List Book
Contents
Voice List ......................................................................... 2
Drum Voice List ................................................................ 3
Preset Style List................................................................. 9
Phrase Category List ......................................................... 9
Effect Type List ............................................................... 10
Effect Parameter List ....................................................... 11
Data/Value Tables ......................................................... 14
MIDI Data Format .......................................................... 15
MIDI Implementation Chart ............................................. 22
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RM1x and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Yamaha RM1x

Summary of Contents for Yamaha RM1x

  • Page 1: Table Of Contents

    List Book Contents Voice List ................. 2 Drum Voice List ..............3 Preset Style List..............9 Phrase Category List ............9 Effect Type List ............... 10 Effect Parameter List ............11 Data/Value Tables ............14 MIDI Data Format ............15 MIDI Implementation Chart ..........

  • Page 2: Voice List

    Voice List Instrument Classical Ethnic & Synth Band Drum Kit Synth Bass & Synth Pad & GM Drum Kit Group Instrument & Wind Percussion Instrument Synth EFX Material Lead Bank Select MSB Bank Select LSB GrandPno Piano RezoBass SynthPad Saw1 A BritePno Strings1 Kalimba1...

  • Page 3: Drum Voice List

    Drum Voice List Bank MSB Bank LSB Alternate Alternate Alternate Alternate Alternate Alternate Alternate Alternate Note# Note AnlgKit1 assign AnlgKit2 assign RhBoxKit assign SynthKit assign SE Kit assign PsychKit assign Acid Kit assign TeknoKit assign E -1 Rev Low Noise Rev Low Noise Rev Low Noise Rev Low Noise...

  • Page 4: Sonar1

    Bank MSB Bank LSB Alternate Alternate Alternate Alternate Alternate Alternate Alternate Alternate Note# Note AmbntKit assign Hard Kit assign HouseKit assign BreakKit assign JunglKit assign D&B Kit assign Big Kit assign HipHpKit assign E -1 Rev Low Noise Rev Low Noise Rev Low Noise Rev Low Noise Rev Low Noise...
  • Page 5 Bank MSB Bank LSB Alternate Alternate Alternate Alternate Alternate Alternate Alternate Alternate Note# Note Aco.Kit assign Jazz Kit assign BrushKit assign PercsKit assign BD Kit assign HH&CyKit assign SD Kit assign Tom Kit assign E -1 Rev Low Noise Rev Low Noise Rev Low Noise Digeridoo 3 Short F -1...

  • Page 6: Brthnoiz

    Bank MSB Bank LSB Alternate Alternate Alternate Alternate Alternate Alternate Alternate Alternate Note# Note SFX Kit1 assign SFX Kit2 assign AnlgKt1N assign AnlgKt2N assign RhBoxKtN assign SynthKtN assign SE Kit N assign PsychKtN assign E -1 Rev Low Noise Rev Low Noise Rev Low Noise Rev Low Noise Rev Low Noise...
  • Page 7 Bank MSB Bank LSB Alternate Alternate Alternate Alternate Alternate Alternate Alternate Alternate Note# Note AcidKitN assign TeknoKtN assign AmbntKtN assign HardKitN assign HouseKtN assign BreakKtN assign JunglKtN assign D&BKitN assign E -1 Rev Low Noise Rev Low Noise Rev Low Noise Rev Low Noise Rev Low Noise Rev Low Noise...
  • Page 8 Bank MSB Bank LSB Alternate Alternate Alternate Alternate Alternate Alternate Alternate Note# Note Big KitN assign HipHpKtN assign Aco.KitN assign JazzKitN assign BrushKtN assign PercsKtN assign GM-StandKit assign E -1 Rev Low Noise Rev Low Noise Rev Low Noise Rev Low Noise Rev Low Noise Digeridoo 3 Short F -1...

  • Page 9: Preset Style List

    Preset Style List / Phrase Category List Style# Category Display Style Name Phrase Category Display Category Name Dance / Techno PSYCHE1 Psychedelic Trance 1 162.0 User User PSYCHE2 Psychedelic Trance 2 141.0 Bass Drum Bass Drum PSYCHE3 Psychedelic Trance 3 145.0 SD/Clap Snare Drum / Clap...

  • Page 10: Effect Type List

    Effect Type List REVERB Exclusive Effect Type Description NO EFFECT Effect turned off. HALL1 Reverb simulating the resonance of a hall. HALL2 Reverb simulating the resonance of a hall. ROOM1 Reverb simulating the resonance of a room. ROOM2 Reverb simulating the resonance of a room. ROOM3 Reverb simulating the resonance of a room.

