Tools Menu; Asus Ez Flash 2; Ai Net2 - Asus M2N68 PLUS User Manual

Change User Password
Select this item to set or change the user password. The User Password item on top of the
screen shows the default Not Installed. After you set a password, this item shows Installed.
To set a User Password:
Select the Change User Password item and press <Enter>.
1.
2. On the password box that appears, type a password composed of at most six letters
and/or numbers, then press <Enter>.
3. Confirm the password when prompted.
The message "Password Installed" appears after you set your password successfully.
To change the user password, follow the same steps as in setting a user password.
Clear User Password
Select this item to clear the user password.
Password Check [Setup]
When set to [Setup], BIOS checks for user password when accessing the Setup utility. When
set to [Always], BIOS checks for user password both when accessing Setup and booting the
system. Configuration options: [Setup] [Always]
2.7

Tools menu

Main Advanced

ASUS EZ Flash 2

AI NET2

2.7.1 ASUS EZ Flash 2
Allows you to run ASUS EZ Flash 2. When you press <OK>, a confirmation message
appears. Use the left/right arrow key to select between [Yes] or [No], then press <OK> to
confirm your choice.
2.7.2 AI NET 2
Check Realtek Phy LAN cable [Disabled]
Enables or disables checking of the Realtek Phy LAN cable during the Power-On Self-Test
(POST). Configuration options: [Disabled] [Enabled]
Chapter 2: BIOS information
BIOS SETUP UTILITY
Power Boot Tools Exit
Press ENTER to run
the utility to select
and update BIOS.
This utility doesn't
support :
1.NTFS format
2-19
