KG200 cover(4)_1109
2006.11.10 3:18 PM
˘
` 1
Service Manual
KG200
Date: November, 2006 / Issue 1.0

Advertisement

Table of Contents
loading

Related Manuals for LG KG200 - Cell Phone 60 MB

Summary of Contents for LG KG200 - Cell Phone 60 MB

  • Page 1 KG200 cover(4)_1109 2006.11.10 3:18 PM ˘ Service Manual KG200 Date: November, 2006 / Issue 1.0...

  • Page 2: Table Of Contents

    Contents 1. Introduction and Specification ..........5 2. Software Download Procedure..........11 3. Assembly and Disassembly ...........18 4. Troubleshooting...............22 5. CIRCUIT DIAGRAMS..............55 6. PCB LAYOUT................71 7. EXPLODED VIEW & REPLACEMENT PART LIST....73 - 3 -...
  • Page 3 - 4 -...

  • Page 4: Introduction And Specification

    1. INTRODUCTION 1. INTRODUCTION 1.1 Unit SPECIFICATION 7330 Sep/ M, 2006 Solution 6226M Type Bar type Antenna Type Internal( tri-Band) Main Display 1,8" 128x160 GPRS Yes, Class 10 Yes, 1.1 Camera Change to 1.3 M Battery 800 mAh Audio player--real resuming FM Receiver MPEG4/H.263 H.264...
  • Page 5 1. INTRODUCTION Video recording Memory Size 128Mb flash + 32Mb Ram Internal NAND 64MB Memory Card MicroSD Bluetooth Yes, slave 1.1 IrMC Yes, 2.0 Java EMAIL Status LED with one color No, OMA 1.0 Dictionary MPEG4 caller ID Finger handwriting Touch Panel AB repeat Music Equalizer...
  • Page 6 1. INTRODUCTION 1.2 PERFORMANCE PRODUCT SPECIFICATION NAME SPECIFICATION EGSM900 Band TX: 890+n*0.2 MHz RX: 935+n*0.2 MHz (n= 0~124) TX: 890+(n-1024)*0.2 MHz RX: 935+(n-1024)*0.2 MHz (n= 975~1023) Frequency Band DCS1800 Band TX: 1710+(n-512)*0.2 MHz RX: 1805+(n-512)*0.2 MHz (n= 512~885) PCS1900 Band TX: 1850.2+(n-512)*0.2 MHz RX: 1930.2+(n-512)*0.2 MHz (n= 512~810) RMS <...
  • Page 7 1. INTRODUCTION Transmit Power EGSM900 Control Level Power Level Tolerance 5(high) 33 dBm 31 dBm 29 dBm 27 dBm 25 dBm 23 dBm 21 dBm 19 dBm 17 dBm 15 dBm 13 dBm 11 dBm 9 dBm 7 dBm 19(low) 5 dBm DCS1800/PCS1900 Control Level...
  • Page 8 1. INTRODUCTION Item Description Specification EGSM900 OFFSET from Carrier (KHz) Max. (dBm) +0.5 600~ < 1,200 1,200~ < 1,800 1,800~ < 3,000 3,000~ < 6,000 Spectrum due to modulation ≥ 6,000 DCS1800/PCS1900 OFFSET from Carrier (KHz) Max. (dBm) +0.5 600~ < 1,200 1,200~ <...
  • Page 9 1. INTRODUCTION Item Description Specification DCS1800/PCS1900 OFFSET from Carrier (KHz) Max. (dBm) Spectrum due to switching transient 1,200 1,800 EGSM900 BER (Class II) < 2% @ -105dBm Bit Error Rate DCS/PCS BER (Class II) < 2% @ -103dBm SLR(Sending Loudness Ratio) 8 +/- 3 dB Frequency (Hz) Max.(dB)

