POCKET GUIDE
This guide is a simple summary of E-1 functions. Carry this
at all times and take advantage of it to ensure smooth
camera operation.
How to Use This Guide
e.g. Button & Dial operation (Exposure compensation)
+
Frame:
Do the operations in the frame simultaneously.
Here it means to compensate the exposure by rotating
the main dial or sub dial while holding down the exposure
compensation button.
e.g. Menu operation (EV step)
Follow the procedure in order as shown and confirm
the settings by pressing the OK button.
1
Use the arrow pad to
Menu button:
select the settings on the
Displays the menu.
menu displayed on the
monitor.
Exposure
Exposure compensation
+
(exposure compensation) button
* Exposure compensation is not
available in M mode.
* EV step interval can be changed.
(Refer to the instruction manual.)
Metering mode
+
(metering mode) button
Spot metering
Main dial:
Changes the
functions or settings.
or
Sub dial:
Changes the
functions or settings.
Finger mark:
Do other operations
while holding the button.
1/3EV
EV STEP
1/2EV
1EV
OK button:
Confirms the
settings.
Arrow pad
Adjustable range:±5.0EV
EV step interval:1/3EV,1/2EV,1EV
Control panel
or
Adjusting toward –
Exposure
compensation value
Exposure
compensation indicator
Control panel
or
Center weighted
Digital ESP metering
averaging metering
OLYMPUS CORPORATION
Shinjuku Monolith, 3-1 Nishi-Shinjuku 2-chome, Shinjuku-ku, Tokyo 163-0914
OLYMPUS AMERICA INC.
Two Corporate Center Drive, Melville, NY 11747-3157, U.S.A. Tel. 1-631-844-5000
Technical Support (USA)
24/7 online automated help: http://www.olympusamerica.com/E1
Phone customer support: Tel. 1-800-260-1625 (Toll-free)
Our phone customer support is available
from 8 am to 10 pm (Monday to Friday) ET
E-Mail: e-slrpro@olympusamerica.com
OLYMPUS OPTICAL CO. (EUROPA) GMBH.
Premises/Goods delivery: Wendenstrasse 14-18, 20097 Hamburg, Germany
Letters: Postfach 10 49 08, 20034 Hamburg, Germany
European Technical Customer Support:
Please visit our homepage http://www.olympus-europa.com
or call our TOLL FREE NUMBER: 00800 - 67 10 83 00
for Austria, Belgium, Denmark, Finland, France, Germany, Italy, Luxemburg,
Netherlands, Norway, Portugal, Spain, Sweden, Switzerland, United Kingdom
·
Please note some (mobile) phone services/provider do not permit access
or request an additional prefix to +800 numbers.
For all not listed European Countries and in case that you can't get connected
to the above mentioned number please make use of the following:
CHARGED NUMBERS: +49 (0) 1805-67 10 83 or +49 (0) 40-23 77 38 99
Our Technical Customer Support is available
OK
from 9 am to 6 pm MET (Monday to Friday)
AE lock
AEL button
Viewfinder
lights up (AE is locked)
AE bracketing
BKT button
ISO sensitivity
ISO button
Using the ISO BOOST mode
Tel. +49 (0) 40-23 77 30 Fax. +49 40-23 07 61
Pressing the AEL button locks the
metered exposure value for the subject.
+
Halfway down
(AE/AF is locked)
* AE lock is not available in M mode.
* The functions assigned to AF lock and AE lock can
be customized. (Refer to "AEL/AFL mode" on P. 5.)
EV step interval:1/3EV,1/2EV,1EV
Number of frames: 3 or 5
+
or
Number
of frames
AUTO,100,200,400,800, 1600,3200
+
or
(AUTO)
ISO BOOST
1
All the way down
(Shutter is released)
Control panel
EV step interval
Bracket shooting
Compensation
range
ISO BOOST mode
Control panel
ON
OK
1
