 6 B. Needle bar and thread take-up mechanism REF.NO. CODE NAME OF PARTS Q'TY S24701001 1 UPPER SHAFT S11921000 1 BALL BEARING, 6002DDU S11922000 1 BALL BEARING, 6003DDU S24702000 1 BALL BEARING, 6304DDU S24703001 1 BALL BEARING COLLAR 100251001 2 SET SCREW, SM6.35 S11863001 1 BALL BEARING SUPPORT 062401016...

  • Page 7: Zigzag Mechanism

    C . Zigzag mechanism 16 17 19 18 25 30 31 26 30 31 35 38 29 28 51 52 24 23 4 5 3 46 45 44 151-761-110...
  • Page 8 C. Zigzag mechanism REF.NO. CODE NAME OF PARTS Q'TY 183702051 1 REDUCTION GEAR ASSY 141309001 1 REDUCTION GEAR 014770622 2 SET SCREW, SOCKET (CP) SM6.35 S24712001 1 SUB SHAFT S11922000 1 BALL BEARING, 6003DDU S24713001 1 COLLAR, B-BEARING 014770622 2 SET SCREW, SOCKET (CP) SM6.35 183707101 1 AUXILIARY SHAFT GEAR ASSY S38642001...
  • Page 9 C . Zigzag mechanism 16 17 19 18 25 30 31 26 30 31 35 38 29 28 51 52 24 23 4 5 3 46 45 44 151-761-110...
  • Page 10 C. Zigzag mechanism REF.NO. CODE NAME OF PARTS Q'TY S24721000 1 ZIGZAG LEVER SHAFT BUSH, F 158946001 1 ZIGZAG LEVER SHAFT BUSH, R S24722001 1 ZIGZAG CONNCTING SHAFT S24723001 1 SPRING 146581001 1 SET SCREW COLLAR 014760622 2 SET SCREW, SOCKET SM5.95 S24724000 1 ZIGZAG ADJUSTING BAR BUSH, S S24725000...

  • Page 11: Needle Plate Mechanism

    D . Needle plate mechanism 151-761-121...
  • Page 12 D. Needle plate mechanism REF.NO. CODE NAME OF PARTS Q'TY S45703000 1 SLIDE PLATE, L S45704000 1 SLIDE PLATE, RR S45705000 1 SLIDE PLATE, RL 105191003 32 SCREW, SM4.37 S45706000 1 SLIDE PLATE, A S45707000 1 SPACER, D S45708000 1 SLIDE PLATE, B 018400836 4 BOLT, SOCKET M4X8 028040246...

  • Page 13: Presser Foot Mechanism

    E . Presser foot mechanism 40 42 41 151-761-201...
  • Page 14 E. Presser foot mechanism REF.NO. CODE NAME OF PARTS Q'TY 111466101 1 PRESSER BAR 145472001 1 BUSH, PRESSER BAR S31012001 1 ADJUSTING SCREW, PRESSER S31013001 1 ADJUSTING NUT, PRESSER S24740001 1 SPRING GUIDE S24741001 1 SPRING S24742101 1 WORK CLAMP ASSY S24743001 1 WORK CLAMP S24744100...

  • Page 15: F1 . Stacker Mechanism

    F1 . F1 . Stacker mechanism 25 27 26 11 12 2627 33 35 25 27 26 5150 31 30 29 25 26 26 27 26 27 5150 151-761-240...
  • Page 16 F1. Stacker mechanism REF.NO. CODE NAME OF PARTS Q'TY S46233001 1 STACKER BASE 018082536 3 BOLT, SOCKET M8X25 028080246 3 WASHER, SPRING 2-8 025080236 3 WASHER, PLAIN M 8 S46272001 1 SLIDE BAR, STACKER S46273001 1 HOLDER, SLIDE BAR 018062536 2 BOLT, SOCKET M6X25 028060246 2 WASHER, SPRING 2-6...

  • Page 17: F2 . Stacker Mechanism

    F2 . F2 . Stacker mechanism 52 54 68 70 59 60 60 59 151-761-240...
  • Page 18 F2. Stacker mechanism REF.NO. CODE NAME OF PARTS Q'TY S46851000 2 ROLLER S24566000 2 SLEEVE ROLL, 45 014060632 4 SET SCREW, SOCKET (CP) M6X6 S46860001 1 ROLLER SHAFT 076001801 2 BALL BEARING, 6001ZZ 048120142 2 RETAINING RING, C12 S46853001 1 BASE, ROLLER SHAFT 018401036 10 BOLT, SOCKET M4X10 028040246...

  • Page 19: Feed Guide Mechanism

    G . Feed guide mechanism 4 5 6 151-761-243...
  • Page 20 G. Feed guide mechanism REF.NO. CODE NAME OF PARTS Q'TY S46165101 1 FEED BRACKET S46186001 1 SENSOR DOG, A S46193001 1 SENSOR DOG, B 018400836 2 BOLT, SOCKET M4X8 028040246 2 WASHER, SPRING 2-4 025040236 2 WASHER, PLAIN M 4 018401636 8 BOLT, SOCKET M4X16 S46318001...
  • Page 21 G . Feed guide mechanism 4 5 6 151-761-243...
  • Page 22 G. Feed guide mechanism REF.NO. CODE NAME OF PARTS Q'TY S24766001 1 HEAD SUPPORT LEVER 012400436 1 SET SCREW, SOCKET (FT) M4X4 S46186001 2 SENSOR DOG, A S47340001 1 BLOCK, Y-SENSOR DOG 018400836 4 BOLT, SOCKET M4X8 028040246 4 WASHER, SPRING 2-4 025040236 4 WASHER, PLAIN M 4 S12062101...

  • Page 23: Feed Guide Mechanism

    H . Feed guide mechanism -5-8 -5-7 -5-5 -5-2 -8-13 -8-12 -5-1 -12-7 -12-8 -5-6 -8-10 -5-3 -8-2 -5-2 -12-5 -5-4 -12-2 -8-1 -8-11 -8-7 -12-1 -8-8 -12-6 -8-2 -12-3 -8-3 -8-9 -12-2 -12-4 -8-4 -8-6 -8-5 -8-14 -8-16 -8-15 151-761-244...
  • Page 24 H. Feed guide mechanism REF.NO. CODE NAME OF PARTS Q'TY S46164001 1 X-FEED BASE S46194100 2 LINEAR GUIDE, 761-X 018401636 18 BOLT, SOCKET M4X16 028040246 18 WASHER, SPRING 2-4 1-5-1 S46163001 1 PULLEY BRACKET 1-5-2 S46208000 2 BALL BEARING, 6904 1-5-3 S46172001 1 PULLEY SHAFT, B...
  • Page 25 H . Feed guide mechanism -5-8 -5-7 -5-5 -5-2 -8-13 -8-12 -5-1 -12-7 -12-8 -5-6 -8-10 -5-3 -8-2 -5-2 -12-5 -5-4 -12-2 -8-1 -8-11 -8-7 -12-1 -8-8 -12-6 -8-2 -12-3 -8-3 -8-9 -12-2 -12-4 -8-4 -8-6 -8-5 -8-14 -8-16 -8-15 151-761-244...
  • Page 26 H. Feed guide mechanism REF.NO. CODE NAME OF PARTS Q'TY 9-8-9 012060636 2 SET SCREW, SOCKET (FT) M6X6 9-8-10 S46191001 1 SPACER 9-8-11 S46175000 1 KEY, 6X6X43 9-8-12 S46207001 1 PULLEY 9-8-13 012060636 2 SET SCREW, SOCKET (FT) M6X6 9-8-14 S46162001 1 MOTOR BRACKET 9-8-15...

