1.7.2

Memory configurations

You may install 512MB, 1GB, 2GB and 4GB unbuffered ECC/non-ECC DDR2 DIMMs into the
DIMM sockets.
• You may install varying memory sizes in Channel A and Channel B. The system maps
the total size of the lower-sized channel for the dual-channel configuration. Any excess
memory from the higher-sized channel is then mapped for single-channel operation.
• Always install DIMMs with the same CAS latency. For optimum compatibility, we
recommend that you obtain memory modules from the same vendor.
• Due to the memory address limitation on 32-bit Windows
or more memory on the motherboard, the actual usable memory for the OS can be
about 3GB or less. For effective use of memory, we recommend that you do any of the
following:
-
-
• This motherboard does not support DIMMs made up of 256 megabits (Mb) chips or less.
The motherboard supports up to 8GB memory modules on Windows
and Vista x64 editions. You may install a maximum of 4GB DIMMs on each slot.
M2N68 PLUS Motherboard Qualified Vendors Lists (QVL)
DDR2-667MHz capability
Vendor Part No.
Kingston KVR667D2N5/512
Qimonda HYS64T64000EU-3S-B2
Micron MT8HTF12864AY-667E1
HY HYMP512U64CP8-Y5 AB
Apacer AU512E667C5KBGC
Transcend 506010-4894
ADATA M2OAD5G3H3160Q1C52
ADATA M2OAD5G314170Q1C58
ADATA M2OAD5H3J4170I1C53
PSC AL6E8E63J-6E1
PSC AL7E8E63J-6E1
GEIL GX21GB5300SX
G.SKILL F2-5400PHU2-2GBNT
Twinmos 8D-A3JK5MPETP
ELIXIR M2Y1G64TU8HA2B-3C
Leadmax LRMP512U64A8-Y5
Chapter 1: Product introduction
Install a maximum of 3GB system memory if you are using a 32-bit Windows
OS.
Use a 64-bit Windows OS if you want to install 4GB or more memory on the
®
motherboard.
SS/
Size CL
DS
512MB SS N/A
512MB SS 5
1G SS 5
1G DS 5
512MB SS 5
1G DS 5
512MB SS N/A
1G DS N/A
2G DS N/A
512MB SS 5
1G DS 5
1G DS 3
2G(kit of 2) DS 5-5-5-15
512MB SS 5
1G DS 5
1G DS N/A
OS, when you install 4GB
®
Chip No.
SO1237650821 SBP D6408TR4CGL25
USL074905PECNB
HYB18T512B00B2F3SFSS28171
D9HNL 7ZE17
HY5PS12521CFP-Y5
AM4B5708GQJS7E06332F
E5108AJBG-6E-E
AD29608A8A-3EG20813
AD29608A8A-3EG80814
AD20908A8A-3EG 30724
A3R12E3JFF717B9A00
A3R12E3JFF717B9A01
Heat-Sink Package
D2 64M8CCF 0815 C7173S
A3R12E3GEF633ACAOY
M2TU51280AE-3C717095R28F
HY5PS12821CFP-Y5 C 702AA
®
XP Professional x64
®
DIMM support
Chip
Brand
A* B*
• •
Kingston
Qimonda • •
Micron • •
Hynix • •
Apacer • •
Elpida • •
ADATA • •
ADATA • •
ADATA • •
PSC • •
PSC • •
GEIL • •
G.SKILL • •
PSC • •
ELIXIR • •
Hynix • •
1-11