  • Page 10: Software Download Procedure

    2. Software Download Procedure 2. Software Download Procedure Tools 1. Download cable 2. PC 3. Battery (3.8 V Li-ion Battery) How to user Leo download tool 2.1 Install Leo Download tool ➜ Choose I accept the terms in the license agreement ➜...
  • Page 11 2. Software Download Procedure ➜ Select default folder ➜ Press Install - 12 -...
  • Page 12 2. Software Download Procedure ➜ Press Finish ➜ Enable Leo Download tool - 13 -...
  • Page 13 2. Software Download Procedure 2.2 Connect Download cable with computer and mobile 2.3 Install SW ➜ Select COM port (Maybe it will show different COM because of we use different computer) - 14 -...
  • Page 14 2. Software Download Procedure ➜ Press Setting and then you will see Multiport Data folder. Change it to the folder which you store the SW. ➜ Select the. Pcs file and press open. After few seconds, you will see below screen. - 15 -...
  • Page 15 2. Software Download Procedure ➜ Press Yes ➜ After you see the pink cycle, long press power on key and then you will see below picture. - 16 -...
  • Page 16 2. Software Download Procedure ➜ After reach to 100%, SW downloads finish. 2.4 Check Software version 2.4.1 Install battery and power on phone. 2.4.2 Press 8 7 8 ( SIM card not installed ) or ✻ # 8 7 8 # ( SIM card installed ) to enter service mode. 2.4.3 Select 2.

  • Page 17: Assembly And Disassembly

    3. Assembly and Disassembly 3. Assembly and Disassembly Tools * Torque screwdriver, no.6 set * Pair of tweezers * Guitar Pick 3.1 Disassembly i. Take off battery cover ii. Release 4 screws from B-Cover. - 18 -...
  • Page 18 3. Assembly and Disassembly iii. Use the Guitar Pick to take off B-Cover iv. Remove the Receiver and Key Pad from A-Cover - 19 -...
  • Page 19 3. Assembly and Disassembly v. Take off the Main Board from B-Cover vi. Take off the Vibrator, side key, BATT connect and from B-Cover - 20 -...
  • Page 20 3. Assembly and Disassembly vii. Take off the LCM from Main Board 1. Release the LCM connect from Main Board 2. Take off LCM from LCM place. 3.2 Assembly Please do the reverse steps of disassembly for assembly phone. - 21 -...

  • Page 21: Troubleshooting

    4. Troubleshooting 4. Troubleshooting Explanations The Go / No Go test has to be performed with a mounted phone. Service function in the software The service menu will be accessed with the following key combination. ✻ # 8 7 8 # (SIM card in side) or 8 7 8 (No SIM card in side) In the software of the phone there is a built in service functionality that allows you to test some of the functions of the phone.
  • Page 22 4. Troubleshooting Network Problems Make a general visual inspection for corrosion or oxidation from liquid damage. Check that the antenna connects is properly fitted and undamaged (Fig.1.1). Replace the antenna if necessary. Check that the antenna Flex Film (Fig 1.2) is not mechanical damaged, dirty or oxidized. Replace it if necessary.
  • Page 23 4. Troubleshooting Audio problems Receiver Turn on the phone. Go to service test menu; choose “11. Receiver” presses any key to check that the Receiver is working properly. Check Receiver and receiver cconnector (Fig 3.1) Fig.3.1 Microphone 1. Turn on the phone. Go to service test menu; choose “4. Echo Loop” (An audio loop is activated) check that the Microphone is working properly.
  • Page 24 4. Troubleshooting Display/Illumination problems Make a general visual inspection for corrosion or oxidation from liquid damage. Turn the phone on. Check the LCD and the illumination. The illumination is lightened when the phone starts and will continue for approximately 20 sec Turn the phone on.
  • Page 25 4. Troubleshooting Capacity/Charging Problems Make a general visual inspection for corrosion or oxidation from liquid damage. Charging Insert a working battery and connect a working charger to the phone. If the battery voltage is too low, you must charge the battery without turning on the phone (this will usually take less than 10 minutes) and when the battery voltage is high enough the phone will be able to turn on and show charging in the Display.
  • Page 26 4. Troubleshooting Key Function Problems Make a general visual inspection for corrosion or oxidation from liquid damage. Turn the phone on. Go to service test menu; choose “5.Keypad”. Press all the buttons. The pressed key will be shown in the Main display. Check that the mechanical response feels normal and that all the keys had been shown in the Main display.