  • Page 27: Thread Breakage Detector Mechanism

    J . Thread breakage detector mechanism 9 10 151-761-219 K . Bottom mechanism 151-761-248...
  • Page 28 J. Thread breakage detector mechanism REF.NO. CODE NAME OF PARTS Q'TY S46713000 1 AMPLIFIER UNIT ASSY 062300616 2 SCREW, PAN M3X6 028030246 2 WASHER, SPRING 2-3 S46716000 1 FIBER UNIT S02657101 1 CORD HOLDER 152937001 1 WASHER 062300616 2 SCREW, PAN M3X6 028030246 2 WASHER, SPRING 2-3 625010000...

  • Page 29: L1 . Folding Margin Mechanism (Option Parts)

    L1 . L1 . Folding margin mechanism (Option parts) -1-9 -1-17 -1-41 -1-30 -1-51-1 -1-51-2 -1-14 -1-42 -1-51-3 -1-31 -1-15 -1-26 -1-2-1 -1-1-3 -1-40 -1-22 -1-2-3 -1-1-4 -1-21 -1-2-4 -1-52-2 -1-1-1 -1-39 -1-7 -1-3 -1-27 -1-1-2 -1-29 -1-8 -1-19 -1-4 -1-6 -1-18 -1-52-1...
  • Page 30 L1. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY S12494000 1 FOLDING CLAMP, SMALL S24888001 1 CONNECTING BLOCK ASSY, R 10-1 S24460001 1 CONNECTING BLOCK, R-1 10-2 S24461001 1 CONNECTING BLOCK, R-2 10-3 018502022 2 BOLT, SOCKET M5X20 10-4 028050242 2 WASHER, SPRING 2-5...
  • Page 31 L1 . L1 . Folding margin mechanism (Option parts) -1-9 -1-17 -1-41 -1-30 -1-51-1 -1-51-2 -1-14 -1-42 -1-51-3 -1-31 -1-15 -1-26 -1-2-1 -1-1-3 -1-40 -1-22 -1-2-3 -1-1-4 -1-21 -1-2-4 -1-52-2 -1-1-1 -1-39 -1-7 -1-3 -1-27 -1-1-2 -1-29 -1-8 -1-19 -1-4 -1-6 -1-18 -1-52-1...
  • Page 32 L1. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY 40-1-24 S12099001 2 KNUCKLE PIN 40-1-25 048050342 4 RETAINING RING, E5 40-1-26 S24787000 1 TUCKING BLADE, RJ 40-1-27 S24788000 1 TUCKING BLADE, LJ 40-1-28 018400632 4 BOLT, SOCKET M4X6 40-1-29 028040242 4 WASHER, SPRING 2-4...
  • Page 33 L1. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY 40-3-3 S37509XXX 1 WORK CLAMP UPPER, L-TRIAN.-J2 40-3-4 145478101 2 SHOULDER SCREW, SOCKET SM4.76 40-3-5 025060136 2 WASHER, PLAIN S 6 40-3-6 S37452000 1 CYLINDER ASSY, 16X45 40-3-6-1 S37453000 1 CYLINDER, 16X45 40-3-6-2...
  • Page 34 L1. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY 40-4-5 S20246001 8 WASHER, PLAIN L 5 40-4-6 S37502XXX 1 INNER CLAMP, TRIANGLE-J2 40-4-7 S37503XXX 1 INNER CLAMP UPPER-1, TRIAN.-J2 40-4-8 S37504XXX 1 INNER CLAMP UPPER-2, TRIAN.-J2 40-4-9 S37505XXX 2 INNER CLAMP UPPER-3, TRIAN.-J2 40-4-10...

  • Page 35: L2 . Folding Margin Mechanism (Option Parts)

    L2 . L2 . Folding margin mechanism (Option parts) -1-30 -1-41 -1-14-9 -1-52-1 -1-52-2 -1-45 -1-52-3 -1-42 -1-14 -1-31 -1-15 -1-22 -1-1-3 -1-2-1 -1-2-3 -1-40 -1-21 -1-1-4 -1-2-4 -1-7 -1-1-1 -1-53-2 -1-27 -1-39 -1-3 -1-8 -1-1-2 -1-29 -1-4 -1-19 -1-6 -1-5 -1-18 -1-53-1...
  • Page 36 L2. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY S12494000 1 FOLDING CLAMP, SMALL S24888001 1 CONNECTING BLOCK ASSY, R 10-1 S24460001 1 CONNECTING BLOCK, R-1 10-2 S24461001 1 CONNECTING BLOCK, R-2 10-3 018502022 2 BOLT, SOCKET M5X20 10-4 028050242 2 WASHER, SPRING 2-5...
  • Page 37 L2 . L2 . Folding margin mechanism (Option parts) -1-30 -1-41 -1-14-9 -1-52-1 -1-52-2 -1-45 -1-52-3 -1-42 -1-14 -1-31 -1-15 -1-22 -1-1-3 -1-2-1 -1-2-3 -1-40 -1-21 -1-1-4 -1-2-4 -1-7 -1-1-1 -1-53-2 -1-27 -1-39 -1-3 -1-8 -1-1-2 -1-29 -1-4 -1-19 -1-6 -1-5 -1-18 -1-53-1...
  • Page 38 L2. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY 41-1-24 S12099001 2 KNUCKLE PIN 41-1-25 048050342 4 RETAINING RING, E5 41-1-26 S24787000 1 TUCKING BLADE, RJ 41-1-27 S24788000 1 TUCKING BLADE, LJ 41-1-28 018400632 4 BOLT, SOCKET M4X6 41-1-29 028040242 4 WASHER, SPRING 2-4...
  • Page 39 L2. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY 41-3-2 S38963XXX 1 WORK CLAMP, UP R-MITER-J2 41-3-3 S38964XXX 1 WORK CLAMP, UP L-MITER-J2 41-3-4 145478101 2 SHOULDER SCREW, SOCKET SM4.76 41-3-5 025060136 2 WASHER, PLAIN S 6 41-3-6 S37452000 1 CYLINDER ASSY, 16X45...
  • Page 40 L2. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY 41-4-4 S12114001 2 CONNECTING PIN, INNER 41-4-5 S20246001 8 WASHER, PLAIN L 5 41-4-6 S38914XXX 1 INNER CLAMP, MITER-J2 41-4-7 S38915XXX 1 INNER CLAMP, UP-1 MITER-J2 41-4-8 S38916XXX 1 INNER CLAMP, UP-2 MITER-J2 41-4-9 S38917XXX...

