- Page 1 TransVision ™ TransVision3 Operating Instructions Read these instructions completely before operating this unit. Contents subject to change without notice or obligation. ™ TransVision Printed in USA...
-
Page 2: Table Of Contents
Table of Contents Safety Instructions …………………………………………………………………………………………… Introduction.......…………………………………………………………………………..… ™ Programming SL-8000 Remote Control to Operate TransVision 3………..…………………………. Connection and Installation of Digital Video Processor……………….………………………………………………….…………………. Installation of the Projector……………………………………………………………………………… Quick Reference Remote Control Operation ....………………………………………………… The Front Panel Controls........…………………………………………………………… Information Menu……….........…………………………………………………………… Using The Control Menus........………………………………………………………… Main Menu ........……………………………………………………………... -
Page 3: Safety Instructions
Safety Instructions WARNING HAZARDOUS VOLTAGE DO NOT OPEN ATTENTION COURANT ELECTRIQUE NE PAS OUYRIR CAN SHOCK, BURN OR CAUSE SEVERE INJURY OR DEATH. DO NOT REMOVE THE TOP COVER. REFER SERVICING TO QUALIFIED PERSONNEL. 1. Read and apply all of the safety and operating instructions provided with your video equipment. 2. - Page 4 FCC CAUTION: Pursuant to Part 15 of the FCC rules, any changes or modifications to this projector not expressly approved by DWIN Electronics Inc. could cause harmful interference and would void the user’s authority to operate this device. - 4 of 23...
-
Page 5: Introduction
Introduction ™ TransVision 3 is a High Definition Digital Video Projection system comprised of two complementary ™ components, a DLP Projector featuring Mustang/HD2 technology from Texas Instruments and a ™ Digital Video Processor. The TransVision 3 offers a outstanding progressive scan HDTV images with 16:9 aspect ratio and 1280x720 (720P) native resolution. -
Page 6: Programming Sl-8000 Remote Control To Operate Transvision ™ 3
Control Signals are transmitted between the Projector and the Digital Video Processor via the DWIN proprietary DVI cable. ™ NOTE: For the TransVision to operate correctly requires the use of a DWIN DVI cable between the Projector and the Digital Video Processor! - 6 of 23... - Page 7 2. DVI-D INPUTS The DVI 1 and DVI 2 inputs are provided for HD (480p, 580p, 720p, 1080i) sources and computer graphics with VGA, SVGA, XGA, and SXGA resolution. For computer graphics with VGA, SVGA, XGA, or SXGA it is recommended to set the computer to 60 Hz vertical frequency. 3.
-
Page 8: Installation Of The Projector
This sensor should not be covered to insure proper operation. 3. The Digital Input should be connected to the circular connector on DWIN’s DVI cable and the DVI- D connector connected to the Digital Output on the back of the Digital Video Processor. -
Page 9: Quick Reference Remote Control Operation
Quick Reference Remote Control Operation ™ The remote control provided with the TransVision ™ TransVision 3 is a universal remote control capable of controlling eight different devices. ™ Select TV device to control the TransVision ™ Press TV to turn the TransVision ™... -
Page 10: The Front Panel Controls
The Front Panel Controls TransVision 3 DWIN POWER MENU FUNCTION VALUE ™ The TransVision 3’s front panel controls include: A POWER button to turn the system On or Off. A MENU button to display the Main menu, or to return to the previous menu. -
Page 11: Input Option
When the power is turned on the TransVision 3 will restore all t settings and display the last active input as a current input. Format Option ® ™ DWIN TransVision From the Main menu scroll up ▲ or down ▼ to highlight the Input ◄Video 1 ►... -
Page 12: Setup Menu
Use the left ◄ or right ► buttons to select 15, 30, 45 or 60 seconds. Menu Position ® ™ DWIN TransVision This feature is to select the location of menus on the screen. ▲ Use the left ◄ button to move the menu to the left, right ► button to the right, up ▲... -
Page 13: Rename Inputs
Rename Inputs This feature is for changing Input Names which appear on the Main Rename Input menu. A default name is provided for each input such as Video 1. Scroll up ▲ or down ▼ the default list to highlight a desired input. Video 1 Video 1 Scroll the right ►... -
Page 14: Image Setup
Image Setup The Image Setup menu allows you to position and adjust the video image size. Video image parameters vary from different video sources Image Setup and must be adjusted to properly fit the screen. H-Position H-Size 1876 To Adjust the Video Image Size and Position: V-Position V-Size Select either the H-Position, H-size, V-Position or V-size option in... -
Page 15: Power Button Setup
Please refer to our TransVision 3 throw distance calculator, under the Software section at www.dwin.com for physical mounting dimensions. 2. Preparation and Installation of the ceiling mount bracket, including drilling holes, securing the bracket to the ceiling and assembling the mounting hardware. -
Page 16: Throw Distance Calculation
The maximum screen offset can be 40% of the picture height plus six inches. Please refer to Lens Shift Adjustment on Page 20. ™ Please refer to our TransVision 3 Calculator, under the Software section at www.dwin.com for assistance with calculating these dimensions. - 16 of 23... -
Page 17: Ceiling Mount Preparation
Note: that the ceiling mounting system enables you to make small adjustments to the vertical tilt without introducing visible keystone distortion. ™ The TransVision 3 is a 16:9 Projector and is designed to be used with a 16:9 screen. For floor-mounted installations the picture offset is the distance between the mounting surface of the projector and the bottom of the picture. -
Page 18: Ceiling Mount Installation & Projector Mounting
8. Raise the assembly “C” and the Projector as a unit and hang from bracket ”B” by sliding two center side screws on bracket “B” into the “L” shaped groove at the outer edges of the assembly “C” mounting bracket. Secure the two assemblies together using the hex screws on the left and right sides of the projector. -
Page 19: Physical Dimensions
When the unit is mounted inside a cabinet, be certain that an exhaust vent is provided so that the hot air generated by the projector may be safely removed from the cabinet. To make the three dimensional adjustment, (the vertical lens offset, up and down or parallel) use the white field pattern of the Screen Setup menu. -
Page 20: Transvision ™ 3 Rs-232 Control
™ TransVision 3 RS232 Control ™ The RS232 interface for the TransVision 3 can be operated from any terminal, such as a Windows based PC running HyperTerminal. Communication Port Set-Up Connector pin-out Baud Rate : 9600 (Transmit Data) Parity : none (Receive Data) Stop bits GND (Signal Ground) -
Page 21: Specifications
Specifications Projector Specifications Controller Specifications Video Systems HDTV / DTV / NTSC / PAL Display Device 1280x720 DMD HD2 Mustang Scanning Formats 480i, 480p, 540p, 580i, 580p, (Digital Micro-mirror Device) Aspect Ratio 16:9, 4:3, Letterbox 720p, 1080i Native Resolution 1280 x 720 / 16:9 PC Signals VGA / SVGA / XGA / SXGA Inputs... -
Page 22: Warranty
Unstable Pixel – No unstable pixels. DWIN Electronics will, at its option, either repair or replace the defect, or replace the defective product or part thereof at no charge to the owner for parts and labor covered by this warranty.