  • Page 27: Other Problems

    4. Troubleshooting Other Problems Make a general visual inspection for corrosion or oxidation from liquid damage according to point. Turn on the phone. Go to service test menu; choose “15. RTC” press any key to check that the RTC is working properly. Check that the clock is working and that it does not start up with 00:00 when a battery is mounted.

  • Page 28: Power Key

    4. Troubleshooting Power and Charger control From Mini USB Connector VBAT F400 F400 Fuse (1A 0603) Fuse (1A 0603) C0603 C0603 VCHG TP401 TP401 U400 U400 TP60MIL TP60MIL R401 R401 PMIC MT6305BN/C PMIC MT6305BN/C R400 R400 TP-1.5 TP-1.5 100K 100K QFN48P QFN48P D400...
  • Page 29 4. Troubleshooting Power on/off Problem Start Go to step 2 Re-Download SW Replace the U400 Check the voltage of the following pins at U400 Replace the U400 VCORE_C407=1.8V? VDD_C408=2. AVDD_C409=2.8V? VMEM_C411=2.7V? VBAT_C405= 3.8V? Change X100 Check the X100=32.768KHZ Change U603 Check the U603_C642=26MHZ Power will work properly - 30 -...
  • Page 30 4. Troubleshooting U601 U600 C405 U400 C407 Pin32 C409 C408 U602 C411 U502 X100 Transceiver C642 U603 U100 U300 Flash TP401 - 31 -...
  • Page 31 4. Troubleshooting Charging Problem Start Change IO300 Check IO300 pin Change D308 or F400 Check D308 or F400 Change U400 Check the U400 Charging will work properly D308 F400 IO300 - 32 -...
  • Page 32 4. Troubleshooting Audio Problem [Louder SPK problem] Start Check LS203, E201 and SPK Change LS203, E201 or SPK Change B212, B213 Check B213, B212 Check R212, R217 Change R212, R217 Check U200_C238 Change U200 Louder SPK will work properly - 33 -...
  • Page 33 4. Troubleshooting Components in Metal Can Speaker Driver (Boomer) C239 N.C. (22p) Close to loud speaker! C0402 U206A Louder Speaker R213 CM1416 R0402 CM1416 LS203 DMS1608F-06-F2-G U200 P30-02B1-00 C237 100nF R212 SPK+ C243 SPK1P MP3_OUTR Vo2(+) C0402 R0402 N.C. (100pF) SPK- SPK1N C234 100nF...
  • Page 34 4. Troubleshooting Audio Problem [Receiver problem] Start Clean LS201 pad Check LS201 pad Change Receiver Check the Receiver Change U202 Check the U202 Receiver will work properly - 35 -...
  • Page 35 4. Troubleshooting Close to Receiver! U202A Receiver CSPEMI201A CSPEMI201A Receiver RECN0 Connector ReceiverN C229 LS201 N.C. (100pF) TP35MIL Fr om MT6226M ReceiverP C0402 SDRP0615FJ04-F6-G U202B CSPEMI201A CSPEMI201A RECP0 ESD210 ESD209 U202 LS 201 - 36 -...
  • Page 36 4. Troubleshooting Audio Problem [MIC problem] Start Clean LS201 pad and change MIC Check LS201 pad and MIC Check R220, R221, R202, R207, C202 Change R220, R221, R202, R207, C202 Check C208, C200 Change C208, C200 MIC will work properly R202, R207 R220, R221 MIC200...
  • Page 37 4. Troubleshooting Microphone MICBIASP R221 R0402 R202 1.5K Close to microphone! R0402 U204A CSPEMI202A C200 100nF CSPEMI202A MICP0 C0402 MIC200 Microphone 4mm OBF215 C202 C205 10uF N.C. (100pF) To MT6226M C0805 C0402 U204B CSPEMI202A C208 100nF CSPEMI202A MICN0 C0402 ESD213 ESD214 R207 1.5K...
  • Page 38 4. Troubleshooting Camera Problem Start Change or reassembly J201 and Camera Check J201 and Camera Change U403 or U404 Check C222, C221, C223 Check R222, R223, R224 Change U100 Camera will work properly U403 U404 Camera - 39 -...
  • Page 39 4. Troubleshooting CMDATA7 CMDATA6 CM_28V CMPCLK C221 C221 CMDATA5 100nF 100nF CMDATA3 C0402 C0402 B205 B205 R0603 R0603 MMS1608S121AT MMS1608S121AT R222 R222 R0402 R0402 CMMCLK J201 J201 CM_AGND To MT6226M CM_28V CMDATA8 P.1 CMDATA2 CLE9124-1501F CLE9124-1501F CMDATA9 P.1 CMDATA1 CMDATA4 DOVDD CMDATA0 HREF...
  • Page 40 4. Troubleshooting Display Problem Start Change LCM or J402 Check J402 or LCM Check R418, R419, R420 Change U100 Check the C428, C429, C431 Change U405 Display will work properly J402 - 41 -...
  • Page 41 4. Troubleshooting LCM connector 0.3 pitch LCM Interface Note:EDS J402 J402 04-6296-025-210-883+ 04-6296-025-210-883+ 6296-025 6296-025 R408 R408 C432 C432 100nF 100nF C0402 C0402 R0402 R0402 LRSTB RESET LRDB C421 C421 LWRB N.C. N.C. LPA0 C0402 C0402 LCM_CS NLD8 P.1,3 NLD7 P.1,3 NLD6 P.1,3...
  • Page 42 4. Troubleshooting Network problem E600 Antenna P55-02B1-01 PA_EN P.1 C658 VBAT C601 C602 C603 C604 C0402 VAPC P.1 100nF 27pF 22pF R603 C0402 C0402 C0402 C0402 C605 R604 C611 220pF R0402 0.5pF C0402 R0402 C0402 C606 U600 L602 L604 C628 C0402 RA605 8.2nH...
  • Page 43 4. Troubleshooting RX Path TX Path RF transceiver (U602) - 44 -...
  • Page 44 4. Troubleshooting VCTCXO (U603) Test point part Function Typical value Description U603, pin1 VCONTROL 1.38V Automatic frequency control voltage (AFC) U603, pin3 OSCOUT 26MHz Reference frequency output U603, pin4 2.8V Power supply - 45 -...
  • Page 45 4. Troubleshooting T/R Switch (U601) Test point part Function Typical value Description U601, pin1 D_RX DCS RX U601, pin2 2.8V PCS RX control signal U601, pin3 P_RX PCS RX U601, pin4 2.8V DCS, PCS TX control signal U601, pin5 D_TX DCS PCS TX U601, pin7 G_TX...
  • Page 46 4. Troubleshooting PA module (U600) Test point part Function Typical value Description U600, pin1 DPCS_IN DCS PCS RF input U600, pin2 2.8V Band select logic input U600, pin3 TXEN 2.8V TX enable logic input U600, pin4 VBAT 3.8V(3.4~4.2V) Battery supply connection U600, pin5 CEXT by pass...
  • Page 47 4. Troubleshooting Network Problem Start Change E600 and J601 Check E600 and J601 Check Tx / Rx signal Change U601 or U600 Change U603 Check U603=26MHZ? Network will work properly - 48 -...
  • Page 48 4. Troubleshooting J601 J601 U601 U600 U602 U603 - 49 -...