  • Page 41: L3 . Folding Margin Mechanism (Option Parts)

    L3 . L3 . Folding margin mechanism (Option parts) -1-17 -1-30 -1-41 -1-9 -1-52-1 -1-26 -1-52-2 -1-44 -1-14 -1-52-3 -1-42 -1-31 -1-15 -1-2-1 -1-40 -1-1-3 -1-22 -1-2-3 -1-53-2 -1-1-4 -1-29 -1-21 -1-2-4 -1-1-1 -1-7 -1-39 -1-27 -1-1-2 -1-8 -1-19 -1-3 -1-6 -1-53-1 -1-4...
  • Page 42 L3. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY S12494000 1 FOLDING CLAMP, SMALL S24888001 1 CONNECTING BLOCK ASSY, R 10-1 S24460001 1 CONNECTING BLOCK, R-1 10-2 S24461001 1 CONNECTING BLOCK, R-2 10-3 018502022 2 BOLT, SOCKET M5X20 10-4 028050242 2 WASHER, SPRING 2-5...
  • Page 43 L3 . L3 . Folding margin mechanism (Option parts) -1-17 -1-30 -1-41 -1-9 -1-52-1 -1-26 -1-52-2 -1-44 -1-14 -1-52-3 -1-42 -1-31 -1-15 -1-2-1 -1-40 -1-1-3 -1-22 -1-2-3 -1-53-2 -1-1-4 -1-29 -1-21 -1-2-4 -1-1-1 -1-7 -1-39 -1-27 -1-1-2 -1-8 -1-19 -1-3 -1-6 -1-53-1 -1-4...
  • Page 44 L3. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY 42-1-24 S12099001 2 KNUCKLE PIN 42-1-25 048050342 4 RETAINING RING, E5 42-1-26 S24787000 1 TUCKING BLADE, RJ 42-1-27 S24788000 1 TUCKING BLADE, LJ 42-1-28 018400632 4 BOLT, SOCKET M4X6 42-1-29 028040242 4 WASHER, SPRING 2-4...
  • Page 45 L3. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY 42-3-2 S37482XXX 1 WOEK CLAMP UPPER, R-ROUND-1-J2 42-3-3 S37483XXX 1 WORK CLAMP UPPER, L-ROUND-1-J2 42-3-4 145478101 2 SHOULDER SCREW, SOCKET SM4.76 42-3-5 025060136 2 WASHER, PLAIN S 6 42-3-6 S37452000 1 CYLINDER ASSY, 16X45...
  • Page 46 L3. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY 42-4-4 S12114001 2 CONNECTING PIN, INNER 42-4-5 S20246001 8 WASHER, PLAIN L 5 42-4-6 S37475XXX 1 INNER CLAMP, ROUND-1-J2 42-4-7 S37476XXX 1 INNER CLAMP UP.-1, ROUND-1-J2 42-4-8 S37477XXX 1 INNER CLAMP UP.-2, ROUND-1-J2 42-4-9 S37478XXX...

  • Page 47: L4 . Folding Margin Mechanism (Option Parts)

    L4 . L4 . L4 . Folding margin mechanism (Option parts) L4 . Folding margin mechanism (Option parts) -1-54-1 -1-15 -1-17 -1-9 -1-30 -1-40 -1-54-2 -1-26 -1-54-3 -1-14 -1-41 -1-2-1 -1-31 -1-2-3 -1-22 -1-2-4 -1-1-3 -1-39 -1-21 -1-1-4 -1-45 -1-7 -1-47 -1-19 -1-29...
  • Page 48 L4. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY S12494000 1 FOLDING CLAMP, SMALL S24888001 1 CONNECTING BLOCK ASSY, R 10-1 S24460001 1 CONNECTING BLOCK, R-1 10-2 S24461001 1 CONNECTING BLOCK, R-2 10-3 018502022 2 BOLT, SOCKET M5X20 10-4 028050242 2 WASHER, SPRING 2-5...
  • Page 49 L4 . L4 . Folding margin mechanism (Option parts) -1-54-1 -1-15 -1-17 -1-9 -1-30 -1-40 -1-54-2 -1-26 -1-54-3 -1-14 -1-41 -1-2-1 -1-31 -1-2-3 -1-22 -1-2-4 -1-1-3 -1-39 -1-21 -1-1-4 -1-45 -1-7 -1-47 -1-19 -1-29 -1-27 -1-1-1 -1-58-2 -1-8 -1-32 -1-3 -1-1-2 -1-6 -1-4...
  • Page 50 L4. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY 43-1-24 S12099001 2 KNUCKLE PIN 43-1-25 048050342 4 RETAINING RING, E5 43-1-26 S24787000 1 TUCKING BLADE, RJ 43-1-27 S24788000 1 TUCKING BLADE, LJ 43-1-28 018400632 4 BOLT, SOCKET M4X6 43-1-29 028040242 4 WASHER, SPRING 2-4...
  • Page 51 L4. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY 43-2-9 S38933XXX 1 CENTER BLADE, SQUARE-J2 43-2-10 S38935XXX 1 SPRING, PLATE L-0.8-SQUARE-J2 43-2-11 S24802000 2 CLAMP BLADE, GAUGE 1.6J 43-3 S38970XXX 1 F-GROUP ASSY, SQUARE-J2 43-3-1 S38971XXX 1 WORK CLAMP, LO SQUARE-J2 43-3-2 S38972XXX 1 WORK CLAMP, UP R-SQUARE-J2...
  • Page 52 L4. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY 43-3-50 025040233 1 WASHER, PLAIN M 4 43-4 S38936XXX 1 INNER CLAMP ASSY, SQUARE-J2 43-4-1 S12113001 2 CONNECTING BLOCK, INNER 43-4-2 018502522 8 BOLT, SOCKET M5X25 43-4-3 014500522 4 SET SCREW, SOCKET (CP) M5 43-4-4 S12114001...

