USER'S GUIDE
PCM16 (16-bit PC Card)
PCM32 (32-Bit CardBus)
Fast Ethernet PCMCIAcards provide a 100Base-
FX fiber port to deliver fiber optic connectivity to
laptops in high-security, fiber-rich LAN
environments. They are offered in either 16-bit
PC card or high-performance 32-bit Cardbus
versions to match virtually any laptop PC. This
eliminates the need for a docking station and a
fixed, fiber NIC.
PCM16-FX-xx-01 PC Card
Part Number
Duplex Fiber-Optic Port
PCM16-FX-ST-01
100Base-FX, 1300 nm multimode ST, 2km (1.2 miles)
PCM16-FX-SC-01
100Base-FX, 1300 nm multimode SC, 2km (1.2 miles)
PCM16-FX-LC-01
100Base-FX, 1300 nm multimode LC, 2km (1.2 miles)
PCM16-FX-SC5-01
100Base-FX, 1310 nm single mode SC, 5km (3.1 miles)
PCM16-FX-SC20-01
100Base-FX, 1310 nm single mode SC, 20km (12.4 miles)
PCM32FX-xx-01 PC CardBus
Part Number
Duplex Fiber-Optic Port
PCM32-FX-ST-01
100Base-FX, 1300 nm multimode ST, 2km (1.2 miles)
PCM32-FX-SC-01
100Base-FX, 1300 nm multimode SC, 2km (1.2 miles)
PCM32-FX-MT-01
100Base-FX, 1300 nm multimode MT, 2km (1.2 miles)
PCM32-FX-LC-01
100Base-FX, 1300 nm multimode LC, 2km (1.2 miles)
PCM32-FX-SC5-01
100Base-FX, 1310 nm single mode SC, 5km (3.1 miles)
PCM32-FX-SC20-01
100Base-FX, 1310 nm single mode SC, 20km (12.4 miles)
*Typical maximum cable distance. Actual distance is dependent upon the physical
characteristics of the network installation.
Installation . . . . . . . . . . . . . . . . . . .2
Diagnostic . . . . . . . . . . . . . . . . . . .3
Cable Specifications . . . . . . . . . . .4
Technical Specifications . . . . . . . .5
Troubleshooting . . . . . . . . . . . . . . .6
Contact Us . . . . . . . . . . . . . . . . . . .7
