Summary of Contents for Eizo Eizo i I-SOUND L2 I-SOUND L2

  • Page 2: Safety Symbols

    Indicates a prohibited action. Copyright© 2000 by EIZO NANAO CORPORATION. All rights reserved. No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, or otherwise, without the prior written permission of Eizo Nanao Corporation.

  • Page 3: Table Of Contents

    INSTALLATION ... 9 TROUBLESHOOTING ... 13 CLEANING ... 14 SPECIFICATIONS ... 15 LIMITED WARRANTY ... 17 • The EIZO i ·Sound L2 should only be used as a sound unit for the new range of ultra-slim-besel incorporate EIZO LCD monitors.

  • Page 4: Precautions

    PRECAUTIONS General CAUTION • Remove the sound unit whenever moving the monitor. Lifting the monitor by the sound unit is dangerous. It may result in injury or equipment damage. • When adjusting the viewing angle of the monitor, do not do so by the sound unit. Adjusting the monitor by the sound unit may dislodge it from the LCD monitor or result in accidental pinching of the skin.
  • Page 5 (ex. recorded cassette tapes, watches, cash cards, floppy diskette, etc.) near the unit to avoid any ill-affects to the items. • The EIZO i ·Sound slim-bezel incorporate EIZO LCD monitors. It should not be used for any other purposes. Please ask the EIZO dealer for more information. ™...

  • Page 6: Introduction

    1. INTRODUCTION About This Manual This manual explains the precautions, features, specifications, and operation of the EIZO i·Sound™ L2 sound unit. Package Contents • i·Sound L2 Sound Unit ... 1 • Stereo Mini-jack Cables ... 1 • User’s Manual ... 1 •...
  • Page 7 Features The EIZO i·Sound L2 sound unit for LCD monitor is specifically designed for the new range of EIZO LCD monitors to make them complete multimedia units. This unit has two speakers that produce clear stereo sound and a volume control. It also accepts audio input from different audio devices such as a sound board, CD and cassette player.

  • Page 8: Controls And Connectors

    Controls and Connectors LINE IN HOOK HOOK DC IN Front VOLUME HEADPHONE SPEAKERS...
  • Page 9 Front / Top • DC IN: Power supply from the monitor After combining the monitor and the speaker unit, the DC IN connector allows for an automatic power supply of the speaker unit through the monitor. • HEADPHONE: Headphones jack A set of headphones is a great tool to work without disturbing people within a close range.

  • Page 10: Installation

    2. INSTALLATION • Always switch the monitor off before installing or removing the sound unit and whenever connecting or disconnecting any other devices to the sound unit. How to connect external audio devices and the computer 1. Remove the power terminal cover of the LCD monitor. Turn off the LCD monitor and remove the power terminal cover as shown below.
  • Page 11 2. Connect the sound unit to the LCD monitor. 1. Attach the sound unit to the LCD monitor. Place the sound unit under the monitor screen and insert the hooks ‘a’ on top of the unit into slots ‘a’ located at the bottom of the rear of the monitor.
  • Page 12 3. Connect the cable of the peripherals to the sound unit. • Please use the enclosed Stereo Mini-jack Cable (or another cable with the same specifications) for connecting audio devices or computers to the unit. When connecting two audio devices to the unit, please purchase another Stereo Mini-jack cable. 1.
  • Page 13 Speakers and sound control 1. Besides the speakers on its unit, audio performance is available by connecting the headphones to the i × × × × × Sound L2 unit (When headphones are connected, no sound can be heard from the speakers.) 2.

  • Page 14: Troubleshooting

    3. TROUBLESHOOTING This page presents problems that can be corrected by the user. If a problem persists even after applying the suggested remedies, contact an EIZO dealer. Problems • No sound Points to check with possible solutions Check that the monitor is turned ON.

  • Page 15: Cleaning

    4. CLEANING WARNING • Keep liquids away from the monitor and the sound unit. Spillage into the unit may result in fire, shock, or equipment damage. CAUTION • To ensure safety, always unplug the monitor before cleaning the sound unit. Failure to do so may result in electric shock.

  • Page 16: Specifications

    5. SPECIFICATIONS Electrical Specifications Speaker Unit Speaker System Amplifier Output (max.) Frequency Response Control Power Supply Power Consumption (max.) 6.0 W Input Connector Output Connector Mechanical Specifications Dimensions Weight Operating Environmental Specifications Temperature Humidity 4 x 2.8 cm (two) Bass Reflex type 2.0 W + 2.0 W...

  • Page 17: Front View

    DIMENSIONS SIDE VIEW FRONT VIEW...

  • Page 18: Limited Warranty

    In the event of malfunction during the warranty period attributable directly to faulty material and/or workmanship, EIZO and EIZO’s authorized distributors will, at their option, either repair or replace the faulty product with the same or similar model. EIZO and EIZO’s authorized distributors shall have no obligation under this warranty, however, in the following...