  • Page 53: L5 . Folding Margin Mechanism (Option Parts)

    L5 . L5 . L5 . Folding margin mechanism (Option parts) L5 . Folding margin mechanism (Option parts) -1-17 -1-15 -1-45 -1-9 -1-30 -1-26 -1-55-1 -1-55-2 -1-14 -1-56 -1-46 -1-55-3 -1-31 -1-22 -1-2-1 -1-1-3 -1-21 -1-44 -1-2-3 -1-1-4 -1-2-4 -1-19 -1-1-1 -1-3 -1-27...
  • Page 54 L5. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY S12494000 1 FOLDING CLAMP, SMALL S24888001 1 CONNECTING BLOCK ASSY, R 10-1 S24460001 1 CONNECTING BLOCK, R-1 10-2 S24461001 1 CONNECTING BLOCK, R-2 10-3 018502022 2 BOLT, SOCKET M5X20 10-4 028050242 2 WASHER, SPRING 2-5...
  • Page 55 L5 . L5 . Folding margin mechanism (Option parts) -1-17 -1-15 -1-45 -1-9 -1-30 -1-26 -1-55-1 -1-55-2 -1-14 -1-56 -1-46 -1-55-3 -1-31 -1-22 -1-2-1 -1-1-3 -1-21 -1-44 -1-2-3 -1-1-4 -1-2-4 -1-19 -1-1-1 -1-3 -1-27 -1-29 -1-18 -1-1-2 -1-4 -1-28 -1-7 -1-4 -1-47 -1-8...
  • Page 56 L5. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY 44-1-24 S12099001 2 KNUCKLE PIN 44-1-25 048050342 4 RETAINING RING, E5 44-1-26 S24787000 1 TUCKING BLADE, RJ 44-1-27 S24788000 1 TUCKING BLADE, LJ 44-1-28 018400632 4 BOLT, SOCKET M4X6 44-1-29 028040242 4 WASHER, SPRING 2-4...
  • Page 57 L5. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY 44-3-6-2 S11433000 2 HOSE NIPPLE, 4M5 44-3-6-3 S37454000 1 KNUCLE JOINT 44-3-7 S37459000 1 SWITCH SETTING BRACKET, 16 44-3-8 S37450001 1 HINGE PIN, R 44-3-9 S37451001 1 HINGE PIN, L 44-3-10 048040346 2 RETAINING RING, E4...
  • Page 58 L5. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY 44-4-10 S38959XXX 2 INNER CLAMP, UP-4 ROUND-2-J2 44-4-11 018300532 14 BOLT, SOCKET M3X5 44-4-12 028030242 14 WASHER, SPRING 2-3 44-4-13 025030232 14 WASHER, PLAIN M 3 44-4-14 S12117000 1 FORM, 2X200X200 44-4-15 S12487000...

  • Page 59: L6 . Folding Margin Mechanism (Option Parts)

    L6 . L6 . Folding margin mechanism (Option parts) -1-9 -1-17 -1-30 -1-41 -1-51-1 -1-14 -1-26 -1-51-2 -1-15 -1-42 -1-51-3 -1-31 -1-40 -1-2-1 -1-1-3 -1-22 -1-2-3 -1-1-4 -1-21 -1-2-4 -1-52-2 -1-1-1 -1-27 -1-7 -1-1-2 -1-29 -1-39 -1-8 -1-3 -1-19 -1-4 -1-52-1 -1-6 -1-5...
  • Page 60 L6.Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY S43645XXX 1 F-GROUP ASSY, TRIANGLE-J S43646XXX 1 FOLDING CLAMP ASSY, TRIANGLE-J 1-1-1 S24886001 1 CONNECTING BLOCK ASSY, SR 1-1-1-1 S24456001 1 CONNECTING BLOCK, SR-1 1-1-1-2 S24457001 1 CONNECTING BLOCK, SR-2 1-1-1-3 018502022 2 BOLT, SOCKET M5X20...
  • Page 61 L6. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY 1-1-47 062401006 4 SCREW, PAN M4X10 1-1-48 028040243 4 WASHER, SPRING 2-4 1-1-49 028060243 2 WASHER, SPRING 2-6 1-1-50 021060206 2 NUT, 2 M6 1-1-51 S15564000 1 T-ASSY, M5 1-1-51-1 S15563000 1 T-M5...
  • Page 62 L6. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY 062300502 6 SCREW, PAN M3X5 028030242 6 WASHER, SPRING 2-3 S16514000 2 SPACER, 0.05 1-10 S16513000 2 SPACER, 0.1 S12494000 1 FOLDING CLAMP, SMALL S24888001 1 CONNECTING BLOCK ASSY, R 10-1 S24460001 1 CONNECTING BLOCK, R-1...

  • Page 63: L7 . Folding Margin Mechanism (Option Parts)

    L7 . L7 . Folding margin mechanism (Option parts) -1-30 -1-41 -1-9 -1-52-1 -1-17 -1-52-2 -1-14 -1-45 -1-42 -1-52-3 -1-31 -1-26 -1-15 -1-2-1 -1-1-3 -1-40 -1-2-3 -1-22 -1-1-4 -1-2-4 -1-21 -1-1-1 -1-53-2 -1-27 -1-7 -1-1-2 -1-39 -1-8 -1-29 -1-3 -1-19 -1-4 -1-6 -1-53-1...
  • Page 64 L7. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY S43647XXX 1 F-GROUP ASSY, MITER-J S43648XXX 1 FOLDING CLAMP ASSY, MITER-J 2-1-1 S24886001 1 CONNECTING BLOCK ASSY, SR 2-1-1-1 S24456001 1 CONNECTING BLOCK, SR-1 2-1-1-2 S24457001 1 CONNECTING BLOCK, SR-2 2-1-1-3 018502022 2 BOLT, SOCKET M5X20...
  • Page 65 L7. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY 2-1-47 S12294001 2 SETTING PLATE, FOLDING CLAMP 2-1-48 062401006 4 SCREW, PAN M4X10 2-1-49 028040243 4 WASHER, SPRING 2-4 2-1-50 028060243 2 WASHER, SPRING 2-6 2-1-51 021060206 2 NUT, 2 M6 2-1-52 S15564000 1 T-ASSY, M5...
  • Page 66 L7. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY S12111001 3 SLIT, C S12112001 3 SLIT, D 062300502 6 SCREW, PAN M3X5 028030242 6 WASHER, SPRING 2-3 S16514000 2 SPACER, 0.05 2-10 S16513000 2 SPACER, 0.1 S12494000 1 FOLDING CLAMP, SMALL S24888001 1 CONNECTING BLOCK ASSY, R...

  • Page 67: L8 . Folding Margin Mechanism (Option Parts)

    L8 . L8 . Folding margin mechanism (Option parts) -1-9 -1-30 -1-41 -1-52-1 -1-17 -1-52-2 -1-14 -1-44 -1-42 -1-52-3 -1-31 -1-15 -1-2-1 -1-40 -1-26 -1-1-3 -1-22 -1-2-3 -1-1-4 -1-53-2 -1-21 -1-2-4 -1-1-1 -1-29 -1-27 -1-7 -1-1-2 -1-39 -1-8 -1-3 -1-19 -1-4 -1-6 -1-53-1...
  • Page 68 L8. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY S43649XXX 1 F-GROUP ASSY, ROUND-1J S43650XXX 1 FOLDING CLAMP ASSY, ROUND-1J 3-1-1 S24886001 1 CONNECTING BLOCK ASSY, SR 3-1-1-1 S24456001 1 CONNECTING BLOCK, SR-1 3-1-1-2 S24457001 1 CONNECTING BLOCK, SR-2 3-1-1-3 018502022 2 BOLT, SOCKET M5X20...
  • Page 69 L8. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY 3-1-47 062401006 4 SCREW, PAN M4X10 3-1-48 028040243 4 WASHER, SPRING 2-4 3-1-49 028060243 2 WASHER, SPRING 2-6 3-1-50 021060206 2 NUT, 2 M6 3-1-51 S12297000 2 SPONGE, 2-30 3-1-52 S15564000 1 T-ASSY, M5...
  • Page 70 L8. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY 3-4-13 025030232 12 WASHER, PLAIN M 3 3-4-14 S12117000 1 FORM, 2X200X200 3-4-15 S12487000 5 FOLDING BLADE CLAMP, INNER 3-4-16 018300532 10 BOLT, SOCKET M3X5 S12111001 3 SLIT, C S12112001 3 SLIT, D 062300502...

