- Page 1 RYOBI 18 VOLT INFLATOR DIGITAL GAUGE MODEL NO. P730 REPAIR SHEET...
- Page 2 RYOBI 18 VOLT INFLATOR – MODEL NUMBER P730 FIGURE B Figure A...
- Page 3 RYOBI 18 VOLT INFLATOR – MODEL NUMBER P730 The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your INFLATOR or when ordering repair parts. PARTS LIST (FIGURE A) PART PART NUMBER DESCRIPTION NUMBER DESCRIPTION 00467001 WIRING HARNESS ASSEMBLY ......1 940015119 LOGO LABEL............1 410001 OFF BUTTON ............1 671891001 SCHRADER VALVE CORE REMOVAL ....1 6605001 * SCREW (M X 10 mm PAN HD.) ...... 514194001 LOCK-ON ACTUATOR ......... 1 660000 * SCREW (M X 1 mm PAN HD.) ......
- Page 4 RYOBI 18 VOLT INFLATOR – MODEL NUMBER P730 The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your INFLATOR or when ordering repair parts. Figure B PARTS LIST (FIGURE B) PART PART NUMBER DESCRIPTION NUMBER DESCRIPTION 64115001 COMPRESSOR COVER ........1 01600 GEAR CASE COVER ASSEMBLY 57065001 RUBBER COMPRESSOR WASHER ....1 WITH BEARINGS ..........1 67096001 CYLINDER ............1 0000087 GEAR SHAFT ASSEMBLY ........
-
Page 5: Wiring Diagram
RYOBI 18 VOLT INFLATOR – MODEL NUMBER P730 MAIN SWITCH MOTOR CONTROL PCB FUSE BLUE BLACK ORANGE BLACK LOCK ON SWITCH BROWN CONTACT PLATE HOLDER WHITE GREEN DIGITAL SHUT OFF PCB PRESSURE GAUGE BLACK BLACK WIRING DIAGRAM * NOTE: The positive side of the motor has a red marking for identification.