  • Page 49: Sim Card Problem

    4. Troubleshooting SIM Card Problem Start Change J500 Check J500 Change U400 Check C511 Change U100 Check the U100 SIM will work properly J500 - 50 -...
  • Page 50 4. Troubleshooting 2.8V I/O SIM card reset output SIMRST SIMRST SIM card clock output MT6226 SIMCLK SIMCLK To MT6305 SIM card supply power control SIMVCC SIMVCC SIM card supply power select GPIO32_SIMSEL SIMSEL/GPIO32 SIM card data input/output SIMDATA SIMDATA SIMDATA SIMIO SIMRST SIMRST...
  • Page 51 4. Troubleshooting Keypad Problem Start Clean the PCBA pad Check test mode Check Power on key Change U400 Check U100 Change U100 Keypad will work properly - 52 -...
  • Page 52 4. Troubleshooting U400 U100 - 53 -...
  • Page 53 4. Troubleshooting KEYPAD (Metal Dome) KCOL3 KCOL3 PWRKEY KCOL2 KCOL2 KCOL1 KCOL1 KCOL0 KCOL0 SW324 SW324 KROW0 KROW0 SW302 SW302 SW304 SW304 [SOFT_L] KROW1 KROW1 SW316 SW316 SW300 SW300 KROW2 KROW2 SW312 SW312 SW306 SW306 SW307 SW307 SW308 SW308 KROW3 KROW3 SW301 SW301...