  • Page 71: L9 . Folding Margin Mechanism (Option Parts)

    L9 . L9 . Folding margin mechanism (Option parts) -1-15 -1-30 -1-40 -1-17 -1-9 -1-54-1 -1-26 -1-54-2 -1-14 -1-44 -1-41 -1-54-3 -1-31 -1-2-1 -1-39 -1-1-3 -1-22 -1-2-3 -1-1-4 -1-45 -1-2-4 -1-21 -1-1-1 -1-32 -1-27 -1-58-2 -1-7 -1-1-2 -1-38 -1-8 -1-3 -1-19 -1-29 -1-58-1...
  • Page 72 L9. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY S43651XXX 1 F-GROUP ASSY, SQUARE-J S43652XXX 1 FOLDING CLAMP ASSY, SQUARE-J 4-1-1 S24886001 1 CONNECTING BLOCK ASSY, SR 4-1-1-1 S24456001 1 CONNECTING BLOCK, SR-1 4-1-1-2 S24457001 1 CONNECTING BLOCK, SR-2 4-1-1-3 018502022 2 BOLT, SOCKET M5X20...
  • Page 73 L9. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY 4-1-47 S24857XXX 1 FOLDING BLADE, LD-SQUARE-J 4-1-48 S12291001 2 ADJUSTING SCREW 4-1-49 S12294001 2 SETTING PLATE, FOLDING CLAMP 4-1-50 062401006 4 SCREW, PAN M4X10 4-1-51 028040243 4 WASHER, SPRING 2-4 4-1-52 028060243 2 WASHER, SPRING 2-6...
  • Page 74 L9.Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY 4-4-12 025030232 10 WASHER, PLAIN M 3 4-4-13 S12117000 1 FORM, 2X200X200 4-4-14 S12487000 3 FOLDING BLADE CLAMP, INNER 4-4-15 018300532 6 BOLT, SOCKET M3X5 S12111001 3 SLIT, C S12112001 3 SLIT, D 062300502...

  • Page 75: L10 . Folding Margin Mechanism

    L10 . L10 . Folding margin mechanism (Option parts) -1-15 -1-30 -1-45 -1-9 -1-55-1 -1-17 -1-55-2 -1-14 -1-56 -1-46 -1-55-3 -1-31 -1-2-1 -1-1-3 -1-44 -1-22 -1-2-3 -1-1-4 -1-26 -1-2-4 -1-21 -1-1-1 -1-27 -1-7 -1-1-2 -1-40 -1-19 -1-29 -1-8 -1-3 -1-18 -1-6 -1-4 -1-5...
  • Page 76 L10. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY S24833XXX 1 F-GROUP ASSY, ROUND-2J S24834XXX 1 FOLDING CLAMP ASSY, ROUND-2J 5-1-1 S24886001 1 CONNECTING BLOCK ASSY, SR 5-1-1-1 S24456001 1 CONNECTING BLOCK, SR-1 5-1-1-2 S24457001 1 CONNECTING BLOCK, SR-2 5-1-1-3 018502022 2 BOLT, SOCKET M5X20...
  • Page 77 L10. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY 5-1-45 S12205000 1 AIR TUBE, 4X2.5-29 5-1-46 S12104000 10 UNION, Y4 5-1-47 S24840XXX 1 FOLDING CLAMP, ROUND-2J 5-1-48 S12291001 2 ADJUSTING SCREW 5-1-49 S12294001 2 SETTING PLATE, FOLDING CLAMP 5-1-50 062401006 4 SCREW, PAN M4X10...
  • Page 78 L10. Folding margin mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY S12494000 1 FOLDING CLAMP, SMALL S24888001 1 CONNECTING BLOCK ASSY, R 10-1 S24460001 1 CONNECTING BLOCK, R-1 10-2 S24461001 1 CONNECTING BLOCK, R-2 10-3 018502022 2 BOLT, SOCKET M5X20 10-4 028050242 2 WASHER, SPRING 2-5...

  • Page 79: Folding Margin Base Mechanism

    M . Folding margin base mechanism 46 47 72 71 151-761-260...
  • Page 80 M. Folding margin base mechanism REF.NO. CODE NAME OF PARTS Q'TY S15532009 1 HINGE BASE S12119001 2 PIN 028080246 4 WASHER, SPRING 2-8 018082536 4 BOLT, SOCKET M8X25 S45682001 1 FOLDING BASE S15530001 1 SHAFT S15531001 1 COLLAR S12123000 2 BALL BEARING, ANGULAR 2 S04782000 1 NUT, U SS-AN02 S45683001...
  • Page 81 M . Folding margin base mechanism 46 47 72 71 151-761-260...
  • Page 82 M. Folding margin base mechanism REF.NO. CODE NAME OF PARTS Q'TY S45694000 1 CYLINDER ASSY, 20X335 44-1 S46249000 1 CYLINDER, 20X335 44-2 S45693000 2 ELBOW, M-5HL-6 S45695001 1 CYLINDER HOLDER, A 018501236 2 BOLT, SOCKET M5X12 028050246 2 WASHER, SPRING 2-5 S45696001 1 CENTER BLADE SUPPORT S12152001...

  • Page 83: Rotary Hook Mechanism

    N . Rotary hook mechanism 151-761-301...
  • Page 84 N.Rotary hook mechanism REF.NO. CODE NAME OF PARTS Q'TY 159745100 1 TIMING PULLEY ASSY, D 014760622 4 SET SCREW, SOCKET SM5.95 S24901001 1 LOWER SHAFT S11921000 1 BALL BEARING, 6002DDU 072620260 1 BALL BEARING, 6202VVC2 048350242 1 RETAINING RING, C35 S11893001 1 HOLDER, B-BEARING 062401016...

