Installation Manual
For Your Records and Warranty
Assistance
Model Name: _____________________
Catalog/Model No.: ________________
Serial No.: ________________________
Date Purchased: ___________________
Where Purchased: _________________
For reference also attach your receipt or a
copy of your receipt to the manual.
installation and
operation manual
for Hunter
Ceiling Fans
TYPE 5 Models
42767-01 • 10/19/07
Advertisement
Table of Contents
Related Manuals for Hunter 23277
Summary of Contents for Hunter 23277
- Page 1 Hunter For Your Records and Warranty Assistance Ceiling Fans Model Name: _____________________ Catalog/Model No.: ________________ Serial No.: ________________________ Date Purchased: ___________________ Where Purchased: _________________ TYPE 5 Models For reference also attach your receipt or a copy of your receipt to the manual.
-
Page 2: Table Of Contents
Ceiling Fan ......14 controls. 9 • Troubleshooting ....15 © 2007 Hunter Fan Company 42767-01 • 10/19/07 • Hunter Fan Company... - Page 3 Installer’s Choice and Optional Accessories Understanding Mounting and Installer’ s Choice® Support Brace Hunter’s patented 2-position mounting system provides you maximum installation flexibility and ease. You can install your Hunter fan in one of two ways, depending on ceiling height and your preference: Standard or Angled mounting. The steps in this manual include instructions for Ceiling both Installer’s Choice mounting methods. Standard Outlet Box Mounting Considering Optional Accessories Style Consider using Hunter’s optional accessories, including a wall-mounted or remote speed control. To install and use the accessories, follow the instructions included with each product.
-
Page 4: Getting Ready
To install a ceiling fan, be sure you can do the following: • Locate the ceiling joist or other suitable support in ceiling. • Drill holes for and install wood screws. • Identify and connect electrical wires. • Lift 40 pounds. If you need help installing the fan, your Hunter fan dealer can direct you to a licensed installer or electrician. Gathering the Tools You will need the following tools for installing the fan: • Electric drill with 9/64” bit • Standard screwdriver (magnetic tip recommended) -
Page 5: Installing The Ceiling Plate
Do not over tighten. For Angled Ceilings: Be sure to orient Flat Washer the ceiling plate so that the hook and one of the threaded screw holes in the ceiling plate are on the lower side. 3” Wood Screw 42767-01 • 10/19/07 • Hunter Fan Company... -
Page 6: Assembling And Hanging The Fan
Canopy downrod. Note: When the downrod is fully installed, 2-3 threads on the pipe will still be visible; this is normal. Securely retighten the set screw with a wrench or pliers. Skip to Step 5-7. Set Screw CAUTION: The adapter has a special coating on the threads. Do not remove this coating; the coating prevents the downrod from unscrewing. Once assembled, do not remove the downrod. 42767-01 • 10/19/07 • Hunter Fan Company... -
Page 7: Wiring The Fan
4-6. Turn the splices upward and push them carefully back through the ceiling plate into the outlet box. 4-7. Spread the wires apart, with the grounded wires on one side of the outlet box and the ungrounded wires on the other side of the outlet box. 42767-01 • 10/19/07 • Hunter Fan Company... -
Page 8: Installing The Canopy
5 • Installing the Canopy 5-1. Partially install two canopy screws (about two full turns) in the hanger bracket. 5-2. Holding the canopy, raise the fan off the hook. 5-3. Align the holes in the canopy with the mounting holes on the ceiling plate. Canopy 5-4. Rotate fan counterclockwise until both canopy screws drop into slot recesses. Tighten screws securely. Install third screw into Steps 5-1– 5-4 mounting hole. Canopy Screw 42767-01 • 10/19/07 • Hunter Fan Company... -
Page 9: Assembling The Blades
6 • Assembling the Blades Hunter fans use several styles of fan blade irons (brackets that hold the blade to the fan). 6-1. Your fan may include blade grommets. If your fan has grommets, insert them by hand into the holes on the blades. 6-2. Attach each blade to a blade iron using three blade assembly screws. If you used grommets, the blades may appear slightly loose after screws are tightened. -
Page 10: Completing Your Installation With A Bowl Light Fixture
7 • Completing Your Installation With or Without a Bowl Light Fixture Your Hunter fan comes with an integrated light fixture assembly. WARNING: Use only the light fixture supplied with this fan model. 7-1. To attach the upper switch housing, partially install two housing assembly screws into the switch housing mounting plate. 7-2. Feed the upper plug connector through the center opening of the housing. - Page 11 Be sure no bare wire or wire strands are visible after CAUTION: Step 7-5 making connections. Light Fixture Mounting Screw Step 7-6 Light Fixture Mounting Screws 42767-01 • 10/19/07 • Hunter Fan Company...
- Page 12 Incorrect connection could cause improper operation and damage to the product. 7-10. Place the lower switch housing assembly over the upper switch Steps 7-9 – 7-10 housing. Align the side screw holes in the upper and lower switch housings. Attach the lower switch housing to the upper switch housing with three housing assembly screws. Lower Switch Housing Plug Connector Detail Housing Assembly Screw 42767-01 • 10/19/07 • Hunter Fan Company...
- Page 13 7-12. Thread the light pull chain through the hole in the center of the glass bowl. 7-13. To install the globe, loosen the three thumbscrews. 7-14. Raise the globe to the light fixture. Tighten the thumbscrews securely. Do not over tighten. Light Bulbs (B10 Candelabra- Based, 60 Watt Maximum) Glass Bowl 42767-01 • 10/19/07 • Hunter Fan Company...
-
Page 14: Operating And Cleaning Your
8-5. Clean wood finish blades with a furniture polishing cloth. Occasionally, apply a light coat of furniture polish for added protection and beauty. Clean painted and high-gloss blades in the same manner as the fan finish. In cold weather, use upward air flow pattern 42767-01 • 10/19/07 • Hunter Fan Company... -
Page 15: Troubleshooting
3. Turn power off, support fan very carefully, and check that the hanger ball is properly seated. If you need parts or service assistance, please call 888-830-1326 or visit us at our Web site at http://www.hunterfan.com. Hunter Fan Company 2500 Frisco Avenue Memphis, Tennessee 38114 42767-01 • 10/19/07 • Hunter Fan Company...