  • Page 54: Circuit Diagrams

    5. Circuit Diagrams 5. Circuit Diagrams SYSTEM BLOCK DIAGRAM - 55 -...

  • Page 55: Keypad Switches And Key Backlight Illumination

    5. Circuit Diagrams Keypad Switches and Key Backlight Illumination KEYPAD (Metal Dome) KCOL3 KCOL3 PWRKEY KCOL2 KCOL2 KCOL1 KCOL1 KCOL0 KCOL0 SW324 SW324 KROW0 KROW0 SW302 SW302 SW304 SW304 [SOFT_L] KROW1 KROW1 SW316 SW316 SW300 SW300 KROW2 KROW2 SW312 SW312 SW306 SW306 SW307...
  • Page 56 5. Circuit Diagrams LCM Backlight Circuit L400 L400 D402 D402 VBAT 10uH Winding 10uH Winding RB520S-30TE61 RB520S-30TE61 SNFC0312P SNFC0312P SC79 SC79 C429 C429 C428 C428 1uF/25V 1uF/25V 2u2F 2u2F C0603 C0603 C0603 C0603 C431 C431 N.C. (100n) N.C. (100n) U405 U405 C0402 C0402...
  • Page 57 5. Circuit Diagrams Microphone MICBIASP R221 R221 R0402 R0402 R202 R202 1.5K 1.5K R0402 R0402 U204A U204A CSPEMI202A CSPEMI202A C200 100nF C200 100nF CSPEMI202A CSPEMI202A MICP0 C0402 C0402 MIC200 MIC200 Microphone 4X1.3mm Microphone 4X1.3mm OBF215 OBF215 C202 C202 C205 C205 10uF 10uF N.C.
  • Page 58 5. Circuit Diagrams Receiver U202A U202A Receiver CSPEMI201A CSPEMI201A CSPEMI201A CSPEMI201A Receiver RECN0 Connector C229 C229 ReceiverN LS201 LS201 N.C. (100pF) N.C. (100pF) TP35MIL TP35MIL C0402 C0402 ReceiverP SDRP0615FJ04-F6-G SDRP0615FJ04-F6-G U202B U202B CSPEMI201A CSPEMI201A CSPEMI201A CSPEMI201A RECP0 ESD210 ESD210 ESD209 ESD209 Spark Gap Spark Gap...
  • Page 59 5. Circuit Diagrams Camera Module CMDATA7 CMDATA6 CM_28V CMPCLK C221 C221 CMDATA5 100nF 100nF CMDATA3 C0402 C0402 B205 B205 R0603 R0603 MMS1608S121AT MMS1608S121AT R222 R222 R0402 R0402 CMMCLK J201 J201 CM_AGND CM_28V CMDATA8 P.1 CMDATA2 CLE9124-1501F CLE9124-1501F CMDATA9 P.1 CMDATA1 CMDATA4 DOVDD CMHREF P.1...
  • Page 60 5. Circuit Diagrams Side Key Switch Sidekey KCOL2 KCOL3 T310 T310 ESD313 ESD313 T302 T302 ESD315 ESD315 SFI0402-050E100nP-LF SFI0402-050E100nP-LF Spark Gap Spark Gap SW310 SW310 SFI0402-050E100nP-LF SFI0402-050E100nP-LF Spark Gap Spark Gap SW320 SW320 C0402 C0402 Push Switch Push Switch C0402 C0402 Push Switch Push Switch...
  • Page 61 5. Circuit Diagrams Memory PIN NAMES A0 to A22 Address inputs for Pseudo SRAM & Nor Flash Memory DQ0 to DQ15 Data inputs / outputs for Pseudo SRAM & Nor Flash Memory I/O1 to I/O8 Data inputs / outputs for Nand E PROM , CE2ps Chip enable inputs for Pseudo SRAM...