  • Page 85: Lubrication

    P . Lubrication 29 30 34 35 58 63 59 61 60 151-761-350...
  • Page 86 P. Lubrication REF.NO. CODE NAME OF PARTS Q'TY S46229000 1 PACKING, FACE PLATE S24910000 1 PACKING, TOP COVER S24911100 1 PACKING, REAR COVER S24912000 1 SUCTION FELT ASSY S24915101 1 SUCTION FELT SUPPORT 062670612 1 SCREW, PAN SM3.57-40X6 S24916000 1 OIL TUBE, 4X6 L=680 142268001 1 CORD HOLDER, L 140647101...
  • Page 87 P . Lubrication 29 30 34 35 58 63 59 61 60 151-761-350...
  • Page 88 P. Lubrication REF.NO. CODE NAME OF PARTS Q'TY S45668001 1 BUSH 081025870 1 O RING, S25 144875001 1 PLUNGER S43405101 1 CAP SCREW ASSY, PUMP 103-1 S25380401 1 CAP SCREW, PUMP 103-2 144876001 1 SPRING, COMPRESSION S38735001 1 OIL FEEDING PIPE S49040001 1 OIL TANK SET 105-1...

  • Page 89: Threading Mechanism

    Q . Threading mechanism 35 34 39 40 11 10 151-761-401...
  • Page 90 Q. Threading mechanism REF.NO. CODE NAME OF PARTS Q'TY 147557101 1 SPOOL PIN S24927101 1 THREAD TENSION ASSY 146924000 2 THREAD BUSH 145446001 2 DISC, TENSION 159805001 1 DISC PRESSER, TENSION 148851001 1 TENSION SPRING 144105000 1 FLANGE WASHER, TENSION SPRING S11182009 1 TENSION NUT ASSY S11183009...

  • Page 91: Bobbin Winder Mechanism

    R . Bobbin winder mechanism V1 1-3 P2 151-761-402...
  • Page 92 R. Bobbin winder mechanism REF.NO. CODE NAME OF PARTS Q'TY S39902001 1 B-WINDER MOTOR SUPPORT PLATE 062300606 4 SCREW, PAN M3X6 S39848001 1 MOTOR ASSY, B-WINDE S35032101 2 SCREW, M2.6X5.5 028260242 2 WASHER, SPRING 2-2.6 S46592000 1 HARNESS, B-WINDER S39901001 1 SHAFT, B-WINDER 014300332 2 SET SCREW, SOCKET (CP) M3X3...

  • Page 93: Thread Trimmer Mechanism

    S . Thread trimmer mechanism 36 35 151-761-403...
  • Page 94 S.Thread trimmer mechanism REF.NO. CODE NAME OF PARTS Q'TY S00337021 1 THREAD TRIMMER CAM 154567000 2 SPACER, 5.3 014771022 2 SET SCREW, SOCKET (CP) SM6.35 159540001 1 FIXED KNIFE 102843004 1 SCREW, FLAT SM3.57 103978002 1 SET SCREW, SM3.18 S45671001 1 THREAD RETAINER 100645003 1 WASHER...

  • Page 95: Manual Switch Mechanism

    T . Manual switch mechanism " / OPTION PARTS " -1-13 -2-13 -1-1 -2-1 -1-2 -2-2 -1-9 -2-9 -1-3 -2-3 -1-4 -2-4 -1-5 -2-5 -1-12 -2-12 -1-10 -2-10 -1-12 -2-12 -1-11 -2-11 -1-8 -2-8 -1-6 -2-6 -1-7 -2-7 -1-14 -2-14 151-761-509...
  • Page 96 T. Manual switch mechanism REF.NO. CODE NAME OF PARTS Q'TY S46697001 1 SWITCH BOX ASSY 1-1-1 S46698001 1 SWITCH COVER, A 1-1-2 S11750100 1 SWITCH, :ABS310N ......<Yellow> 1-1-3 S11706100 1 SWITCH, :ABS110N ......<Green> 1-1-4 S11706101 1 SWITCH, :ABS110N ......<Blue> 1-1-5 S38866100 1 SWITCH, :ABS311N ......

  • Page 97: U1 . Air Pressure Mechanism

    U1 . U1 . Air presure mechanism 22-4 130 131 128 129 126 127 124 125 122 123 119 121 115 116 140 141 138 139 136 137 134 135 56-2 26-2 32-2 22-3 151-761-514...
  • Page 98 U1.Air pressure mechanism REF.NO. CODE NAME OF PARTS Q'TY S49141001 1 VALVE ASSY, 9 S49142000 1 MANIFOLD, 9 S12158000 4 VALVE, VZ3243-N S12160000 5 VALVE, VZ3153-N S04896000 3 ELBOW UNION, 1 140682001 1 SILENCER S49152000 1 PT-ELBOW S49143001 1 VALVE ASSY, 7 S49144000 1 MANIFOLD, 7 S12161000...
  • Page 99 U1 . U1 . Air presure mechanism 22-4 130 131 128 129 126 127 124 125 122 123 119 121 115 116 140 141 138 139 136 137 134 135 56-2 26-2 32-2 22-3 151-761-514...
  • Page 100 U1. Air pressure mechanism REF.NO. CODE NAME OF PARTS Q'TY S32129000 1 AIR TUBE, 6 L=1350 S31765000 1 AIR TUBE, 6 L=230 S46255000 1 AIR TUBE, 6 L=680 S28677000 1 AIR TUBE, 6 L=1000 S31155000 1 AIR TUBE, L=400 S46254000 1 AIR TUBE, 6 L=590 S28474000 1 AIR TUBE, 6 L=480...
  • Page 101 U2 . U2 . Air presure mechanism 22 26 19A 19B 20A 20B 21A 21B 22A 22B 23A 23B 24A 24B 25A 25B 26A 26B 25 24 27A 27B 28A 28B 15-1 14-4 -1-1 58 57 55 54 151-761-514...

  • Page 102: U2. Air Pressure Mechanism

    U2. Air pressure mechanism REF.NO. CODE NAME OF PARTS Q'TY S49145001 1 VALVE ASSY, 10 S49146000 1 MANIFOLD, 10 S12161000 5 VALVE, VZ3143 S12160000 4 VALVE, VZ3153-N S01542000 1 ELBOW UNION, 61 140682001 1 SILENCER S12159000 1 BLANKING PLATE ASSY 018503036 2 BOLT, SOCKET M5X30 028050246...
  • Page 103 U2 . U2 . Air presure mechanism 22 26 19A 19B 20A 20B 21A 21B 22A 22B 23A 23B 24A 24B 25A 25B 26A 26B 25 24 27A 27B 28A 28B 15-1 14-4 -1-1 58 57 55 54 151-761-514...
  • Page 104 U2. Air pressure mechanism REF.NO. CODE NAME OF PARTS Q'TY 062301606 1 SCREW, PAN M3X16 028030246 1 WASHER, SPRING 2-3 021300206 1 NUT, 2 M3 S14328000 1 THROTTLE VALVE S12104000 2 UNION, Y4 018403036 1 BOLT, SOCKET M4X30 028040246 1 WASHER, SPRING 2-4 S19554000 1 MULTI CONNECTOR ASSY, 6P 70-1...

