Hunter 22563 Parts Manual

Hardware
(Drawn to Scale)
x 1
x 2
x 4
x 2
x 3
x 4
x 1
x 4
x 11
x 16
x 16
Balancing
x 1
Kit
Wire
x 3
x 4
Connector
x 3
Low Profile
Washer
3" Wood Screw
Hanger
Flat Washer
Bracket
Assembly
1.5" Wood Screw
Low Profile
Screw
Canopy Screw
Set Screw
Isolator
Blade
Assembly
Screw, Blade
Iron Armature
Screw, Blade
Assembly
Blade
Grommet
Switch
Housing
Assembly
Screw, Switch
Housing Assembly
Screw,
Machine, 6-32
Fan Parts
(Not Drawn to Scale)
PARTS GUIDE
PARTS GUIDE
Using this Parts Guide, make sure all
parts are included in the box.
If parts are missing, DO NOT RETURN
THIS ITEM TO THE STORE, call 866-268-1936 for assistance.
THIS PARTS GUIDE IS FOR REFERENCE ONLY.
REFER TO THE INSTALLATION MANUAL FOR FULL ASSEMBLY INSTRUCTIONS.
Model #

Parts List

Asm. Dwg. #
Finish
Item Name Qnty
* Hanging System Kit 1
Ceiling Plate
Canopy
Canopy Trim Ring
Hanger Ball / Downrod Assembly
Setscrew
Low Profile Washer
Canopy Screw
Wood Screw 1.5"
Wood Screw 3"
Flat Washer
* Screw, Low Profile
Switch Housing Assembly 1
Light Kit Assembly 1
Retaining Ring 3
Blade Iron Set 1
Blade Set 1
Screw, Blade Iron Armature 11
Hardware Kit 1
Blade Grommet
Blade Assembly Screw
Screw, Machine, 6-32
Wire Connector
Screw, Switch Housing Assembly
Balancing Kit 1
Dummy Terminal, Male 1
Dummy Terminal, Female 1
Switch Housing Cover 1
Plug Button 1
Light bulb / Bulb 3
Globe/Shade 3
Hunter Fan Company • 7130 Goodlett Farms Pkwy. #400 • Memphis, TN 38016 • www.hunterfan.com • 98000-01-635 09-23-2010 •
22563
96869-01
New Bronze
Part #
96759-30
99807-30
97096-01
75990-01
92805-05
G0761-24
63755-05
96869-00-860
65666-01
08198-01
08200-01
73853-01
73854-01
77646-04
87215-01