  • Page 62 5. Circuit Diagrams Component place information Vibrator SIM Card MCP Memory TCXO GSM/GPRS Contact Connector TV579002xxGD 26MHz AWT6166 32.768KHz Transceiver MT6129 Camera Module and Socket Antenna Pogo Pin Mini USB Speaker Connector Grounding Spring Speaker Microphone Pogo Pin Contact Audio Micro SD Booster Baseband...
  • Page 63 - 64 -...
  • Page 64 5. CIRCUIT DIAGRAMS Screw pad EINT0_HEADSET ENIT1_FM_INT STH1 STH1 EINT2_CHARGER ED[0..15] P.3 TP-D1.0 TP-D1.0 TP-D1.1 TP-D1.1 FIDU-1.0R-2.0 FIDU-1.0R-2.0 TP25MIL TP25MIL TP-4.0 TP-4.0 TP25MIL TP25MIL STH2 STH2 TP-D1.0 TP-D1.0 TP-D1.1 TP-D1.1 FIDU-1.0R-2.0 FIDU-1.0R-2.0 TP25MIL TP25MIL TP-4.0 TP-4.0 TP25MIL TP25MIL SD_CLK STH3 STH3 SD_CD TP-D1.0...
  • Page 65 5. CIRCUIT DIAGRAMS Components in Metal Can MICBIASP MICBIASP TOP VIEW R221 R221 R0402 R0402 R204 R204 L MIC R0402 R0402 C203 100nF C203 100nF MICN1 C0402 C0402 R202 R202 C206 C206 1.5K 1.5K C207 C207 10uF 10uF R0402 R0402 N.C.
  • Page 66 5. CIRCUIT DIAGRAMS 3 IN 1 MCP Flash Memory U300 U300 VMEM TV00579002CAGD TV00579002CAGD TV00578003AABD-A TV00578003AABD-A EA[1..23] KEYPAD (Metal Dome) Vccf(N.C_1Gbit) KCOL3 Vccf KCOL3 PWRKEY KCOL2 KCOL2 Vccps KCOL1 KCOL1 KCOL0 KCOL0 SW324 SW324 WP#/ACC EA10 RESET# /WATCHDOG P.1 EA11 CEf1# /ECS0_FLASH P.1 EA12...
  • Page 67 5. CIRCUIT DIAGRAMS VBAT F400 F400 Fuse (1A 0603) Fuse (1A 0603) C0603 C0603 VCHG TP401 TP401 U400 U400 TP60MIL TP60MIL R401 R401 PMIC MT6305BN/CY PMIC MT6305BN/CY R402 R402 R400 R400 TP-1.5 TP-1.5 100K 100K QFN48P QFN48P 100K 100K D400 D400 100K 100K...
  • Page 68 5. CIRCUIT DIAGRAMS C504 C504 22nF 22nF C0402 C0402 C501 C501 N.C. N.C. S_IO C0402 C0402 U502 U502 C505 C505 Si4700 Si4700 VSIM 100pF 100pF FMM24PA-A FMM24PA-A J500 J500 S_RST C0402 C0402 SIM Crad Slot SIM Crad Slot WL629D3-T02-7F WL629D3-T02-7F FM_ANT FMIP RFGND...
  • Page 69 5. CIRCUIT DIAGRAMS E600 E600 Antenna Antenna P55-02B1-01 P55-02B1-01 PA_EN P.1 C658 C658 VBAT C601 C601 C602 C602 C603 C603 C604 C604 C0402 C0402 VAPC P.1 100nF 100nF 27pF 27pF 22pF 22pF R603 R603 C0402 C0402 C0402 C0402 C0402 C0402 C0402 C0402 C605...

