Connecting the drain line

Secure the drain hose to the drain to prevent moving and
leaking.
NOTE
y The drain hose should be properly secured. Failure to
properly secure the drain hose can result in flooding
and malfunction.
y Total height of the house end should not exceed 96
inches (244.8 cm) from the bottom of the washer.
y The drain must be installed in accordance with any
applicable local codes and regulations.
y Make sure that drain hose is not stretched, pinched,
crushed, or kinked.
Using a standpipe
1
Insert the end of the drain hose into the standpipe.
Drain Hose
2
Use a tie strap to secure the drain hose in place.
39"
(99 cm)
Cable Tie
39"
(99 cm)
Cable Tie
INSTALLATION INSTRUCTIONS
Using a laundry tub
Drain Hose
B
end the end of the drain hose to the desired shape and
support it on the edge of the laundry tub. Use a tie strap to
secure the drain hose in place.
15
Laundry Tub
Tie Strap