  • Page 105: V1 . Power Supply Equipment Mechanism

    V1 . V1 . Power supply equipment mechanism 21 23 -3-2 -3-1 151-761-515...
  • Page 106 V1. Power supply equipment mechanism REF.NO. CODE NAME OF PARTS Q'TY S46596001 1 POWER SUPPLY UNIT ASSY S46738000 1 POWER SUPPLY, SWITCHING 0A5300805 2 SCREW, PAN (S/P WASHER) M3X8 S46599001 1 POWER SUPPLY PCB ASSY 1-3-1 152565000 3 FUSE, B 5A 1-3-2 152566000 1 FUSE, C 2A...

  • Page 107: V2 . Power Supply Equipment Mechanism

    V2 . V2 . Power supply equipment mechanism Head 151-761-515...
  • Page 108 V2. Power supply equipment mechanism REF.NO. CODE NAME OF PARTS Q'TY S31319000 1 CIRCUIT PROTECTOR, 5A 0A4300606 2 SCREW, PAN (S/P WASHER) M3X6 S46638000 1 HARNESS, T1-PROTECTOR S46639000 1 HARNESS, PROTECTOR-MOTOR S46694000 1 CORD BUSH, KR61A S46640000 1 GROUND WIRE S43224000 1 FDD, 3.5 0A5300805...

  • Page 109: Printed Circuit Board Mechanism

    W . Printed circuit board mechanism P 2 7 P 2 4 P 2 8 P 3 0 P 2 5 P 2 9 P 2 6 P 2 3 P 2 2 P 2 1 151-761-518 X . Marker mechanism (Option parts) V 1-3 P9 151-761-521...
  • Page 110 W. Printed circuit board mechanism REF.NO. CODE NAME OF PARTS Q'TY S46658001 1 MAIN PCB ASSY S46678000 1 PROM, 761 MAIN S46679000 1 PROM, 761 F-GROUP 151-761-518 X. Marker mechanism (Option parts) REF.NO. CODE NAME OF PARTS Q'TY S27937000 2 MARKING LIGHT ASSY, T S24958001 2 MARKER SETTER, RIGHT 018502036...

  • Page 111: Motor Mechanism

    Y . Motor mechanism 17 19 20 18 151-761-650...
  • Page 112 Y.Motor mechanism REF.NO. CODE NAME OF PARTS Q'TY S46629000 1 SERVO MOTOR, 400W 018062036 4 BOLT, SOCKET M6X20 028060246 4 WASHER, SPRING 2-6 S45673001 1 MOTTOR BRACKET, DD 018062536 3 BOLT, SOCKET M6X25 028060246 3 WASHER, SPRING 2-6 S24960009 1 PULLEY COVER 062400816 2 SCREW, PAN M4X8 028040246...

  • Page 113: Aa . Operation Panel Mechanism

    AA . AA . Operation panel mechanism 12 13 151-761-530 AB . 151-761-530 AB . Foot switch pedal mechanism 151-761-651...
  • Page 114 AA.Operation panel mechanism REF.NO. CODE NAME OF PARTS Q'TY S46681001 1 OPERATION PANEL COVER ASSY S46196101 1 PANEL COVER S40448000 1 INVERTER 0A4300605 3 SCREW, PAN (S/P WASHER) M3X6 S45176001 1 PLATE S40447000 1 LCD MODULE S46833001 4 SCREW, PAN M1.6X4 S46682000 1 SWITCH SHEET S46197101...

  • Page 115: Ac1 . Power Table

    AC1 . AC1 . Power table 151-761-652...
  • Page 116 AC1. Power table REF.NO. CODE NAME OF PARTS Q'TY S24777100 8 ADJUSTING SCREW, 20 S40883000 4 CASTER, 100 S12235009 1 TOOL BOX 018400836 4 BOLT, SOCKET M4X8 028040246 4 WASHER, SPRING 2-4 S46168001 1 BASE, F-BRACKET 018081636 6 BOLT, SOCKET M8X16 028080246 6 WASHER, SPRING 2-8 S15547009...

  • Page 117: Ac2 . Power Table

    AC2 . AC2 . Power table / Motorgestell 85 153 43 44 155 156 150 104 151-761-652...
  • Page 118 AC2. Power table REF.NO. CODE NAME OF PARTS Q'TY S46204001 1 SUB FRAME, A S46205001 1 SUB FRAME, B S46206101 1 SUB FRAME, C 018081236 8 BOLT, SOCKET M8X12 028080246 8 WASHER, SPRING 2-8 S47344001 1 GUARD BAR 018502536 2 BOLT, SOCKET M5X25 028050246 2 WASHER, SPRING 2-5 S12216001...
  • Page 119 AC2 . AC2 . Power table / Motorgestell 85 153 43 44 155 156 150 104 151-761-652...
  • Page 120 AC2. Power table REF.NO. CODE NAME OF PARTS Q'TY 018300836 4 BOLT, SOCKET M3X8 028030246 4 WASHER, SPRING 2-3 025030236 4 WASHER, PLAIN M 3 S46652000 1 HARNESS, CLAMP-IN S39819000 24 CORD CLAMP, 1259 S39821000 4 CORD CLAMP, 19P7 S09141000 4 CORD CLAMP, 16-L S09142000 1 CORD CLAMP, 20-L...

  • Page 121: Ad1 . Attachment Set (Option Parts)

    AD1 . AD1 . Attachment set (Option parts) 151-761-940...
  • Page 122 AD1.Attachment set (Option parts) REF.NO. CODE NAME OF PARTS Q'TY S47646XXX 1 F-GROUP SUPPLY ASSY, 761 MI-2J S43653XXX 1 F-GROUP ASSY, TRIANGLE-J2 S46702000 1 SENSOR HARNESS, B RETRACTABLE S43273000 1 3.5 MEDIA, 2HD S09989000 1 FLOPPY CASE S42658000 1 INDEX LABEL, 3.5FD S47647XXX 1 F-GROUP SUPPLY ASSY, 761 MI-J2 S43655XXX...
  • Page 123 AD1 . AD1 . Attachment set (Option parts) 151-761-940...
  • Page 124 AD1.Attachment set (Option parts) REF.NO. CODE NAME OF PARTS Q'TY S12112001 3 SLIT, D 062300502 6 SCREW, PAN M3X5 028030242 6 WASHER, SPRING 2-3 S46702000 1 SENSOR HARNESS, B RETRACTABLE S48389XXX 1 F-GROUP SUPPLY ASSY, 761 SQ-J2 S38970XXX 1 F-GROUP ASSY, SQUARE-J2 S12111001 3 SLIT, C S12112001...