  • Page 70: Pcb Layout

    6. PCB LAYOUT - 71 -...
  • Page 71 6. PCB LAYOUT - 72 -...

  • Page 72: Exploded View & Replacement Part List

    7. EXPLODED VIEW & REPLACEMENT PART LIST 7.1 EXPLODED VIEW 13 14 33 42 34 37 35 48 47 49 24 32 38 39 - 73 -...
  • Page 73 - 74 -...
  • Page 74 7. EXPLODED VIEW & REPLACEMENT PART LIST 7.2 KG200 Service Parts LG Part Maker parts Location Part name Description Color number No(ARIMA) Chip Set GP_IC BASEBAND U100 BB processor EUSY0326801 PROCESSOR_MT6226MA/BC- 311009000002LJ L_TFBGA_296BALL_MTK GP_IC POWER MANAGEMENT U400 Power IC EUSY0325101...
  • Page 75 7. EXPLODED VIEW & REPLACEMENT PART LIST LG Part Maker parts Location Part name Description Color number No(ARIMA) GP_VARISTOR_5V_VPORT0402100MV05_0402 VARISTOR SEVY0008601 3080040000006A _10pF_INPAQ GP_ATTENUATORS_3dB_50ohm_0404_¡ ATTENUATOR SQGY0000301 33400003000006 0.3dB_YAGEO GP_ATTENUATORS_5dB_50ohm_0404_¡ ATTENUATOR SQGY0000401 33400005000006 0.3dB_YAGEO EME -SMT GP_CON MINI USB CONNECTOR_MNC40- IO300...
  • Page 76 7. EXPLODED VIEW & REPLACEMENT PART LIST LG Part Maker parts Location Part name Description Color number No(ARIMA) GP_VIBRATOR Bar VIBRATOR SJMY0008901 3200000000019H Type_Z4TH3B0140024_R2.5*12.5_JINLONG GP_REAR CABINET_BLACK_7330_PC_GABEUL REAR COVER MCJN0059101 Black 4020B7330000V7 PLASTIC GP_CAP_BLACK_7330_SILICON SCREW CAP MCCH0094101 Black 4060B7330000VD RUBBER_SCREW_MISUNG POLYTECH CO.
  • Page 77 7. EXPLODED VIEW & REPLACEMENT PART LIST LG Part Maker parts Location Part name Description Color number No(ARIMA) Accessory GP_BATTERY PACK_Li- BATTERY PACK SBPL0087501 ion_3.7V_800mAh_WITHOUT 306003100000A3 COVER_E3AR040802H12_WELLDONE GP_SWITCHING TRAVEL SWITCHING CHARGER_100~240V_5.2V_550mA_CE_GP- TRAVEL SGCT0004601 331000000000LY ACGN-22T-A22_Europe EN 50 CHARGER 075(ungrounded)_GEARWAY_SUNFONE GP_HDF_CHM201STS04042_32ohm_56dB_-...
  • Page 78 Note...
  • Page 79 Note...
