Garmin GPSMAP 720 Template

These instructions for printing a mounting template must be followed precisely. Failure to do so may result in incorrect dimensions on the
template and an incorrect cutout (too large or too small) on the mounting surface of your boat.
To print the attached mounting template, check the dimensions of the template and select the appropriate size of paper. Both the length and
width measurements are indicated on the template.
The paper size must be larger than the dimensions of the template. Select the paper size using the Properties button in the Adobe Acrobat print
dialog box.
Select Auto-Rotate and Center to ensure the template prints in the correct orientation.
ImPoRtAnt: When printing the flush mount template, set Page Scaling in the Adobe Acrobat print dialog box to none.
Page Scaling:
Select None:
Auto-Rotate and Center:
Select with a check mark
for correct orientation
After printing and before cutting the mounting surface, measure the printed template to ensure both the length and the width printed at the
correct size and to ensure that the dimensions of the printed template match the actual size of your mount. Garmin is not responsible for any
damages or expenses resulting from a miscut mounting surface arising from a failure to follow these instructions.

Printing a Mounting Template

Notice
Notice
Properties: Select
the paper size.
Paper size (example):
Use appropriate size paper.