  • Page 125: Ad2 . Attachment Set (Option Parts)

    AD2 . AD2 . Attachment set (Option parts) -1-14 -1-13 -1-10 -1-11 -1-12 -1-23 -1-12 -1-5 -1-6 -1-7 -1-8 -1-22-1 -1-22-2 -1-18 -1-16 -1-15 -1-19 -1-2 -1-17 -1-4 -1-3 -1-21 -1-20 -1-1 -1-9 151-761-940...
  • Page 126 AD2. Attachment set (Option parts) REF.NO. CODE NAME OF PARTS Q'TY <Attaching the label for right-hand> S25025201 1 LABELING DEVICE, A S25026201 1 LABELING ASSY 1-1-1 S25027001 1 SUPPORT PLATE 1-1-2 018400832 2 BOLT, SOCKET M4X8 1-1-3 025040232 2 WASHER, PLAIN M 4 1-1-4 028040242 2 WASHER, SPRING 2-4...

  • Page 127: Ad3 . Attachment Set (Option Parts)

    AD3 . AD3 . Attachment set (Option parts) -1-14 -1-23 -1-13 -1-10 -1-11 -1-12 -1-6 -1-12 -1-5 -1-7 -1-8 -1-22-1 -1-22-2 -1-16 -1-15 -1-19 -1-18 -1-2 -1-17 -1-4 -1-3 -1-21 -1-9 -1-20 -1-1 151-761-940...
  • Page 128 AD3. Attachment set (Option parts) REF.NO. CODE NAME OF PARTS Q'TY <Attaching the label for left-hand> S25047201 1 LABELING DEVICE, B S25026201 1 LABELING ASSY 2-1-1 S25027001 1 SUPPORT PLATE 2-1-2 018400832 2 BOLT, SOCKET M4X8 2-1-3 025040232 2 WASHER, PLAIN M 4 2-1-4 028040242 2 WASHER, SPRING 2-4...

  • Page 129: Ad4 . Attachment Set (Option Parts)

    AD4 . AD4 . Attachment set (Option parts) -1-14 -1-13 -1-10 -1-11 -1-12 -1-23 -1-12 -1-5 -1-6 -1-7 -1-8 -1-22-1 -1-22-2 -1-18 -1-16 -1-15 -1-19 -1-2 -1-17 -1-4 -1-3 -1-21 -1-20 -1-1 -1-9 151-761-940...
  • Page 130 AD4. Attachment set (Option parts) REF.NO. CODE NAME OF PARTS Q'TY <Attaching the label for right-hand> S31971201 1 LABELING ASSY, A S25026201 1 LABELING ASSY 3-1-1 S25027001 1 SUPPORT PLATE 3-1-2 018400832 2 BOLT, SOCKET M4X8 3-1-3 025040232 2 WASHER, PLAIN M 4 3-1-4 028040242 2 WASHER, SPRING 2-4...

  • Page 131: Ad5 . Attachment Set (Option Parts)

    AD5 . AD5 . Attachment set (Option parts) -1-14 -1-23 -1-13 -1-10 -1-11 -1-12 -1-6 -1-12 -1-5 -1-7 -1-8 -1-22-1 -1-22-2 -1-16 -1-15 -1-19 -1-18 -1-2 -1-17 -1-4 -1-3 -1-21 -1-9 -1-20 -1-1 151-761-940...
  • Page 132 AD5. Attachment set (Option parts) REF.NO. CODE NAME OF PARTS Q'TY <Attaching the label for left-hand> S31972201 1 LABELING ASSY, B S25026201 1 LABELING ASSY 4-1-1 S25027001 1 SUPPORT PLATE 4-1-2 018400832 2 BOLT, SOCKET M4X8 4-1-3 025040232 2 WASHER, PLAIN M 4 4-1-4 028040242 2 WASHER, SPRING 2-4...

  • Page 133: Ad6 . Attachment Set (Option Parts)

    AD6 . AD6 . Attachment set (Option parts) 151-761-940...
  • Page 134 AD6.Attachment set (Option parts) REF.NO. CODE NAME OF PARTS Q'TY S47641XXX 1 F-GROUP SUPPLY ASSY, 761 TRI-J S43645XXX 1 F-GROUP ASSY, TRIANGLE-J S43273000 1 3.5 MEDIA, 2HD S09989000 1 FLOPPY CASE S42658000 1 INDEX LABEL, 3.5FD S47642XXX 1 F-GROUP SUPPLY ASSY, 761 MIT-J S43647XXX 1 F-GROUP ASSY, MITER-J S43273000...

  • Page 135: Ae . Programmer

    AE . AE . Programmer 151-761-942 AF . AF . AF . Attachment set (Option parts) -7-2 -7-1 151-761-944...
  • Page 136 AE. Programmer REF.NO. CODE NAME OF PARTS Q'TY S43249001 1 PROGRAMMER ASSY S43250000 1 TOP COVER, PROGRAMMER S43251000 1 LOWER COVER, PROGRAMMER S43252000 1 SPACER, KEYBOARD S43253000 1 RUBBER SHEET, KEYBOARD S43254000 1 KEYBOARD SHEET 037301015 4 TAPPING SCREW, PAN V M3X10 S43255000 1 LCD COVER S43256000...

  • Page 137: Accessories

    Z . Accessories -5-1 -11-1 -10-2 -10-3 -11-2 -4-5 -10-1 -11-1 -8-1 -11-4 -11-1 -11-3 -8-2 -4-4 -8-3 -4-1 -4-2 -4-3 151-761-910...
  • Page 138 Z. Accessories REF.NO. CODE NAME OF PARTS Q'TY 122991001 1 ACCESSORY BAG 142443001 1 SCREW DRIVER, 1.9X52 118837001 1 SCREW DRIVER, 3.4X70 101572101 1 SCREW DRIVER, 5.5X190 149173001 1 SCREW DRIVER, HEXAGONAL 3 150332001 1 SCREW, DRIVER, 2X100 S46264000 1 SCREW DRIVER, STUBBIES 2X38 100887001 1 WRENCH, 8X9 107780001...
  • Page 139 Z . Accessories -5-1 -11-1 -10-2 -10-3 -11-2 -4-5 -10-1 -11-1 -8-1 -11-4 -11-1 -11-3 -8-2 -4-4 -8-3 -4-1 -4-2 -4-3 151-761-910...
  • Page 140 Z. Accessories REF.NO. CODE NAME OF PARTS Q'TY S12116000 1 SPONGE, 3X200X200 S12117000 1 FORM, 2X200X200 S11959001 1 LOWER THREAD GUIDE 150145009 1 THREAD GUIDE HOLDER ASSY 22-1 021500106 1 NUT, 1 M5 22-2 150185009 1 THREAD GUIDE HOLDER 22-3 S37037001 1 SCREW, PAN (S/P WASHER) M5X32 S24982000...

  • Page 141: Warning Labels

    Wa. Warning labels Size (mm) Code / Warning labels / Name of Parts S38353-101 40X64 Hazardous voltage Hochspannung Un voltage non adapté Un voltaje inadecuado will cause injury. verletzungsgefahr! provoque des blessures. puede provocar las S38352-101 Label, elec. shock 4 lang. 35X118 heridas.

  • Page 142: Index

    PARTS BOOK BROTHER INDUSTRIES,LTD. Printed in Japan 151-761 S98761-001 1999.02. F (1)

Table of Contents