  • Page 11: Effect Parameter List

    Effect Parameter List Reverb Type Variation Type HALL1,2, ROOM1,2,3, STAGE1,2, PLATE HALL1,2, ROOM1,2,3, STAGE1,2, PLATE No. * Parameter Range Value Control No. * Parameter Range Value Control Reverb Time 0.3 – 30.0s 0-69 table#4 Reverb Time 0.3 – 30.0s 0-69 table#4 Diffusion 0 –...
  • Page 12 CROSS DELAY CHORUS1,2,3,4, CELESTE1,2,3,4 No. * Parameter Range Value Control No. * Parameter Range Value Control L->R Delay 0.1 – 355.0ms 1-3550 LFO Frequency 0.00 – 39.7Hz 0-127 table#1 R->L Delay 0.1 – 355.0ms 1-3550 LFO PM Depth 0 – 127 0-127 Feedback Level -63 –...
  • Page 13 TREMOLO GUITAR AMP SIMULATOR No. * Parameter Range Value Control No. * Parameter Range Value Control LFO Frequency 0.00 – 39.7Hz 0-127 table#1 Drive 0 – 127 0-127 AMP Type Off,Stack,Combo,Tube AM Depth 0 – 127 0-127 LPF Cutoff 1.0k – Thru 34-60 table#3 PM Depth...

  • Page 14: Data/Value Tables

    Data/Value Tables Table#4 Table#1 Table#2 Table#3 Modulation Delay Offset (ms) EQ Frequency (Hz) Reverb Time (s) LFO Frequency (Hz) Data Value Data Value Data Value Data Value Data Value Data Value Data Value Data Value Data Value Data Value 0.00 1.81 5.38 0 THRU(20)

  • Page 15: Midi Data Format

    MIDI Data Format (3) TRANSMIT/RECEIVE DATA The RM1x tone generator and sequencer blocks handle different MIDIevents. (3-1) CHANNEL VOICE MESSAGES These are listed seqparately in the MIDI Data Format as well as in the MIDI (3-1-1) NOTE OFF Implementation Chart.
  • Page 16 (3-6-1-2)IDENTITY REQUEST (Received only) SENSITIBITY, FINE TUNING, COURSE TUNING F0H 7EH 0nH 06H 01H F7H ("n" is the device number, but the RM1x (3-2-3) ALL NOTE OFF (CONTROL NUMBER = 7BH , DATA VALUE = 0) receives this in Omni.) Turns off all notes of the corresponding channel which are on.

  • Page 17: Tone Generator Block

    SW4 [] MIDI Sync Transmitted when MIDI Sync = MTC. (3-3) SYSTEM COMMON MESSAGE These are transmitted and received as Control Messages for RM1x functions. (2) RECEIVE FLOW They are not recorded as SEQUENCE DATA. MIDI >-[]---+ <CHANNEL VOICE MESSAGE>...
  • Page 18 0tthhhhh standard time specification with sub-frames 11110111 End of Exclusive 0cmmmmmm 0kssssss ss=08H-0FH, dd=on is received, and the PATTERN will be changed to the RM1x's 0gifffff sections A - P respectively. 0bbbbbbb 11110111 End of Exclusive Transmitted when you move between measures in the SONG mode.
  • Page 19 02 01 10 00..7F Reverb Parameter 11 Refer to Ef. Parameter List depends on Reverb type 00..7F Reverb Parameter 12 Refer to Ef. Parameter List depends on Reverb type 00..7F Reverb Parameter 13 Refer to Ef. Parameter List depends on Reverb type 00..7F Reverb Parameter 14 Refer to Ef.
  • Page 20 nn 09 00..FF Detune -12.8..+12.7[Hz] nn 0A bit3..0 bit7..4 (80) 2nd bit3..0 bit3..0 nn 0B 00..7F Volume 0..127 nn 0C 00..7F Velocity Sense Depth 0..127 nn 0D 00..7F Velocity Sense Offset 0..127 nn 0E 00..7F 0:random L63..C..R63(1..64..127) nn 0F 00..7F Note Limit Low C-2..G8 nn 10...
  • Page 21 <Table 1-6> Effect Type List REVERB TYPE TYPE MSB TYPE LSB No Effect Rev Hall 1 Rev Hall 2 Rev Room1 Rev Room 2 Rev Room 3 Rev Stage 1 Rev Stage 2 Rev Plate No Effect No Effect Rev WhiteRm Rev Tunnel No Effect Rev Basement...

  • Page 22: Midi Implementation Chart

    YAMAHA [ Music Sequencer --- voice part Date:08-SEP-1998 Model RMlx MIDI Implementation Chart Version : 1.0 Transmitted Recognized Remarks Function ... Basic Default 1 - 16 1 - 16 Memorized Channel Changed 1 - 16 1 - 16 Default Memorized...
  • Page 23 YAMAHA [ Music Sequencer --- sequencer part Date:08-SEP-1998 Model RMlx MIDI Implementation Chart Version : 1.0 Transmitted Recognized Remarks Function ... Basic Default 1 - 16 1 - 16 Memorized Channel Changed Default Mode Messages Altered ************** Note 0 - 127...
  • Page 24 M.D.G., EMI Division © Yamaha 1998 V344030 810 CMIT 18.2 – 02B0 Printed in Japan...
